Becken BSF2771 Manual de usuario
Stand fan | Ventilador de pie | Ventoinha de pé
AF Manual VENTOINHA PÉ BSF2771 A5 EN.indd 1 31/03/17 18:45
Dear client,
Thank you for purchasing this product.
The quality of this appliance has been certied by several
laboratory tests. This instructions manual is provided to
simplify the use of the appliance as well as to guarantee a
safe use.
Please read carefully the instructions and safety measures
described in this manual.
We sincerely hope you will be satised when using your new
appliance.
AF Manual VENTOINHA PÉ BSF2771 A5 EN.indd 2 31/03/17 18:45
3
EN
Stand fan | Ventilador de pie | Ventoinha de pé
INDEX
1. SAFETY INSTRUCTIONS 4
1.1. Power Supply 5
1.2. Power Cord and Other Cables 5
1.3. Humidity and Water 5
1.4. Cleaning 5
1.5. General Precautions 6
2. OPERATING INSTRUCTIONS 6
2.1. Product Description 8
2.2. Using the Product 9
2.3. Maintenance 11
2.4. Troubleshooting 12
3. TECHNICAL SPECIFICATIONS 12
4. POST-SALE SERVICE 13
5. ENVIRONMENTAL PROTECTION 13
AF Manual VENTOINHA PÉ BSF2771 A5 EN.indd 3 31/03/17 18:45
4
1. SAFETY INSTRUCTIONS
Important Warnings
Before using your appliance read this instructions manual carefully and
keep it in a safe place as you may need to consult it in the future.
Before turning on your appliance, and to ensure a safe and correct
operation, do not use if:
• It has fallen to the ground;
• You notice any evidence of damage;
• Any anomaly occurs during its operation.
To avoid hazards or deterioration of your appliance through incorrect
use it is advisable to read these instructions thoroughly.
Your appliance may not be used for other purposes than the ones
intended and solely for household use. Any damage resulting from
using the appliance outside this scope, any incorrect use, as well as
any manual modications to the product will not be covered and
automatically voids the warranty.
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Warning: to avoid the risk of electric shock, do not
remove the cover. The interior does not contain any parts
that can be repaired by the user. Ask for assistance from
qualied personnel.
AF Manual VENTOINHA PÉ BSF2771 A5 EN.indd 4 31/03/17 18:45
5
EN
Stand fan | Ventilador de pie | Ventoinha de pé
Assistance
In case of malfunction, take your appliance to a qualied technician for
assistance.
This appliance can be used by children from the age of 8 and by
people with reduced physical, sensorial or mental capabilities and/or
lack of experience and knowledge if they have been given instructions
on using the appliance safely and if they understand the hazards
involved. Children may not play with the appliance. Cleaning and
maintenance must not be carried out by children without supervision.
These instructions are also available at www.suporteworten.pt
1.1. Power Supply
Make sure the main voltage is compatible with the appliance’s. If this is
not the case, please consult the Customer Support Service.
1.2. Power Cord and Other Cables
Do not tangle the cord or pull it to disconnect the appliance. Also, keep
the cord away from warm surfaces.
Never use the appliance if it has a damaged cable or socket.
Take it to the Technical Support Service for replacement.
1.3. Humidity and Water
Do not use your appliance in humid places. Do not allow the appliance
to become wet under any circumstances as this may be dangerous.
To avoid re hazard or electric shock do not expose your appliance
to humidity or water. Furthermore, do not place your appliance under
water (e.g. for cleaning).
1.4. Cleaning
Before cleaning, be sure to switch o the appliance and remove the plug
from the main power supply. Always allow the unit to cool down before
cleaning.
To clean the exterior of the product use a dry soft cloth only.
AF Manual VENTOINHA PÉ BSF2771 A5 EN.indd 5 31/03/17 18:45
6
1.5. General Precautions
• Please follow the instructions in the user manual which help to
properly install and operate this product and enjoy its advanced
features. Please keep the instructions for future reference.
• Read all instructions before using the product.
• Maintenance and service operations are only to be carried out by
authorized professionals.
• Any damage caused by manual modications to the product is not
covered by the warranty.
• If this product is used for other purposes than the ones originally
intended, or if it is not correctly connected, the product may become
damaged and the warranty will be voided.
2. OPERATING INSTRUCTIONS
• Read this instruction manual carefully before using this appliance.
• Keep this instruction manual in a safe place.
• Ensure the voltage of your electrical installation corresponds to that
indicated on the appliance.
• Disconnect the appliance from the power supply when not in use.
• Do not use any appliance with a damaged cord or plug, or after any
malfunction or damage.
• If the power cord is damaged it must be replaced by the
manufacturer, its after-sales service or a qualied technician.
• Always disconnect from the socket before cleaning.
• Never move the device by pulling the power cord.
• Ensure there is no risk of the power cord becoming entangled.
AF Manual VENTOINHA PÉ BSF2771 A5 EN.indd 6 31/03/17 18:45
7
EN
Stand fan | Ventilador de pie | Ventoinha de pé
• Do not wrap the power cord around the appliance and do not bend it.
• Always use the product on a at and stable surface.
• Never use the appliance in damp places, such as the bathroom.
• Never allow children to use the fan without supervision.
• Store the remote control out of the reach of children.
• Never cover the grill while the appliance is switched on.
• Never allow the fan to get wet or permit any type of liquid to enter
the motor or the control panel.
• Place the fan on a at, stable surface to ensure it does not fall.
• Make sure your fan is fully assembled before use.
• Never place your ngers, pencils, or other objects in the grill, whether
the fan is switched on or not.
• Disconnect the fan from the mains socket when it is not in use or
when moving or cleaning it. Do not disconnect from the socket by
pulling on the power cord.
• This appliance is intended for domestic use only.
AF Manual VENTOINHA PÉ BSF2771 A5 EN.indd 7 31/03/17 18:45
8
2.1. Product Description
1- Front grill
2- Small fan blade
3- Large fan blade
4- Plastic nut
5- Rear grill
6- Motor shaft
7- Motor housing
8- Fan housing
9- Screw
10 - Vertical adjustment screw
11 - Vertical support
12 - Base
13 - Screw
AF Manual VENTOINHA PÉ BSF2771 A5 EN.indd 8 31/03/17 18:45
9
EN
Stand fan | Ventilador de pie | Ventoinha de pé
2.2. Using the Product
Assembly
• The appliance must be fully assembled before use.
• Place the vertical support into the base and tighten the screw in the
lower part of the base.
• Loosen o the vertical adjustment screw and pull the extendable
handle to adjust the fan until it is at the desired height then tighten
the screw.
• Insert the fan housing into the extendable handle and tighten the
screw.
• Insert the rear grill through the motor shaft, ensuring the plastic pins
on the grill snap into the holes in the motor housing.
• Secure the grill in place by turning the plastic nut clockwise.
• Insert the large fan blade into the motor shaft, then insert the small
fan blade in an anti-clockwise direction.
• Fix the front grill to the rear grill and close using the xing hook.
• Adjust the angle of the fan before switching it on.
Remote control
• Insert two batteries (1.5A AAA type) into the remote control and
close the battery cover by clicking it into place.
• Ensure there are no objects in the way that can obstruct the signal.
• Remove the batteries from the remote control if you do not use it for
an extended period of time (four or more weeks).
AF Manual VENTOINHA PÉ BSF2771 A5 EN.indd 9 31/03/17 18:45
10
Operation
• Place the fan on a at and stable surface. Ensure the fan is in a
secure position so that it cannot tip over or fall.
• Connect the appliance to an electrical socket that is in a good
condition. Ensure the mains voltage is compatible with that shown
on the appliance.
• To start the appliance, press the control panel button or use the
remote control.
• The fan can operate the following speed:
1 2 3 4 5 6 1
• To adjust the speed of the fan, press the Speed button on the fan
control panel or the +/- button on the remote control.
• Press the button marked OSC on the control panel or remote control
to make the fan rotate. Press this button again to stop rotation.
• This fan has a Timer function. Using this function enables the fan
to switch o automatically at the end of a set time. The set time can
vary from 1 to 15 hours. To set the time, repeatedly press the button
on the control panel or on the remote control. The selected number
of hours is displayed by the pilot light corresponding to the set time.
To deactivate the timer function, press the timer button until the
corresponding indicator switches o.
• The fan has a NATURAL mode. This mode alternates the speed
of the fan from minimum to maximum speed. To select this mode,
press the button marked Mode on the control panel or on the
remote control until the corresponding pilot light appears.
• The fan has a BREEZE mode. This mode consists of maintaining
a lower air ow that reduces the noise of the fan.
AF Manual VENTOINHA PÉ BSF2771 A5 EN.indd 10 31/03/17 18:45
