Beltronics Vector 990 Manual de usuario

Head Office

2422 Dunwin Drive

Mississauga, Ontario

Canada L5L 1J9

Tel: (905) 828-1002 Fax: (905) 828-2951

wwwwww..bbeellttrroonniiccss..ccoomm

This product is subject to one or more of the following patents:

United States

#4,571,593 #4,625,210 #4,630,054 #4,939,521

#4,952,936 #4,961,074 #5,402,087 #5,446,923

#5,587,916 #5,600,132

Canada

#1,187,586 #1,187,602 #1,295,714 #1,295,715

Other Patents Pending

Safety Warning System®L.C.–Patents Pending

Printed in Canada 273004-13

,Fundamental Mixer Technology, FMT and Shadow Technology

are registered trademarks of BELTRONICS USA, Inc. VECTOR 990,

Total Tracking Laser, TTL, AccuSweep and AutoScan are trademarks of

BELTRONICS USA, Inc. Safety Warning System is a registered trademark

of Safety Warning System L.C.

VECTOR 990

Operating Instructions

MOTOROLAMOTOROLA

digitaldna

MOTOROLA

Model V990

International

Digital

Voice and Text Messages

North American

Driver Selectable Features

International

Driver Selectable Features

THE NEXT GENERATION IN DIGITAL PERFORMANCE

CONGRATULATIONS!

SOFTWARE UPGRADABLE

SHADOW TECHNOLOGY®II

Thank you for purchasing VECTOR 990

International

– the

world’s only truly International Radar detector. VECTOR 990

International contains 10 Radar frequencies making it ideal for

travel anywhere in the world. VECTOR 990 International

contains 16 North American Driver Selectable Features and 20

International Driver Selectable Features, 64 Digital Voice and

Text Messages, and the best possible Radar sensitivity in the

industry. Enjoy your new detector and be sure to obey all laws

where ever you may travel.

Remember, owning a Radar detector does not give you a

license to speed. Alerts from a Radar detector serve as an

effective reminder to check your speed. Laws vary throughout

the USA and Europe governing the use of a Radar detector.

It is your responsibility to follow these laws.

VECTOR 990 International contains Flash Technology which

provides the highest capability to be reprogrammed as the

threat of new police traffic radar monitoring technologies

emerge. Please ensure that you promptly send in your

Consumer Information card. This will ensure you are notified

about new traffic monitoring technologies as they emerge.

VECTOR 990

International

contains Shadow

Technology® II making it undetectable to the

Interceptor VG-2 Radar Detector Detector.

Shadow Technology is activated at all times

– no button activity is required.

The custom Anodized Aluminum Travel

Case is designed to protect your unit

and its accessories when not in use.

Enjoy your new purchase and please

drive safely.

Includes 16 Driver Selectable Features

5 Operating Modes 11 General Features

Normal Mode

Modifications Mode

Quick-Start X Band (10.525 GHz) On/Off

Tech Mode

Voltage Meter Mode K Band (24.125 GHz) On/Off

Super Wideband Ka (33.4-36.0)

AccuSweep™

Operating modes are

Selected using PWR Button

See page 00.

AutoMute On/Off

Radar/Laser Digital Voice

Prompts On/Off

Safety Warning System™On/Off

Safety Warning System Digital

Voice or Tone

Audio/Visual Scroll Rate

Fast/Slow

Inverted Display Option

AutoScan

General Features selected by pressing

CTY button followed by the PWR

Button when the unit is off.

Operating Modes are

selected using the PWR button

(

see page 5

General Selectable Features are

accessed by pressing the PWR and

CTY buttons simultaneously, when

the unit is off.

(see page 11.)

Note: for convenience AutoScan

™

is accessed using the CTY button

(see page 9

VECTOR 990

International

provides more user Selectable Features

than any other detector on the market. Selectable Features allow you

to “customize” how alerts will be presented to you.

5Operating Modes

1. NORMAL Mode

A lengthy power up test

sequence; text messages identify

alerts received, i.e. “XXBBaanndd”.

2. MODIFICATIONS Mode

Full Power-up test sequence;

presents ONLY those General

Selectable Features which you

have altered from factory pre-set.

Text messages identify alerts received.

3. QUICK START Mode

No test sequence; unit immediately

shows last used traveling

mode:“AAuuttooSSccaann™”,

“HHiigghhwwaayy”, “ CCiittyyXX”

“CCiittyy

AALLLL

”, Text messages

identify alerts received.

4. TECH Mode

Full Power-up text sequence.

Text messages identify band received

followed by ACTUAL police traffic

radar or Laser frequency, i.e.,

“2244..115500” to confirm K band.

5. VOLTAGE METER Mode

Full Power-up text sequence.

Text Messages identify band

received. Between alerts, display

shows readout of your vehicle’s

battery voltage.

11 General Selectable Features

1. X Band (10.525 GHz)

ON or OFF

2. K Band (24.150 GHz)

ON or OFF

3. Super Wideband Ka

(33.4 – 36.0 GHz)

ON or OFF

4. AccuSweep™ON or OFF

5. AutoMute ON or OFF

6. Radar/Laser Digital

Voice Prompts ON or OFF

7. Safety Warning System™

ON/OFF

8. Safety Warning System™

Digital Voice ON or OFF

9. Audio/Visual Scroll Rate:

FAST or SLOW

10. Inverted Display Option

ON or OFF

11 . AutoScan™, “Highway”,

“City X”or “City ALL.”

Table of Contents

Profile of Features . . . . . . . . . . . . . . . . . . . . . . . . . 4

Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

kPower-Up Test Sequence/Start-Up Mode . . . . 5

kTutorial Mode . . . . . . . . . . . . . . . . . . . . . . . . . 7

kSet and Forget Memory . . . . . . . . . . . . . . . . . . 8

kReset to Factory Settings . . . . . . . . . . . . . . . . . 8

kDRK (Bright/Dim/Dark) Button . . . . . . . . . . . 8

kAUD (Auto-Mute/Volume Control) Button . . . 9

kCTY (City/Highway) Button . . . . . . . . . . . . . . 9

Selectable Features (North American Mode) . . . . . . . 11

kTravel Mode – What is it? . . . . . . . . . . . . . . . . 14

kEngaging Travel Mode . . . . . . . . . . . . . . . . . . . 14

kEntering Selectable Features . . . . . . . . . . . . . . 16

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

kGeneral Guidelines . . . . . . . . . . . . . . . . . . . . . . 16

Understanding Radar, Laser and SWS™. . . . . . . . . . 19

Interpretation of Alerts . . . . . . . . . . . . . . . . . . . . . 20

kRadar Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

kInstant-On/Pulsed Radar Alert . . . . . . . . . . . . 22

kTypical False Alert (Radar) . . . . . . . . . . . . . . . . 23

kLaser Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

kSafety Warning System®(SWS™) Alerts . . . . . . 24

Performance Verification . . . . . . . . . . . . . . . . . . . . 26

Conditions That Affect Radar Alerts . . . . . . . . 26

Conditions That Affect Laser Alerts . . . . . . . . 26

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Warranty Service . . . . . . . . . . . . . . . . . . . . . . . 29

Post Warranty Service . . . . . . . . . . . . . . . . . . . 30

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Profile of Features

1. PWR (Power/Start-Up Mode) Button: pressing

and holding PWR will turn the unit on. Continuing

to press the PWR button will scroll through the five

start-up mode options: NNOORRMMAALL,,MMOODDSS

(Modifications), QQ--SSTTAARRTT(Quick Start), TTEECCHHMMOODDEE,,

VVOOLLTTAAGGEEMMEETTEERRMMOODDEEplus TTUUTTOORRIIAALLMMOODDEE.

2. Text Message Display:communicates all mode

selections (i.e. DDIIMM, DDAARRKK, CCIITTYY, HHIIGGHHWWAAYYand

AAUUTTOOMMUUTTEE)and confirms Radar band and signal

strength, presence of Laser and SWS™messages

received.

3. DRK (Bright/Dim/Dark) Button: provides bright,

dark and fully adjustable dim settings of the Text

Display for discreet night travel. Audio alerts are not

affected.

4. CTY (City/Highway/AutoScan) Button: choose

between Autoscan™, Highway, City X or City ALL

(X/K/Ka) filtration modes.

5. AUD (Auto-Mute/Volume Control) Button:

provides manual muting of all Radar and sws™alerts.

Pressing and holding the AUD button will change the

audio level.

6. Antenna Opening: Radar and sws™signals are

received by a patented diecast antenna with

integrated transition to microstrip mixer.

7. Laser Optical Sensors: collect Laser signals from in

front and behind.

8. Audio Alert Speaker: all audible alerts and Digital

Voice Messages are emitted from this location.

9. Power Jack: using the straight or coiled cord,

VECTOR 990 operates in any vehicle with a 13.8 volt DC

negative ground system

(10.5 volt to 15.5 volt range)

Getting Started

Power-Up Test Sequence/Start-Up Mode

Using the supplied straight or coiled power cord,

place the end with the “elbow” shaped jack into the

receptacle on the side of the detector; the opposite

end of the cord connects to the cigarette barrel. Plug

the cigarette barrel into your vehicle’s cigarette plug, or the

secondary receptacle if your vehicle is so equipped. Press

the PWR button to turn the unit ON. Depending upon the

Operating Mode selected, the power up test sequence and

confirmation of Radar/Laser/SWS™alerts will be relayed to

you as follows:

NNOORRMMAALL(Factory Pre-Set Mode)

A lengthy, power up test sequence that displays audio

and text messages for Laser, Ka, K, X and Safety

Warning System®(SWS™) followed by the status of

the General Selectable Features each time the unit is

turned on. When complete, unit is ready for

operation and will display Radar, Laser and SWS™

messages when signals are detected. Normal Mode

is recommended when first using your VECTOR 990.

MMOODDSS(Modifications Mode)

Presents audio and text messages for Laser, Ka, K, X

and Safety Warning System®(SWS™), followed by

ONLY those General Selectable Features which have

been modified by the user from their Factory pre-set

state each time unit is turned on. Unit is ready for

operation and will display Radar, Laser and SWS™

messages when signals are detected.

QQ--SSTTAARRTT(Quick-Start Mode)

Unit will bypass the power up test sequence and will

display the last selected traveling mode:“

AAuuttooSSccaann™

”

(factory default) “

HHiigghhwwaayy

”, “

CCiittyyXX

” or “

CCiittyy

AALLLL”.

Q-Start is recommended when you are comfortable

with the detector and do not require a rundown of

sample messages. Unit is ready for operation and will

display Radar, Laser and SWS™messages when

signals are detected.

TTEECCHHMODE (Displays Frequency Received)

Presents audio and text messages followed by the

display of the ACTUAL frequency of the received

radar bandwidth and Laser. Unit is ready for

operation and will display Radar, Laser and SWS™

messages – including actual frequencies – when

signals are detected.

Sample alerts while operating in Tech Mode:

Laser Alert: “LLAASSEERR990000NNMM”

X Band Alert: “XXBBAANNDD” followed by “1100..552255”

K Band Alert: “KKBBAANNDD” followed by “2244..115500”

Ka Band Alert: “KKaaBBAANNDD” followed by any

frequency between 3333..44––3366..00GGHHzz.

VV--MMEETTEERR(Voltage Meter Mode)

Presents a continuous, digital readout of your

vehicle’s battery voltage

(10.5 volt to 15.5 volt range)

If voltage rises above 15.5, the display will flash

“HHIIVVOOLLTT” until the problem with your vehicle is

corrected. If voltage falls below 10.5 volts, display

will flash “LLOOWWVVOOLLTT” until the problem with your

vehicle is corrected.

Note: during continuous readout of your vehicle’s battery voltage, you’ll

notice the mode of operation you’re traveling will be illuminated in the

left hand corner of the display in abbreviated form:

Autoscan: AAssHighway: HHCity X: CCxxCity ALL: CCAA

Whichever Operating mode you select, VECTOR 990

will be in standby mode and ready to detect traffic

Radar, Laser and SWS™signals. The display will show

“

AAuuttooSSccaann™

” (factory pre-set which is suitable for ALL

driving conditions, unless you change this to “

HHiigghhwwaayy

”,

“

CCiittyyXX

”, or “

CCiittyy

AALLLL” (see page 9).

TUTORIAL MODE

The Tutorial Mode allows you to become more

familiar with all audible and visual alerts. The

message

“

TTUUTTOORRIIAALL

”

appears in the display followed

by the audio and corresponding Text Message for

“

LLAASSEERR

”

“

KKaaAAUUDDIIOO

”

“

KKAAUUDDIIOO

”

“

XXAAUUDDIIOO

”

, sample

Radar alert (K band signal ramping from weak to

strong) and

“

SSAAFFEETTYYWWAARRNNIINNGGSSYYSSTTEEMMSSAAMMPPLLEEAALLEERRTTSS

”

Three sample SWS™messages are then presented in

the display along with the corresponding

Digital Voice Messages:

Sample 1

“

AACCCCIIDDEENNTTAAHHEEAADD

”

Sample 2

“

HHIIGGHHWWAAYYWWOORRKKCCRREEWWAAHHEEAADD

”

Sample 3

“

PPOOLLIICCEEIINNPPUURRSSUUIITT

”

You can access the complete list of SWS

™

messages

by pressing the AUD button. “MMSSGG11”will appear in the

display once AUD is pressed. Pressing the AUD button

a second time will allow you to listen to the SWS

™

message while viewing it in the display. (to move

forward in the list, press the CTY button; to move

backward in the list, press the DRK button). Continue

the steps above to play all 60 SWS

™

messages.

To exit Tutorial Mode, press the PWR button and

your unit will be on and ready to receive signals.

Note: sample radar and SWS™messages are random.

Presentation of alerts will differ than what is printed based

on operating mode selected. Tutorial Mode will cycle

continuously until PWR is pressed to exit this mode.

Set and Forget Memory

Any time VECTOR 990 is turned off or unplugged

from the cigarette lighter socket, all feature settings

you have selected are retained in the unit’s memory.

Set and Forget Memory eliminates the need to reset

your preferred feature settings each time your unit is

turned off and then back on.

Reset to Factory Settings

You can reset your unit to factory settings (North

American Mode) for Start-Up mode, volume, DRK, AUD,

CTY and General Selectable Features. To reset, press

and hold the CTY button with the unit on until the

display shows “RREESSEETT“.Two“beeps” will sound and your

unit will cycle through the NNOORRMMAALLStart-Up Mode.

DRK (Bright/Dim/Dark) Button

The DRK button allows selection of a bright, fully

adjustable dim or dark mode. VECTOR 990 is

factory preset to full bright display. To engage dim

mode, press and hold the DRK button. The display

will cycle through various levels of dim illumination.

Release the button at your chosen level. To engage

dark mode, press the DRK button a second time.

A single “beep” coupled with the brief illumination

“

DDAARRKK

”

on the display confirms your selection.

You’ll notice an

“

AAss

”

(AutoScan™),

“

”

(Highway

mode),

“

CCxx

”

(City mode) or

“

CCAA

”

(City ALL)

remains dim to confirm your unit is receiving power.

To return to a full bright setting, press the DRK

button a third time; two “beeps” confirm this

selection. Use of the DRK button does not affect

audio alerts.

Important—if you press the the DRK button and do not

receive audible confirmation, the audio level has been set

too low.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Detector de radar de Beltronics

Beltronics

Beltronics V960/V940 Manual de usuario

Beltronics

Beltronics STiR Plus Manual de usuario

Beltronics

Beltronics STi Driver - STi Driver Radar Detector Manual de usuario

Beltronics

Beltronics Vector V8 Manual de usuario

Beltronics

Beltronics Vector V10 Manual de usuario

Beltronics

Beltronics Professional GX65 Manual de usuario

Beltronics

Beltronics Shifter ZR4 Manual de usuario

Beltronics

Beltronics STi Magnum Professional Series Manual de usuario

Beltronics

Beltronics STiR Plus Manual de usuario

Beltronics

Beltronics Ultimate Pro 300 Manual de usuario

Beltronics

Beltronics RX45 Manual de usuario

Beltronics

Beltronics Vector 955 Manual de usuario

Beltronics

Beltronics V965 Manual de usuario

Beltronics

Beltronics V895 Manual de usuario

Beltronics

Beltronics RX75PLUS - RX-75 PLUS Radar Detector Manual de usuario

Beltronics

Beltronics Express 925 Manual de usuario

Beltronics

Beltronics Vector 970 Manual de usuario

Beltronics

Beltronics RX 65 Manual de usuario

Beltronics

Beltronics Bel STi Manual de usuario

Beltronics

Beltronics Sti-R Manual de usuario

Beltronics

Beltronics 906 Manual de usuario

Beltronics

Beltronics Ultimate Pro 100 Manual de usuario

Beltronics

Beltronics LaserPro 905 Manual de usuario

Beltronics

Beltronics RX65 - Radar Manual de usuario

Manuales populares de Detector de radar de otras marcas

Cobra

Cobra XRS 9700 Manual de usuario

Inforad

Inforad v3 Manual de usuario

Cobra

Cobra ESD9200 Instrucciones de funcionamiento

Escort

Escort C65 Manual de usuario

Cobra

Cobra SPX 7800BT Manual de usuario

Escort

Escort max 360c Manual de usuario

Cobra

Cobra XRS 9940 Manual de usuario

Lowrance

Lowrance LRA-2400 Manual de usuario

Cobra

Cobra ESD-9160 Manual de usuario

Whistler

Whistler CR80 Manual de usuario

Stinger

Stinger VIP Manual de usuario

Cobra

Cobra XRS 9430 Manual de usuario

Cobra

Cobra Pro 9680 Manual de funcionamiento

Escort

Escort SmartRadar Manual de usuario

Whistler

Whistler 1655 Manual de usuario

Radenso

Radenso Pro M-Edition Manual de usuario

Rocky Mountain

Rocky Mountain RMR-D250 Manual de usuario

Cobra

Cobra XRS 9645 Manual de usuario
