Children’s Wooden Dollhouse
SKY 1797
ASSEMBLY MANUAL
NOTICE
Thank you very much for choosing Best Choice Products! Please read
the installation instructions carefully before installing.
- Firmly secure all screws before use.
- Product is intended for indoor use only.
- Retain these instructions for future reference.
The parts and hardware below have been included for assembly:
NOTE: Philips head screwdriver needed for assembly
1bestchoiceproducts.com
1 PERSON
ASSEMBLY 45 MIN
ASSEMBLY
17
8
9
10
11
2
3
4
5
6
12
13
18
19
14 16
17
15
20 22
23
24
21
x1 x1
x1 x2
x13
x31
x4
x2
x2
x1
x2
x1 x1
x1 x2
x1
x1
x1 x1
x1 x1
x1
x1
x2
x2
x1
x1
x1
x1
A
B
C
D2
D1
STEP 1: Attach the part 1, 2, 3, 4, and 5 supports
to the part 12 wall with five part B screws.
STEP 3: Slide the part 20 floor piece into the part
3 support to form the third floor. Secure part 20
with the part 6 support. Attach the part 6 support
to the wall with a part B screw.
STEP 2: Slide two part 16 wall pieces between the
longer supports to form the back wall of the doll
house. Slide the part 18 floor piece between the
supports to form the first floor. Slide the part 19
floor piece between the supports to form the sec-
ond floor. Attach the part 13 wall to the side of the
doll house with four part B screws.
STEP 4: Use the part 24 wall to separate the first
floor into two rooms. Secure the wall with four part
B screws, two on each side.
2
bestchoiceproducts.com
STEP 5: Attach the part 10 railing to part 9 with a
part A screw. Repeat this to build another railing.
STEP 7: Place a part 11 support beneath the stair-
well railing between the first and second floor and
secure it with a part A screw and a part B screw.
Repeat this to attach another part 11 support be-
neath the stairwell railing between the second and
third floor.
STEP 6: Place the two railings on the second floor
and third floor. Attach the part 7 railing to the doll
house between the first and second floor with
three part A screws. Repeat this to attach the part
8 railing to the doll house between the second and
third floor.
STEP 8: Secure the stairwell railings with two part
A screws on the rear of the doll house.
A
9
7
8
10
3bestchoiceproducts.com
STEP 9: Attach the part 14 wall addition to the
left wall with two part D2 screws and two part
D1 bolts. Insert two part C dowels into a part 23
wall piece, one on each side. Repeat this for the
other part 23 wall piece. Attach the two part 23
wall pieces to the third floor wall with two part B
screws.
STEP 11: Form the roof the doll house with the
part 21 roof support and two part 22 roof pieces.
Secure the roof to the doll house with ten part B
screws.
STEP 10: Secure the part 15 doorway to the part
23 wall pieces with three part B screws and one
part A screw. Slide the part 17 back wall between
the wall pieces on the third floor.
STEP 12: The Children’s Wooden Dollhouse is
complete.
4
bestchoiceproducts.com
Email us, we’re here 7 days a week to help you!
customerservice@bestchoiceproducts.com
WARNING
Manufacturer and seller expressly disclaim any and all liability for personal injury, property
damage or loss, whether direct, indirect, or incidental, resulting from the incorrect
attachment, improper use, inadequate maintenance, or neglect of this product.
