Beijer Electronics IFC MC Manual de usuario
IFC MC
Manual
MA00281D 2002-12 English, Svenska
Foreword
Beijer Electronics AB, MA00281D
Manual IFC MC
Foreword
This manual describes the installation and functions of the memory expansion
card IFC MC.
The expansion card is used to connect a PCMCIA flash memory card to
operator terminals with expansion slots.
IFC MC supports the flash memory cards 4MB (SM9AMD4M002) and
8 MB (SM9AMD8M002) from SMART Modular Technologies.
For information about the flash memory card, please contact the dealer.
Besides this manual, the manual for the operator terminals and the
programming tool for the operator terminals is also available.
Beijer Electronics AB, MA00281D, 2002-12
Please read the entire installation manual prior to installing and using this equipment.
Only qualified personnel may install, operate or repair this equipment. Beijer Electronics AB is not
responsible for modified, altered or renovated equipment.
Because the equipment has a wide range of applications, users must acquire the appropriate knowledge to
use the equipment properly in their specific applications.
Only parts and accessories manufactured according to specifications set by Beijer Electronics AB may be
used.
BEIJER ELECTRONICS AB SHALL NOT BE LIABLE TO ANYONE FOR ANY DIRECT,
INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM
THE INSTALLATION, USE OR REPAIR OF THIS EQUIPMENT, WHETHER ARISING IN
TORT, CONTRACT, OR OTHERWISE. BUYER’S SOLE REMEDY SHALL BE THE REPAIR,
REPLACEMENT, OR REFUND OF PURCHASE PRICE, AND THE CHOICE OF THE
APPLICABLE REMEDY SHALL BE AT THE SOLE DISCRETION OF BEIJER ELECTRONICS AB.
Foreword
Beijer Electronics AB, MA00281D
Please fill this form out with any suggestions regarding the manual.
This page, or a copy of it, can be sent to us at the addresses below.
Name ....................................................................................
Company....................................................................................
Address ....................................................................................
City, Zip code.............................................................................
Country ....................................................................................
Telephone...............................Fax...............................................
E-mail ....................................................................................
Please fax this page to the Marketing Department,
Beijer lectronics AB at +46-40-93 23 01,
or send it by conventional mail to
The Marketing Department, Beijer lectronics AB
Box 426, S -201 24 MALMÖ, Sweden.
Comments can also be sent to manual@beijer.se.
Comments regarding MA00281D Page
Safety precautions
Beijer Electronics AB, MA00281D
afety precautions
General
–Read the safety precautions carefully.
–Check the delivery for transportation damage. If damage is found, notify the
supplier as soon as possible.
–The product fulfills the requirements of article 4 of EMC directive
89/336/EEC.
–Do not use the product in an environment with high explosive hazards.
–The supplier is not responsible for modified, altered or reconstructed
equipment.
–Use only parts and accessories manufactured according to specifications of
the supplier.
–Read the installation and operating instructions carefully before using the
product.
–Only qualified personnel may operate the equipment.
During installation
–The product is designed for stationary installation on a plane surface.
–Install the product according to the accompanying installation instructions.
–Ground the product according to the accompanying installation instructions.
–Only qualified personnel may install the product.
–Do not install the product in direct sunlight.
During use
–Keep the equipment clean.
–Emergency stop and other safety functions should not be controlled from the
terminal.
Safety precautions
Beijer Electronics AB, MA00281D
ervice and maintenance
–The agreed warranty applies.
–Repairs should be made by qualified personnel.
At disassembly and scrapping
–Local regulations apply concerning recycling of products or parts.
–The following components contain substances that might be hazardous to
health and the environment: electrolytic capacitors.
Contents
Beijer Electronics AB, MA00281D
Contents
1Installation................................................................................................7
1.1 Installation of one expansion card................................................7
1.2 Installation of two expansion cards...............................................9
2 Settings in the programming tool...........................................................11
2.1 Define slot .................................................................................11
2.2 Transfer the settings...................................................................14
3 Functions of the memory card................................................................15
3.1 Backup.......................................................................................15
3.2 Memory expansion ....................................................................17
Installation
Beijer Electronics AB, MA00281D 7
1 Installation
The system program (operating system/firmware) in the operator terminals
must be of the same version if IFC MC is used as a backup card to copy projects
or files between different terminals.
For information about making the operator terminal autoload from the memory
card, see section Autoloading terminal projects from memory card in chapter 3.1.
The memory card can only be read and written to by the terminal, and not by a
personal computer.
This chapter describes how to mount the memory card in the terminal.
1.1 Installation of one expansion card
Perform the following steps to mount the IFC MC expansion card:
1. Switch the terminal power off.
2. Make sure that the ESD protection is good.
3. Remove the cover plate on the rear of the terminal, and the two expansion
plates on the short side. In terminals equipped with two expansion slots, the
slots are called Slot 1 and Slot 2. In terminals with one expansion slot, it is
called Slot 1.
Slot 1
Slot 2
Installation
8Beijer Electronics AB, MA00281D
4. Put the jumper J1 on the expansion card in the position SLOT 1 if the
expansion card is mounted in Slot 1, and in position SLOT 2 if the card is
mounted in Slot 2.
5. Mount the expansion cables with the components of the expansion card
placed upwards. One of the expansion cables is mounted between X1 on the
CPU card and X1 on the expansion card, and the other cable between X2
on the CPU card and X2 on the expansion card.
6. Fasten the card with the spacers or the screws. Use the screws if the expan-
sion card is mounted in Slot 1, and the spacers if the card is mounted in
Slot 2.
7. Check that the expansion cable is correctly mounted.
8. Mount the cover plates.
Note!
To use the memory card for autoload of a terminal project, it has to be mounted
in Slot 1.
J1
X1
X1
X2
X2
Installation
Beijer Electronics AB, MA00281D 9
1.2 Installation of two expansion cards
Two expansion cards can be mounted in some terminals. They are mounted in
parallel to the connector on the CPU card in the terminal. Two expansion cards
can be connected via one expansion cable since there is a parallel contact on the
cable. The connector in the middle is used for the expansion card placed in
Slot 1 and the end connector is used for the expansion card placed in Slot 2. If
only one card is used either connector can be used.
The connector X1 on the expansion card in Slot 2 is connected to the connector
X1 and the CPU card in the terminal via the X1 connector on the expansion
card in Slot 1. If the X2 connector on the CPU card in the terminal is used by
any or both cards, this connector is connected to the X2 connector on the
expansion card.
When two expansion cards are mounted in the same terminal the card in Slot 1
is mounted with the distances and the card in Slot 2 with the screws in the dis-
tances.
Note!
Only one IFC MC can be used in the terminal.
To use the memory card for autoload of a terminal project, it has to be mounted
in Slot 1.
X1
X2
X1
X1
Card in
Slot 2
Card in
Slot 1
X2
Installation
10 Beijer Electronics AB, MA00281D
