BCM RX61H Manual de usuario

RX61H

Intel® H61 Micro ATX Motherboard (mATX) supports 2nd/3rd Generation

Intel® Core™ i7/i5/i3 Processors (Sandy Bridge/Ivy Bridge Processors)

User’s Manual Ver 1.0

RX61H User’s Manual

2 RX61H User’s Manual

Safety Information

Electrical safety

To prevent electrical shock hazard, disconnect the power cable from the electrical outlet

before relocating the system.

When adding or removing devices to or from the system, ensure that the power cables

for the devices are unplugged before the signal cables are connected. If possible,

disconnect all power cables from the existing system before you add a device.

Before connecting or removing signal cables from the motherboard, ensure that all

power cables are unplugged.

Seek professional assistance before using an adapter or extension cord. These devices

could interrupt the grounding circuit.

Make sure that your power supply is set to the correct voltage in your area. If you are not

sure about the voltage of the electrical outlet you are using, contact your local power

company.

If the power supply is broken, do not try to fix it by yourself. Contact a qualified service

technician or your retailer.

Operation safety

Before installing the motherboard and adding devices on it, carefully read all the manuals

that came with the package.

Before using the product, make sure all cables are correctly connected and the power

cables are not damaged. If you detect any damage, contact your dealer immediately.

To avoid short circuits, keep paper clips, screws, and staples away from connectors,

slots, sockets and circuitry.

Avoid dust, humidity, and temperature extremes. Do not place the product in any area

where it may become wet.

Place the product on a stable surface.

If you encounter technical problems with the product, contact a qualified service

technician or your retailer.

The symbol of the crossed out wheeled bin indicates that the product

(electrical and electronic equipment) should not be placed in

municipal waste. Check local regulations for disposal of electronic

products.

RX61H User’s Manual

Safety Declaration

This device complies with the requirements in Part 15 of the FCC rules. Operation is subject

to the following two conditions:

This device may not cause harmful interference.

This device must accept any interference received, including interference that may

cause undesired operation.

RX61H User’s Manual

4 RX61H User’s Manual

About this guide

This user guide contains the information you need when installing and configuring the

motherboard.

How this guide is organized

This manual contains the following parts:

Chapter 1: Product introduction

This chapter describes the features of the motherboard and the new technology it

supports. This chapter also lists the hardware setup procedures that you have to

perform when installing system components. It includes description of the jumpers and

connectors on the motherboard.

Chapter 2: BIOS setup

This chapter tells how to change system settings through the BIOS Setup menus.

Detailed descriptions of the BIOS parameters are also provided.

Where to find more information

Refer to the following sources for additional information and for product and software

updates.

1. Technical Support

If a problem arises with your system and no solution can be obtained from the user’s manual,

please contact your place of purchase or local distributor.

2. Optional documentation

Your product package may include optional documentation, such as warranty flyers, that may

have been added by your dealer. These documents are not part of the standard package.

Conventions used in this guide

To make sure that you perform certain tasks properly, take note of the following symbols

used throughout this manual.

DANGER/WARNING: Information to prevent injury to yourself

when trying to complete a task.

CAUTION: Information to prevent damage to the components

when trying to complete a task.

IMPORTANT: Instructions that you MUST follow to complete a

task.

NOTE: Tips and additional information to help you complete a

task.

RX61H User’s Manual

Typography

Bold text Indicates a menu or an item to select

Italics Used to emphasize a word or a phrase

<Key> Keys enclosed in the less-than and greater-than sign means

that you must press the enclosed key

Example: <Enter> means that you must press the Enter or

Return key

<Key1>+<Key2>+<Key3> If you must press two or more keys simultaneously, the key

names are linked with a plus sign (+)

Example: <Ctrl>+<Alt>+<D>

Command Means that you must type the command exactly as shown,

then supply the required item or value enclosed in brackets

Example: At the DOS prompt, type the command line:

afudos /i[filename]

afudos /iP5P800VM.ROM

RX61H User’s Manual

6 RX61H User’s Manual

Packing List

Before you begin installing your single board, please make sure that the following materials

have been shipped:

1 x RX61H Micro-ATX Main board

1 x DVD-ROM contains OS device drivers

2 x SATA cables

1 x I/O Shield

1 x Quick Installation Guide

If any of the above items is damaged or missing, please contact your

retailer.

RX61H User’s Manual

Revision History

Revision Revision History Date

V 1.0 First release version 2012/08/31

RX61H User’s Manual

8 RX61H User’s Manual

Table of Content

Specifications Summary ......................................................................................................9

Specifications......................................................................................................................10

Chapter 1 - Product Introduction.......................................................................................12

1.1 Product highlights.......................................................................................................12

1.2 Before you Proceed ...................................................................................................15

1.3 Motherboard Overview...............................................................................................16

1.4 Central Processing Unit (CPU)...................................................................................19

1.5 System Memory.........................................................................................................26

1.6 Expansion Card..........................................................................................................30

1.7 Jumpers .....................................................................................................................33

1.8 Connectors.................................................................................................................35

Chapter 2 - BIOS Setup ......................................................................................................44

2.1 BIOS Setup Program .................................................................................................44

2.2 BIOS Menu Screen ....................................................................................................46

2.3 Main Setup.................................................................................................................47

2.4 Advanced BIOS Setup ...............................................................................................48

2.5 Chipset.......................................................................................................................63

2.6 Boot............................................................................................................................72

2.7 Security......................................................................................................................73

2.8 Save & Exit.................................................................................................................74

RX61H User’s Manual

Specifications Summary

CPU Socket LGA1155 supports Core i7/i5/i3, Celeron, Pentium CPU

Chipset Intel® H61

Memory 2 x 240 Pin DIMM sockets supports DDR3 memories 1066/1333

MHz up to 16GB

Display Intel® HD Graphics 2000/3000/4000; DVMT Support up to 1.7GB

Memory

Audio Realtek® ALC892, 5.1 with Multiple Streaming HD Audio

LAN Intel 82579LM Gigabit Ethernet controller

Intel 82583V Gigabit Ethernet controller (Optional)

Expansion

1 x PCI-E x16

2 x PCI-E x1

1 x PCI 2.3

I/O

1 x VGA & 1 x DVI-D

2 x COM

10 x USB 2.0

4 x SATAII (support IDE, AHCI)

1x LPT (pin header)

1x PS2 MS/KB

Features

Others 8 Bit GPIO (DIO)/Front audio

RX61H User’s Manual

10 RX61H User’s Manual

Specifications

System

CPU Socket LGA1155 supports Core i7/i5/i3 , Celeron, Pentium CPU

BIOS AMI 32 Mb BIOS

System Chipset Intel® H61

I/O Chipset Nuvoton NCT6776F

Memory 2 x 240 Pin DIMM sockets supports DDR3 memories 1066/1333 MHz up to 16GB

Watchdog Timer Reset: 1 sec.~255 min. and 1 sec. or 1 min./step

H/W Status Monitor Monitoring temperatures, voltages, and cooling fan status. Auto throttling control

when CPU overheats

Expansion Slots 1 x PCI-E x16 slot, 2x PCIe x1 slot

1 x PCI Slots (PCI 2.3 compliant)

DIO 8 Bit GPIO

S3 / S4 Yes

TPM N/A

Wake up on LAN or

Ring LAN (PXE)

Smart Fan Control Yes

Display

Chipset Intel® HD Graphics 2000/3000/4000 integrated

Display Memory DVMT Support up to 1.7GB Memory

Max. Resolution 2048 x 1536 bpp(@ 75Hz)

Dual Display DVI + VGA

VGA on board

DVI on board, via level shifter

Audio

Audio Codec Realtek® ALC892, 5.1 +2 with two independent Streaming

Audio Interface Line in, Line Out, Mic-in

Ethernet

LAN1 Intel 82579LM GbLAN Controller

LAN2 Intel 82583V GbLAN Controller (Optional)

Back I/O Port

Back Panel

1 x PS2 KB/MS

1 x VGA

1 x DVI-D

2 x COM port

2 x RJ45 port
