Beko HCA62640B Manual de usuario

HCA62640B - HCA62640W

EN - ES - BS - MK - PT - RO - RU - SK - SL - SQ - SR- UA

01M-8848063200-0722-08

01M-8848053200-0722-08

User Manual

Cooker Hood

2 / EN Cooker Hood / User Manual

ENGLISH 3-16

ESPAÑOL 17-32

BOSANSKI 33-46

МАКЕДОНСКИ 47-65

PORTUGUÊS 66-81

ROMÂNĂ 82-97

РУССКИЙ 98-119

SLOVENSKÝ 120-133

SLOVENŠČINA 134-147

SHQIPTARE 148-161

СРПСКИ 162-179

УКРАЇНСЬКА 180-198

CONTENTS

Please read this user manual first!

Dear Valued Customer,

Thank you for preferring this Beko appliance. We hope that you get the best results

from your appliance which has been manufactured with high quality and state-of-

the-art technology. For this reason, please read this entire user manual and all other

accompanying documents carefully before using the appliance and keep it as a

reference for future use. If you handover the appliance to someone else, give the user

manual as well. Follow the instructions by paying attention to all the information and

warnings in the user manual.

Remember that this user manual may also apply to other models. Differences between

models are explicitly described in the manual.

Meanings of the Symbols

Following symbols are used in various sections of this user manual:

CImportant information and useful hints about

usage.

AWARNING: Warnings against dangerous situa-

tions concerning the security of life and property.

WARNING: Warning for danger of fire.

BWARNING: Warning for electric shock.

This appliance has been produced in environmentally friendly facilities without harming the nature.

4 / EN Cooker Hood / User Manual

1.1 General Safety

Important Safety Instructions

Read Carefully And Keep For

Future Reference This section

contains safety instructions that

will help protect from risk of fire,

electric shock, exposure to leak

microwave energy, personal inju-

ry or property damage. Failure to

follow these instructions shall void

any warranty.

•Beko products comply with the

applicable safety standards;

therefore, in case of any damage

on the appliance or power cable,

it should be repaired or replaced

by the dealer, service center or a

specialist and authorized service

alike to avoid any danger. Faulty

or unqualified repair work may

be dangerous and cause risk to

the user.

•This appliance is intended to be

used in household and similar

applications such as:

– Staff kitchen areas in shops,

offices and other working en-

vironments;

– Farm houses

– By clients in hotels, and other

residential type environments;

– Bed and Breakfast type envi-

ronments.

•Operate the appliance for its

intended purpose only as de-

scribed in this manual.

•The manufacturer cannot be

held liable for damages result-

ing from improper installation or

misuse of the product.

•This appliance can be used by

children aged from 8 years and

above and persons with reduced

physical, sensory or mental ca-

pabilities or lack of experience

and knowledge if they have been

given supervision or instruction

concerning use of the appliance

in a safe way and understand

the hazards involved.

•Children shall not be allowed

play with the appliance. Clean-

ing and user maintenance shall

not be made by children without

supervision.

Important safety and environmental instructions

Cooker Hood / User Manual 5 / EN

•The minimum distance between

the supporting surface for the

cooking vessels on the hob and

the lowest part of your product

must be at least 65 cm.

•If the instructions for installation

for the gas hob specify a greater

distance, this has to be taken

into account.

•Make sure that your mains

power supply complies with the

information supplied on the rat-

ing plate of the appliance.

•Never use the appliance if the

power cable or the appliance it-

self is damaged.

•Prevent damage to the power

cable by not squeezing, bending,

or rubbing it on sharp edges.

Keep the power cable away from

hot surfaces and naked flame.

•Use the appliance with a

grounded outlet only.

WARNING: Do not connect the

appliance to the mains until the

installation is fully complete.

•Place the appliance in a way so

that the plug is always accessi-

ble.

•Do not touch the lamps if they

have operated for a long time.

They can burn your hands since

they will be hot.

•Follow the regulations set out by

competent authorities on dis-

charge of the exhaust air (this

warning is not applicable for use

without flue).

•Operate your appliance after

putting a pot, pan etc. on the

hob. Otherwise, high heat may

cause deformation in some parts

of your product.

•Turn off the hob before taking

the pot, pan etc. from it.

•Do not leave hot oil on the hob.

Pans with hot oil may cause self

combustion.

•Pay attention to your curtains

and covers since oil may catch

fire while cooking food such as

fries.

•Grease filter must be cleaned

at least monthly. Carbon filter

must be replaced at least every

3 months.

Important safety and environmental instructions

6 / EN Cooker Hood / User Manual

•Product shall be cleaned ac-

cordance with user manual. If

cleaning was not carried out in

accordance with user manual,

there may be fire risk.

•Do not use non-fire-resistant

filtering materials instead of the

current filter.

•Only use the original parts or

parts recommended by the

manufacturer.

•Do not operate the product with-

out the filter and do not remove

the filters while the product is

running.

•In the event of be started any

flame, de-energize your product

and cooking appliances.

•In the event of be started any

flame, cover the flame and never

use water to extinguish.

•Unplug the appliance before

each cleaning and when the ap-

pliance is not in use.

•The negative pressure in the en-

vironment should not exceed 4

Pa (4x10 bar) while the hood for

electric hob and appliances run-

ning on another type of energy but

electricity operate simultaneously.

•In the environment where the

appliance is being used, the ex-

haust of devices running on fuel

oil or gas, such as room heater

must be absolutely isolated or

device must be hermetical type.

•When connecting the flue, use

pipes with a diameter of 120 or

150 mm. Pipe connection must

be as short as possible and have

as few elbows as possible.

Danger of choking! Keep all the

packaging materials away from

children.

CAUTION: Accessible parts may

become hot when used with

cooking appliances.

•The product outlet must not be

connected to air channels that

include other smoke.

•The ventilation in the room may

be insufficient when the hood for

electric hob is used simultane-

ously with the devices operating

on gas or other fuels (this may

not apply to appliances that only

discharge the air back into the

room).

Important safety and environmental instructions

Cooker Hood / User Manual 7 / EN

Important safety and environmental instructions

•Objects placed on the product

may fall. Do not place any ob-

jects on the product.

•Do not flambe under the your

product.

WARNING: Before installing the

Hood, remove the protective films.

•Never leave high naked flames

under the hood when it is in op-

eration

•Deep fat fryers must be contin-

uously monitored during use:

overheated oil can burst into

flames.

1.2 Compliance with the WEEE

Directive and Disposing of the Waste

Product:

This product complies with EU WEEE Directive

(2012/19/EU). This product bears a classification

symbol for waste electrical and electronic equip-

ment (WEEE).

This symbol indicates that this product

shall not be disposed with other

household wastes at the end of its ser-

vice life. Used device must be returned

to offical collection point for recycling

of electrical and electronic devices. To find these

collection systems please contact to your local au-

thorities or retailer where the product was pu-

chased. Each household performs important role

in recovering and recycling of old appliance.

Appropriate disposal of used appliance helps pre-

vent potential negative consequences for the envi-

ronment and human health.

1.3 Compliance with RoHS Directive

The product you have purchased complies with EU

RoHS Directive (2011/65/EU). It does not contain

harmful and prohibited materials specified in the

Directive.

1.4 Package Information

Packaging materials of the product are

manufactured from recyclable materials

in accordance with our National

Environment Regulations. Do not dis-

pose of the packaging materials together with the

domestic or other wastes. Take them to the pack-

aging material collection points designated by the

local authorities.

8 / EN Cooker Hood / User Manual

General appearance

2.1 Overview

596

366

391

350

400

Min:750 Max:1080

395

330

213

166.5

3421.6.595.13

1. Inner chimney

2. Outer chimney

3. Body

4. Grease filter (Behind Glass Cover)

5. Control panel

6. Lighting

2.2 Technical data

Model HCA62640B HCA62640W

Supply voltage & frequency 220-240V ~ 50 Hz

Lamp power 2x3 W

Motor power 210 W

Flow rate – 3. Level 582 m³/h

Insulation class of motor Class F

Insulation class Class I

(Figure 1)

Cooker Hood / User Manual 9 / EN

Operation of the appliance

3.1 Controlling the appliance

KEY FUNCTION

A : Light On / Off You may illuminate the cooking area by pressing this button. Re-press the button

to turn off the lamp.

B : 1. Stage Button Operates the appliance on 1st speed. When you press this button again to turn off

the appliance, the screen speed stage turns off.

C : 2. Stage Button Operates the appliance on 2nd speed. When you press this button again to turn off

the appliance, the screen speed stage turns off.

D : 3. Stage Button Operates the appliance on 3rd speed. When you press this button again to turn off

the appliance, the screen speed stage turns off.

3.2 Efficient use in terms of energy saving

•When using your appliance, adjust the speed settings according to vapour and odour intensity, in

order to save energy.

•Use low speeds (1-2) under normal conditions, and high speed (3) for intense odour and vapour.

•The lamps on the hood are placed for illuminating the cooking area.

•Using them for environmental lighting shall cause unnecessary energy expenditure and insufficient

lighting.

3.3 Operation of the hood

•Your appliance contains a motor that has various speeds.

•For better performance, we recommend using low speeds under normal conditions and high speeds

in cases of strong odours and intense vapour.

•You can start your appliance by pressing on the desired speed setting button. (B,C,D)

•You can illuminate the cooking area by pressing the lamp. (A)

3.4 Automatic stop

Your appliance has Automatic Stop feature, enabling it to ventilate for a bit more and remove the un-

wanted odours and vapour inside the environment and turn off automatically after the cooking is done.

To enable Automatic Stop feature, press the any speed stage button (B, C, D) on the control panel for

longer than 2 seconds; the 15-minute timer function shall be activated.When the automatic stop feature

is active, pressing the same speed button shall disable the automatic stop function and the appliance's

motor shall stop. This feature is disables when you switch between different speed stages.

10 / EN Cooker Hood / User Manual

3 Operation of the appliance

If you want the appliance to stop automatically, you

need to enable the automatic stop feature again.

3.5 Replacement of lamp

MAX 3 W

(Figure 3)

Make the electrical connections of the appliance.

Your appliance uses 3W spot LED lamp. For re-

placing the lamps, push downwards on the holder

from its behind, turn it counter-clockwise, and take

it out downwards. Apply the above operation in re-

verse to install new lamps.

Bulb

Bulb power 3 W

Holder / Socket GZ 10

Bulb voltage 220 - 240 V

Size 53x50 mm

ILCOS Code DR/F3-220-240-GZ10-50-53

Luminous flux 260 lm

Correlated colour

temperature

3000 K

This product contains a light source of energy ef-

ficiency class “F”.

3.6 Operation with flue connection

•Vapour is extracted through the

flue duct, which is fastened to

the connection head on the

hood.

•The diameter of the flue duct must be the same

as the connection ring. In horizontal settings, the

pipe has to have a slight upward slope (around

10º) so that the air can exit the room easily.

3.7 Operation without flue

connection

•Air is filtered through the carbon

filter and recirculated in the

room. Carbon filter is used

when it is impossible to use a

flue in the house.

•In flueless use, remove the flaps inside the flue

adapter.

•Remove the grease filter. To install the carbon

filter, fit the filter to the tabs by centring it on

the plastic piece on both sides of the fan body.

Tighten it by turning right or left.

•Replace grease filter.

Otros manuales para HCA62640B

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Campana de ventilación de Beko

Beko

Beko HCA62541W Manual de usuario

Beko

Beko BHCB66641BBBHS Manual de usuario

Beko

Beko BHCA63741BHSI Manual de usuario

Beko

Beko CTB 6250 W Manual de usuario

Beko

Beko BHCA66341BBH Manual de usuario

Beko

Beko CWB 6403 X Manual de usuario

Beko

Beko CTB 6250 W Manual de usuario

Beko

Beko BHCB63640B Manual de usuario

Beko

Beko ADV 5400 I Guía del usuario

Beko

Beko BHCA66641BBHS Manual de usuario

Beko

Beko CCB 5140 XA Manual de usuario

Beko

Beko CTB 6250 W Manual de usuario

Beko

Beko CTB 9407 Manual de usuario

Beko

Beko HNT61110X Manual de usuario

Beko

Beko CFB 5432 W Manual de usuario

Beko

Beko CWB 6430 X Manual de usuario

Beko

Beko BHCA62422BBH Manual de usuario

Beko

Beko 01M-8852733200-0120-02 Manual de usuario

Beko

Beko CTB 6250 W Manual de usuario

Beko

Beko BHCA 64640 B Manual de usuario

Beko

Beko HCA93640SS Manual de usuario

Beko

Beko HNE51210S Manual de usuario

Beko

Beko HNT 62210 B Manual de usuario

Beko

Beko BHCA66641BFBHS Manual de usuario

Manuales populares de Campana de ventilación de otras marcas

emmeti

emmeti RECUPA MED A-140 Guía

Nibe

Nibe F135 Manual de usuario

Kuppersberg

Kuppersberg INTRO 60 Instrucciones de instalación y mantenimiento

Zephyr

Zephyr Spruce AK9834BS Guía de instalación

Hisense

Hisense MH6INBG Manual de usuario

Miele

Miele DA 1255 Manual de usuario

Broan

Broan 46000 Manual de usuario

GE Profile PV977 Instrucciones originales

FALMEC

FALMEC FFRIA24W5FS Manual de usuario

Whirlpool

Whirlpool RH2600XL-1 SERIES Manual de usuario

Küppersbusch

Küppersbusch DX ISLA Manual de usuario

ETNA

ETNA AV360RVS Manual de usuario

JUNO

JUNO JDF603E6 Manual de usuario

Miele

Miele DA 6708 D Manual de usuario

Tricity Bendix

Tricity Bendix LE 150 Manual

AEG

AEG X68163BV1 Manual de usuario

AEG

AEG 125 D Manual de usuario

Smeg

Smeg KSEV97X Manual de usuario
