BenQ MS521 Manual de usuario

BenQ QSG-5130.book Page 1 Monday, June 24, 2013 2:20 PM

Digital Projector

uick Start Guideuick Start Guide

Install the lens cap

1. Attach the lens cap strap.

2. Close the lens cap as left.

BenQ QSG-5130.book Page 2 Monday, June 24, 2013 2:20 PM

568

224

BenQ QSG-5130.book Page 3 Monday, June 24, 2013 2:20 PM

The above numbers are approximate and may be slightly different from the actual measurements. Only the

recommended screen sizes are listed. If your screen size is not in the table above, please contact your dealer

for assistance.

MS521/MX522/MS511H

MW523/TW523

BenQ QSG-5130.book Page 4 Monday, June 24, 2013 2:20 PM

Ceiling mount screws˖

M4 x 8(Max.L=8 mm)

Unit˖mm

80.0

196.0

181.0

71.9

301.6

21.0

81.0

57.5 162.1

BenQ QSG-5130.book Page 5 Monday, June 24, 2013 2:20 PM

BenQ QSG-5130.book Page 6 Monday, June 24, 2013 2:20 PM

BenQ QSG-5130.book Page 7 Monday, June 24, 2013 2:20 PM

OFF

BenQ QSG-5130.book Page 8 Monday, June 24, 2013 2:20 PM

Ta b l e o f c o n t e n t s

English .............................................................................................. 10

Français ............................................................................................ 11

Deutsch ............................................................................................ 12

Italiano.............................................................................................. 13

Español ............................................................................................. 14

Português ......................................................................................... 15

Svenska............................................................................................. 16

Русский............................................................................................ 17

Nederlands....................................................................................... 18

Polski................................................................................................. 19

Türkçe .............................................................................................. 20

Čeština..............................................................................................21

ไทย ..................................................................................................... 22

繁體中文............................................................................................ 23

简体中文............................................................................................ 24

日本語 ............................................................................................... 25

한국어 ............................................................................................... 26

............................................................................................ 27

BenQ QSG-5130.book Page 9 Monday, June 24, 2013 2:20 PM

All specifications are subject to change without notice.

Lamp life results will vary depending on environmental conditions and usage.

Optical

Resolution

(MS521/MS511H)

800 x 600 SVGA

(MX522)

1024 x 768 XGA

(MW523/TW523)

1280 x 800 WXGA

Display system

1-CHIP DMD

Lens F/Number

(MS521/MX522/MS511H)

F = 2.51 to 2.69,

f = 21.95 to 24.18 mm

(MW523/TW523)

F = 2.55 to 3.06

f = 21 to 25.6 mm

Offset

(MS521/MX522/MS511H): 130% ;

(MW523/TW523): 125%

Zoom ratio

(MS521/MX522/MS511H): 1.1X;

(MW523/TW523): 1.2X

Lamp

(MS521/MX522/MW523/MS511H/

TW523): 190 W lamp

Electrical

Power supply

AC100–240V, 2.6 A,

50-60 Hz (Automatic)

Power consumption

(MS521/MX522/MW523/MS511H/

TW523): 265 W (Max); < 0.5 W

(Standby)

Mechanical

Weight

2.3 Kg (5.1 lbs)

Output terminals

RGB output

D-Sub 15-pin (female) x 1

Speaker

(Stereo) 2 watt x 1

Control

RS-232 serial control

9 pin x 1

IR receiver x 1

USB Type B x 1

Input terminals

Computer input

RGB input

D-Sub 15-pin (female) x 2

Video signal input

S-VIDEO

Mini DIN 4-pin port x 1

VIDEO

RCA jack x 1

SD/HDTV signal input

Analog - Component RCA jack x 3

(through RGB input)

Digital-HDMI x 1

Audio signal input

Audio in

PC audio jack x 2

Audio out

PC audio jack x 1

Environmental Requirements

Operating temperature

0°C-40°C at sea level

Operating relative humidity

10%-90% (without condensation)

Operating altitude

0-1499 m at 0°C-35°C

1500-3000* m at 0°C-30°C (with High

Altitude Mode on)

* China region only applies to an altitude

of 2000m.

Specifications

(EN)

BenQ QSG-5130.book Page 10 Monday, June 24, 2013 2:20 PM
