BenQ SX920 Manual de usuario

The above numbers are approximate and may be slightly different from the actual measurements. Only the recommended

screen sizes are listed. If your screen size is not in the table above, please contact your dealer for assistance.

Projection dimensions

The screen aspect ratio is 16:10 and the projected picture is 16:10

SU922

Screen dimensions Projection distance <D> [cm]Lowest/

Highest lens

position <E>

[cm]

Diagonal

<A>

[inch (mm)]

Height

[cm]

Width

<C>

[cm]

Min distance Average Max distance

<A>

<C> <E>

<D>

<F>

<G>

<A>

<C>

<F>

<G>

<D>

<E>

<F>: Screen <G>: Center of lens

60 (1524) 81 129 139180221 4.0

70 (1778) 94 151 162210258 4.7

80 (2032) 108 172 185240295 5.4

90 (2286) 121 194 208270332 6.1

100 (2540) 135 215 231300369 6.7

110 (2794) 148 237 254330406 7.4

120 (3048) 161 259 277360442 8.1

130 (3302) 175 280 300390479 8.8

140 (3556) 189 302 323420516 9.4

150 (3810) 202 323 34645055310.1

160 (4064) 215 345 36947959010.8

170 (4318) 229 366 39250962711.4

180 (4572) 242 388 41553966312.1

190 (4826) 256 409 43856970012.8

200 (5080) 269 431 46159973713.5

The above numbers are approximate and may be slightly different from the actual measurements. Only the recommended

screen sizes are listed. If your screen size is not in the table above, please contact your dealer for assistance.

Projection dimensions

The screen aspect ratio is 16:10 and the projected picture is 16:10

SW921

Screen dimensions Projection distance <D> [cm]Lowest/

Highest lens

position <E>

[cm]

Diagonal

<A>

[inch (mm)]

Height

[cm]

Width

<C>

[cm]

Min distance Average Max distance

<A>

<C> <E>

<D>

<F>

<G>

<A>

<C>

<F>

<G>

<D>

<E>

<F>: Screen <G>: Center of lens

60 (1524) 81 129 145189233 6.1

70 (1778) 94 151 169221272 7.1

80 (2032) 108 172 193252311 8.1

90 (2286) 121 194 218283349 9.1

100 (2540) 135 215 24231538810.1

110 (2794) 148 237 26634642711.1

120 (3048) 162 259 29037846612.1

130 (3302) 175 279 31440950413.1

140 (3556) 189 302 33844154314.1

150 (3810) 202 323 36247258215.1

160 (4064) 215 345 38650462116.2

170 (4318) 229 366 41153566017.2

180 (4572) 242 388 43556669818.2

190 (4826) 256 409 45959873719.2

200 (5080) 269 431 48362977620.2

The above numbers are approximate and may be slightly different from the actual measurements. Only the recommended

screen sizes are listed. If your screen size is not in the table above, please contact your dealer for assistance.

Projection dimensions

The screen aspect ratio is 4:3 and the projected picture is 4:3

SX920

Screen dimensions Projection distance <D> [cm]Lowest/

Highest lens

position <E>

[cm]

Diagonal

<A>

[inch (mm)]

Height

[cm]

Width

<C>

[cm]

Min distance Average Max distance

<F>: Screen <G>: Center of lens

<A>

<F>

<G>

<A>

<C>

<E>

<D>

<F>

<G>

60 (1524) 91 122 17222427513.7

70 (1778) 107 142 20126132016.0

80 (2032) 122 163 23029836618.3

90 (2286) 137 183 25833541220.6

100 (2540) 152 203 28737245822.9

110 (2794) 168 224 31640950325.1

120 (3048) 183 244 34444754927.4

130 (3302) 198 264 37348459529.7

140 (3556) 213 285 40252164132.0

150 (3810) 229 305 43055868634.3

160 (4064) 244 325 45959573236.6

170 (4318) 259 345 48863377838.9

180 (4572) 274 366 51667082341.1

190 (4826) 290 386 54570786943.4

200 (5080) 305 406 57374491545.7

Ceiling mount screws: M5

(Max. L = 25 mm;

Min. L = 20 mm)

Unit: mm

205.94

411.88

135

267.5

75.53

549.7

582.7

407.7

289.7

291.2065.94

35.74

164.1

172.26

3.5
