BenQ HT6050 Manual de usuario

4J.04J02.001

HT6050

Projection dimensions

Projection distance

Center of lens

Screen

Vertical offset

Maximum zoom Minimum zoom

W

H

The screen aspect ratio is 16:9 and the projected picture is 16:9.

Screen Size Semi Long Long Zoom

Diagonal Width Height Distance Distance

Wide

Tele Wide Tele

Inch m Inch m Inch m Inch m Inch m Inch m Inch m

Screen Size Wide Zoom Standard

Diagonal Width Height DistanceDistance

Wide Wide TeleTele

Inch m Inch m Inch m Inch m Inch m Inch m Inch m

200 5.08 174 4.43 98 2.49 192 4.87 227 5.76 268 6.82 336 8.55

300 7.62 261 6.64 147 3.74 288 7.31 340 8.63 - - - -

400 10.16 349 8.86 196 4.98 - - - - - - - -

- - - - - - - -

500 12.70 436 11.07 246 6.23

80 2.03 70 1.77 39 1.00 77 1.95 91 2.30 107 2.73 135 3.42

100 2.54 87 2.21 49 1.25 96 2.44 113 2.88 134 3.41 168 4.27

120 3.05 105 2.66 59 1.49 115 2.92 136 3.45 161 4.09 202 5.13

150 3.81 131 3.32 74 1.87 144 3.65 170 4.32 201 5.11 252 6.41

500 12.70 436 11.07 246 6.23 - - - - - - - -

200 5.08 174 4.43 98 2.49 336 8.55 506 12.84 523 13.28 872 22.14

300 7.62 261 6.64 147 3.74 505 12.82 758 19.26 784 19.92 1307 33.21

400 10.16 349 8.86 196 4.98 673 17.09 1011 25.68

- - - -

80 2.03 70 1.77 39 1.00 135 3.42 202 5.14 209 5.31 349 8.86

100 2.54 87 2.21 49 1.25 168 4.27 253 6.42 261 6.64 436 11.07

120 3.05 105 2.66 59 1.49 202 5.13 303 7.70 314 7.97 523 13.28

150 3.81 131 3.32 74 1.87 252 6.41 379 9.63 392 9.96 654 16.60

The above numbers are approximate and may be slightly different from the actual

measurements. Only the recommended screen sizes are listed.

If your screen size is not in the table above, please contact your dealer for assistance.

Screen Size Wide Fix

Diagonal Width Height Distance

NA

Inch m Inch m Inch m Inch m

200 5.08 174 4.43 98 2.49 136 3.44

300 7.62 261 6.64 147 3.74

400 10.16 349 8.86 196 4.98 - -

- -

- -

500 12.70 436 11.07 246 6.23

80 2.03 70 1.77 39 1.00 54 1.38

100 2.54 87 2.21 49 1.25 68 1.72

120 3.05 105 2.66 59 1.49 81 2.07

150 3.81 131 3.32 74 1.87 102 2.58

Ceiling Mount Installation

431.0 mm (W) x 167 mm (H) x 320.5 mm (D)

530.8

547.8

614.8

431.0

216.0

334.5

431.0

156.0

174.5

167.0

64.0

83.0

316.9

26.5

73.5

320.5

334.5

431.0

165.0

20.0

130.0

240.0

260.0

*Ceiling Mount Screws:

M4 (Max. L=12, Min. L=10)

2

ON

22 1

4

1

3

5

PUSH

12

ON

3

5

4

3

1

2

X2

X2

OFF
