BeNext MoLiTe Manual de usuario



Version0.320February2012www.2iHome.eu

Quickstart

MoLiTesensorEU

Technicalspecs

Normaloperatingvoltage2xAA1,5Vbatteries

Frequencyrange868.42MHz

WirelessRangeUpto30metersinlineofsight

Temperaturesensoraccuracy+/‐2,5°Cfrom‐55

Cto+130

C

MotionsensorrangeMax.10metersundera110

angle

BasicOperations

‐TheMoLiTecandetectmovement,

‐TheMoLiTecanmeasurelightintensity

‐TheMoLiTecanmeasurethetemperature.

‐TheMoLiTecantriggerasecuritysystem.

Howitoperates

AfterasuccessfulinclusiontheMoLiTecanbemountedonthewalldirectlyorwithabracket.

Whenmovementisdetectedtheindicatorlightwillblinkshortly,thisindicatesthataz‐wavemessagehas

beensendsuccessfully.

Withacontrolleryoucanrequestthetemperatureandbatterylevel.

Mounting

1. Beforemount,theMoLiTeSensorshouldbeincludedintoaZ‐Wavenetworkandassociated.

2. Useaflatscrewdriverattheinletsonthesidestogentlyunlockthebackcover.

3. Usethesuppliedscrewstomountthecoverorbrackettothewall.

Foroptimaluse,mounttheMoLiTebetween1,5mand2,5maboveground

(ArotatingbracketisavailabletoadjustthedirectiontheMoLiTeispointingto).

4. PlacetwoAA1,5Vbatteriesintothedevice.

5. MounttheMoLiTeontothebackcoverandbesuretocloseitonallsides.

6. Mountingiscompletedwhentheledblinksforafull1sec.

7. TheMoLiTesensorhastostartupforca10seconds.

8. Afterca10secondstheMoLiTeisreadyfordetection.

IncludeorexcludeinZ‐Wavenetwork1

1. WhentheMoLiTeismounted,removeitfromthebackcover.

2. PressandholdtheTamperswitchfor2secondsandreleasetostarttheinclusionorexcludeprocess.

3. Whenclassicinclusionfailed,theproductwillstartNetworkWideInclusionautomatically.





1MakesureyourZ‐Wavecontrollerisindecorrectoperationmode(includeorexclude).

Tamperswitch

Indicatorlight

Movementsensor

Lightand

temperature

sensor



Version0.320February2012www.2iHome.eu

TechnicalManual

Caution:

‐Thisdeviceisusingaradiosignalthatpassesthroughwalls,windowsanddoors.Therangeisstrongly

influencedbylocalconditionssuchaslargemetalobjects,housewiring,concrete,furniture,

refrigerators,microwavesandsimilaritems.Onaverage,theindoorrangeisapproximately30meters.

‐Donotexposethisproducttoexcessiveheatormoisture.

‐Preventlongtermexposuretodirectsunlight.

‐Donotattempttorepairthisproduct.Iftheproductisdamagedorifyouareindoubtaboutthe

properoperation,taketheproductbacktotheplaceofpurchase.

‐Donotcleantheproductwithanyliquid.

‐Indooruseonly.

Technicaldetails



Detailedinstruction

WeadvisetheMoLiTetobemountedbetween1,5mand2,5mfromtheground,flaton

thewallandnotfacingdown.Withanoptionalbracket,thedirectiontheMoLiTeis

pointsatcanbechanged(up/downandleft/right).TheMoLiTedetectsmovementupto

10meters.Withoutbracketattached,itisrecommendedtoplacetoMoLiTeinthe

middleofthewall(see‘Goodsensorpositioning’).







Badsensorpositioning(poorareacoverage)Goodsensorpositioning



Normaloperatingvoltage2xAA1,5Vbatteries

From2,3to4,0V

donotuserechargeablebatteries

Frequencyrange868.42MHz

WirelessRangeUpto30metersinlineofsight

Temperaturesensoraccuracy+/‐2,5

Cfrom‐55

Cto+130

C

MotionsensorrangeMax.10metersundera110

angle

Storagetemperature‐5

Cto+65

Storagehumidity10%to70%

Operatingtemperature0

Cto50

C

Operatinghumidity:30%to80%



Version0.320February2012www.2iHome.eu



Indicationmode

Theindicatorlightgivesvariousstatusesofthedeviceasfollows:

1. Readyforlearnmode: indicatorlightblinkseverysecond.

2. Learninprogress(add):indicatorlight2timeseverysecond.

3. Learninprogress(remove):indicatorlight3timeseverysecond.

4. Learnmodesuccess: indicatorlightisonforonesecond.

5. Learnmodefailed: indicatorlightblinks8timesrapidly.

6. Tamperpressed/releasedindicatorlightblinks3timesrapidly.

7. Mountingsuccessful  indicatorlightisonfor1second.

8. RFmessagesendfailed indicatorlightblinks6timesrapidly



SupportingCommandClasses

Basictype:BASIC_TYPE_ROUTING_SLAVE

Generictype:GENERIC_TYPE_SENSOR_BINARY

Specifictype:SPECIFIC_TYPE_NOT_USED

Listening:False,Z‐WaveLib:4.51



class:0x30COMMAND_CLASS_SENSOR_BINARY

class:0x31COMMAND_CLASS_SENSOR_MULTILEVEL

class:0x60COMMAND_CLASS_MULTI_CHANNEL_V2

class:0x70COMMAND_CLASS_CONFIGURATION

class:0x71COMMAND_CLASS_ALARM

class:0x72COMMAND_CLASS_MANUFACTURER_SPECIFIC

class:0x80COMMAND_CLASS_BATTERY

class:0x84COMMAND_CLASS_WAKE_UP

class:0x85COMMAND_CLASS_ASSOCIATION

class:0x86COMMAND_CLASS_VERSION

class:0xEFCOMMAND_CLASS_MARK

class:0x20COMMAND_CLASS_BASIC



NotlisteningRoutingSLAVE

ThisZ‐Waveproductwillbeusedasroutingslave.SlavenodesarenodesinaZ‐Wavenetworkthatreceive

commandsandperformactionsbasedonthecommand.Thisdevicewillalwaysbeinsleepmodebecauseit

worksonbatteries.Insleepmodethedeviceisnotactivelistening,thedevicewillwakeupaccordingtothe

wakeupcommandclass.



IncludeInitiator

TheincludeinitiatorisusedwhenPrimaryandInclusionControllersincludenodesintothenetwork.When

boththeincludeinitiatorhavebeenactivatedsimultaneouslythenewnodewillbeincludedtothenetwork(if

thenodewasnotincludedpreviously).

ExcludeInitiator

TheexcludeinitiatorisusedbyPrimaryControllerstoexcludenodesfromthenetwork.Whentheexclude

initiatorandaslaveinitiatorareactivatedsimultaneously,itwillresultintheslavebeingexcludedfromthe



Version0.320February2012www.2iHome.eu

network(andresettoNodeIDzero).Eveniftheslavewasnotpartofthenetworkitwillstillberesetbythis

action.

Z‐Wavecompatibility

BecausethisisaZ‐Wavedevice,itmeansitcanco‐operatewithotherZ‐Wavedevicesofothermanufacturers.

Itcanco‐existinaZ‐Wavenetworkexistingwithproductfromothermanufacturers.

Hops&Retries

TheZ‐Waverangehasarangeofupto30metersinlineofsight.Thissignalisnotlimitedtothe30meter

rangeduetoroutingtheZ‐Wavemessagetoothernodesinthenetwork.ThiswaytherangeoftheZ‐Wave

networkcanbeexpandedto150metersindoors(limitof4hops).



class0x20COMMAND_CLASS_BASIC

Whenamovementisdetectedabasicsetframewithvalue255issenttotheassociatednodes.Ifthe

configuredtimeisdonewithnomovementisdetectedabasicsetframewithvalue0issenttotheassociated

nodes.Thisisthecontrollingroleofthebasiccommandclass.



Thesupportingroleofthebasiccommandclassismappedtothesensorbinarycommandclass.

class:0x30COMMAND_CLASS_SENSOR_BINARY

TheSensorBinaryCommandClasscanbeusedtocheckifmotionisdetected,value0meansthatthereisno

motiondetectedandthereforeaassociatednodeisoff,value255meansthataassociatednodeison.



Class:0x80COMMAND_CLASS_BATTERY

Thisclassisusedtorequestandreportbatterylevelsforagivendevice.

Whenbatterylevelislowerthen20%theMoLiTewillsendabatterywarning(value255)aftereverywakeup

notification.Abatterygetwillreporttheactualvalueevenifbelow20%



class:0x86COMMAND_CLASS_VERSION

ThisCommandClassisusedtoobtaininformationabouttheMoLiTe.TheZ‐Wavelibrarytype,theZ‐Wave

protocolversionandtheapplicationversionwillbereported.

Becausetheversion2issupportedthiscommandclasscanalsobeusedtorequesttheserialnumberofthe

devicewiththeDEVICE_SPECIFIC_GETcommand.



class:0x72COMMAND_CLASS_MANUFACTURER_SPECIFIC

Thiswillreportinformationaboutthemanufacturer.ThisproductwillcontainthemanufacturerIDofBeNeXt.

ManufacturerIDofBeNeXtis138,theIDofthisproductis4.



class:0x70COMMAND_CLASS_CONFIGURATION

Configureparameters:



0. Notused

1. Settodefault

Description:Setallconfigvaluestodefaultvalues(factorysettings).Readmorein

chapterconfigurationReset.

Size: 1byte*

Param1:  if0xFFthensettodefault

Param2,3,4:notused



Version0.320February2012www.2iHome.eu



2. Modetimeout

Description:Thetimeusedinmode2toturnthesensoroff.This

Timewillstartrunningassoonasdetectionisseen.

Defaultvalue:0x0384=900sec=15min



Size:2bytes(integer)*

Param1:  themostsignificantbyteoftheinteger

Param2:  theleastsignificantbyteoftheinteger

Param3,4:notused 



3. Switchofftime

Description:Theswitchofftimewillstartrunningassoonasmodetimeoutisdone.

Motionsensoristurnedonandwhenmovementis

detectedagainthemodetimeout(cfgparam1)willstartrunningall

overagain.

Whenswitchofftimeisdoneabasicoffmessageissenttothe

associatednode.

Defaultvalue:0x0A8C=2700sec=45min.  



Size:2bytes(integer)*

Param1:  themostsignificantbyteoftheinteger

Param2:  theleastsignificantbyteoftheinteger

Param3,4:notused 



4. Sensitivity

Description:thesensitivityofthemotioncircuit

Default:0x50=80



Size: 1byte*

Param1:Sensitivityvaluebetween0and127(valuesabove127willbereported

asthesetvaluebutwillbehandledinSWas127).

0isleastsensitiveand127ismostsensitive.

Param2,3,4:notused



5. themode

Description:  Themodethatisenteredafterdetection

Default:  0x02



Size:1byte*

Param1:mode1,2or3.

Mode1:nodetectionpossible.Batterysavemode

Mode2:normaloperationmode:sendonafterdetectionandoffafter

giventimenodetection.

Mode3:Z‐Wavechipisalwaysontorequeste.g.versionor

manufacturerid.

Ifmodeis0orhigherthen3,thatvaluewillbereportedafteragetbut

willbehandledinSWasmode2.

Param2,3:  notused.



6. Thetemperatureoffset

Description:  Aoffsetforthetemperature.



Version0.320February2012www.2iHome.eu

Default:  0x00



Size:2bytes*

Param1,2:  Asignedintegertodeterminetheoffsetoffthetemperature.

Param3,4:  notused.



*ifasizeisotherthengivensizetheframeisignoredtotallysoconfigurationvaluesarenotchanged



class:0x31COMMAND_CLASS_SENSOR_MULTILEVEL

Sensor_multilevel_get

TheSensorMultilevelCommandClassisusedtogetareportfromtheMoLiTe.Thereturnedvalueisthe

measuredtemperatueinsidethehousingwith2decimals.



class:0x60COMMAND_CLASS_MULTI_CHANNEL_V2

Requesttemperature

Channel1

Note:Thereturnedvalueisthemeasuredtemperature(+/‐offset)insidethehousingwith2decimals.



Requestlight/lux

Channel2

Note:ThereturnedvalueisthemeasuredLDRresistancein%.



class:0x85COMMAND_CLASS_ASSOCIATION

TheAssociationCommandClassisusedtoassociateotherdeviceswiththeMoLiTe.Thedevicesthatare

associatedcanbecontrolledonapplicationlevel.Everynodeassociatedinthegroupwillbeswitchedonwith

aBASIC_SETverytimemotionisdetected.



Numberofgroupings:1

Maximumsupportednodespergroup:5



Becauseonlyonegroupissupportedgroupingidentifierisignoredinallcases.



class:0x84COMMAND_CLASS_WAKE_UP

TheWakeUpCommandClassisusedatbattery‐operateddevices.ThisclassallowstheMoLiTetowakeup

occasionallytonotifyothersdevices,thattheMoLiTeisreadytoreceivecommands.Afterreceivingthe

commandstheMoLiTewillgointosleepmodeagain.Thewakeupintervalcanbesetusingthe

WAKE_UP_INTERVAL_SETcommand.



Thedefaultvalueis0x1C20=7200sec=2hour

Thedefaultnodeis0xFF=255(broadcast)



Itispossibletosendawakeupnotificationonuserinteraction.Todothispressandholdthetamperswitch

for4seconds(mountthedevice).



Whenthewakeuptimeissetto0awakeupnotificationisneversendperiodically,onlyonuserinteraction.



Version0.320February2012www.2iHome.eu

class:0x71COMMAND_CLASS_ALARM

Thiscommandclassisusedtoidentifythestateofthetamperalarm.Thedevicewillsendanunsolicitedreport

tothecontrollerifthestatusischanged,thevalue0x00willindicatethatthetamperisplacedcorrectlyonthe

wall.Thevalue0xFFwillindicateatamperalarm.

Thereis1alarmtype:

3:Tamperswitch

Everyotheralarmtypethatisrequestedwillbeignoredbyapplication.



Version0.320February2012www.2iHome.eu

ConfigurationReset

TheMoLiTeSupportsaconfigurationresetfunction.Configurationresetmeans

‐Allconfigurationvaluesaredefaulted.

‐Wakeupintervalisdefaulted.



Note:Allconfigurationswillalsobedefaultedafterexclusionthedevice.



Thisfunctioncanbeactivatedbysendingaconfigurationsetframe:



CONFIGURATION_SET

Parameter:0x01

Size: 0x01(can’tbedifferentfrom1)

Value: 0xFF(canbeanyvalueexceptfor0x55or0xAA)



Whenthevalueofconfigurationvalueisrequested2possiblevaluescanbereturned



CONFIGURATION_REPORT

Parameter:0x01

Value0x55:Devicedoesn’thaveallhisdefaultconfigurationsettingsanymore.

Evenwhenaconfigurationparameterischangedbacktothedefaultvalue

Value0xAA:Devicesstillhasallhisfactorysettings.

Thisareonlyconfigurationparameters,wakeupintervalcanbechanged.



Alwaysawakemode

Thealwaysawakemodeisusedtorequestdifferentvaluesfromthedevicee.g.versionandmanufacturer

specific.



Thealwaysawakemodecanbeactivatedby:



CONFIGURATION_SET

Parameter: 0x05

Size:  0x01(can’tbedifferentfrom1)

Value:  0x03(mode3)



Thealwaysawakemodecanbedeactivatedby:



CONFIGURATION_SET

Parameter: 0x05

Size:  0x01(can’tbedifferentfrom1)

Value:  Anyvalueexcept3



Asecondoptiontodeactivatemode3is

1. Removebatteries.

2. Waitca10seconds.

3. Replacebatteries



Note:inalwaysawakemodethebatterieswillbedrainveryfast,wedonotrecommendtousethismode.



Version0.320February2012www.2iHome.eu

Troubleshooting



FrequentlyAskedQuestions



Q:Ican’thavemyMoLiTeincludedintomyZ‐Wavenetwork,whatamIdoingwrong?

A:1.IsthecontrollerreadytoincludeanydeviceintotheZ‐Wavenetwork?Ifthecontrollerisnotin

Includeorexcludemode,theMoLiTecannotbeincludedorexcluded.

2.TheMoLiTeisalreadyincludedinaZ‐Wavenetwork.ExcludetheMoLiTeand

Trytoincludeitagain.



Q:Whydoesn’ttheMoLiTedetectanymovement?

A:1.TheMoLiTeisn’tincludedinaZ‐Wavenetwork.Includeitandtryitagain.

2.Thebatteriesarealmostempty,tryputtingnewonesin.



Q:ThetemperaturereportoftheMoLiTeisincorrect.

A:1.TheMoLiTeisplaceddirectlyinthesun,whichmakesthetemperatureinthehousingoftheMoLiTe

hotterthanelsewhereintheroom.

2.Thecalibrationisnotthesameasyourothertemperaturesensor,itispossibletodoare‐calibration

ofthetemperaturesensorwith2myhomeandthemyGate.



Q:IhaveconfiguredavaluebutwhenIrequestit,itisnotchanged?

A:Itismandatorythatthecorrectsizeisusedwhileconfigureaparameter;gotothedocumentationabout

theconfigurationcommandclasstocheckiftherightsizeisusedduringconfiguration.Ifthewrongsizeisused

theframeisignoredtotally.



Q:IhaveconfiguredanewvalueandwhenIrequestitthecorrectvalueisreturnedbutthebehaviorisstillthe

same?

A:Someconfigurationparametershavelimitsofwhattheycando,gotothedocumentationabout

configurationtocheckifthevalueoftheconfiguredparameterisoutofflimit.



Q:WhenImounttheMoLiTeitperformsitsstandardmountingroutinebutafter4secondstheindicatorlight

doesn’tgoonfor1secondbutblinks6times.

A:blinking6timescanmean:

1. MoLiTeisnotincluded

2. MoLiTeisnotassociated

3. MoLiTecan’treachedhisdestination

Ifallthreeoptionsarecorrected,MoLiTeiswilloperatecorrectlyandcanbemountedagain.



Q:WhenIexcludetheMoLiTetheconfigurationtimes(idleandswitchoff)areresetbacktodefault.

A:ThatiscorrectwhentheMoLiTeisexcludedallconfigurationsincludingwakeuptimingsareresetbackto

default.Youwillneedtoconfigurethedeviceagainafterincludedintothecontroller.

Byforcingthetamperswitchawakeupmessage(broadcast)willbesendtoeasilychangetheconfiguration.



Tabla de contenidos

Manuales populares de Sensor de seguridad de otras marcas

THORLABS

THORLABS PDA10JT Manual de usuario

Waeco

Waeco UV-DETECT Manual de usuario

Intermatic

Intermatic IOS-DSIMF Manual de usuario

urmet domus

urmet domus 1083 Manual de usuario

Siemens

Siemens AZL66 Series Manual de usuario

BTI

BTI Profiline Multi Finder Manual de usuario

Challenger

Challenger SL01 Manual de usuario

DMP Electronics

DMP Electronics 1122INT Manual de usuario

Rielta

Rielta Ladoga MK-RK Manual de usuario

Mirion Technologies

Mirion Technologies ACCURAD PRD Manual de usuario

Bosch

Bosch DS835 Manual de usuario

DBI SALA

DBI SALA EZ Stop Manual del operador

Lamptime

Lamptime ST05C Manual de usuario

Ubiquiti

Ubiquiti MFI-MSC Manual de usuario

Subsite

Subsite 910R Instrucciones de instalación

Satel

Satel OPAL Pro Manual de usuario

Aleph

Aleph XC-1XTEU Manual de usuario

Pima

Pima LARIS QUAD Manual de usuario
