MagnaSpread Pull-Type

WARRANTY REGISTRATION FORMS AND PROCEDURES

WARRANTY REGISTRATION & DEALER INSPECTION FORM

The following section contains the necessary documents used to register a new BBI unit for warranty.

In order to activate the new equipment warranty, these forms should be returned to BBI no later than 30

(thirty) days from the date of sale to the end user.

These forms are in triplicate and distributed as follows:

1. Dealer retains one set for his / her records

2. One set returned to BBI

3. One set remains in operator’s manual and given to end user at time of delivery

These documents are as follows:

This form is completed when the dealer is preparing to deliver the new unit to the end user. It certies

the dealer has inspected the equipment, it operates correctly and all safety signs and guards are in

place. Any modications made to the equipment by the dealer should also be noted.

This form certies that the customer was instructed on safe and proper use, the equipment operates

correctly, warranty was explained and a copy of the owner’s manual was delivered. This form also

certies that if electronic rate control is installed, the customer has been given proper instruction as

to the operation of the system. Furthermore, a dealer service contact name and number has been

provided.

Please return the executed copies to BBI within 30 days to activate the warranty.

The copies can be sent via email to: [email protected], faxed to: 706-778-2787,

or mailed to: BBI Spreaders P.O. Box 630 Cornelia, GA 30531.

This form certies that if the unit is equipped with Tractor Supplied Hydraulics, proper return

requirements were discussed.

Important Tractor-Supplied Hydraulic Systems Information

Customer’s Warranty Registration

Dealer Inspection Form

MagnaSpread Pull-Type

WARRANTY REGISTRATION & DEALER INSPECTION FORM

DEALER EQUIPMENT AND SAFETY INSPECTION REPORT

To have a fully-executed warranty, the dealer must ll this form out at time of delivery. There is no warranty

without a fully-executed warranty registration and dealer inspection form.

All warning signs and safety signs are in place

All guards are in place

Modications to equipment (write details below)

Conveyor chain tension is properly adjusted

Equipment congured as ordered

Equipment is properly assembled

Equipment is functional and operates properly

Model & Serial Number:

Comments / equipment modications:

Signature of Set-Up Person Dealer Name Date

DELIVERY INSPECTION - DEALER COPY

MagnaSpread Pull-Type

CUSTOMER’S WARRANTY REGISTRATION - DEALER COPY

CUSTOMER’S WARRANTY REGISTRATION

Customer’s warranty protection on this equipment is only valid when this certication form is completed

and signed by both the customer and dealer at the time of delivery of the equipment and registered with

the manufacturer.

Signature of Dealer Dealer Name Date

Signature of Customer Customer Name Date

DEALER’S SIGNATURE INDICATES:

CUSTOMER’S SIGNATURE INDICATES:

All systems were explained and understood

Customer received a copy of the operator’s manual

Receipt of instructions on safe and proper use

If equipped with Electronic Rate control, this system was explained and owner’s manual was received

A dealer parts/service representative contact has been provided

Warranty was explained to the customer

Electronic Rate control programmed and operates correctly

Equipment operates properly and customer was instructed in safe and proper operation

Acceptance of equipment

Receipt of owners manual and clear understanding of warranty

Dealer name: Customer name:

Address: Address:

City, State, Zip: City, State, Zip:

Model & Serial Number:

Date of Delivery:

Chain tension and adjustment section reviewed and discussed

Clear understanding of chain tension and adjustment

MagnaSpread Pull-Type

On units equipped with tractor-supplied hydraulics the return must be connected to a 0 (zero) pressure

return. Gear motor systems require no pressure return.

DO NOT connect the system unless 0 (zero) pressure can be veried on return or damage to the motors

will result! Connecting to a pressurized return will VOID THE WARRANTY.

Various tractor manufacturers use different language for their brand to identify a 0 (zero) pressure return.

Please consult your manufacturer to insure the proper 0 (zero) pressure return is identied.

To maintain maximum operational efciency, your tractor needs to have 42 GPM (Gallons Per Minute)

overall, with 2 remotes each at 21 GPM and 2,000 PSI (Pounds per Square Inch) in order to operate the

tractor-supplied hydraulic system.

IMPORTANT TRACTOR-SUPPLIED HYDRAULIC SYSTEMS INFORMATION

TRACTOR-SUPPLIED HYDRAULICS - DEALER COPY

IMPORTANT!

Signature of Dealer Dealer Name Date

Signature of Customer Customer Name Date

MagnaSpread Pull-Type

WARRANTY REGISTRATION & DEALER INSPECTION FORM

DEALER EQUIPMENT AND SAFETY INSPECTION REPORT

To have a fully-executed warranty, the dealer must ll this form out at time of delivery. There is no warranty

without a fully-executed warranty registration and dealer inspection form.

All warning signs and safety signs are in place

All guards are in place

Modications to equipment (write details below)

Equipment congured as ordered

Equipment is properly assembled

Equipment is functional and operates properly

Model & Serial Number:

Comments / equipment modications:

Signature of Set-Up Person Dealer Name Date

DEALER INSPECTION - BBI COPY

Conveyor chain tension is properly adjusted

MagnaSpread Pull-Type

CUSTOMER’S WARRANTY REGISTRATION - BBI COPY

CUSTOMER’S WARRANTY REGISTRATION

Customer’s warranty protection on this equipment is only valid when this certication form is completed

and signed by both the customer and dealer at the time of delivery of the equipment and registered with

the manufacturer.

Signature of Dealer Dealer Name Date

Signature of Customer Customer Name Date

DEALER’S SIGNATURE INDICATES:

CUSTOMER’S SIGNATURE INDICATES:

All systems were explained and understood

Customer received a copy of the operator’s manual

Receipt of instructions on safe and proper use

If equipped with Electronic Rate control, this system was explained and owner’s manual was received

A dealer parts/service representative contact has been provided

Warranty was explained to the customer

Electronic Rate control programmed and operates correctly

Equipment operates properly and customer was instructed in safe and proper operation

Acceptance of equipment

Receipt of owners manual and clear understanding of warranty

Dealer name: Customer name:

Address: Address:

City, State, Zip: City, State, Zip:

Model & Serial Number:

Date of Delivery:

Chain tension and adjustment section reviewed and discussed

Clear understanding of chain tension and adjustment

MagnaSpread Pull-Type

On units equipped with tractor-supplied hydraulics the return must be connected to a 0 (zero) pressure

return. Gear motor systems require no pressure return.

DO NOT connect the system unless 0 (zero) pressure can be veried on return or damage to the motors

will result! Connecting to a pressurized return will VOID THE WARRANTY.

Various tractor manufacturers use different language for their brand to identify a 0 (zero) pressure return.

Please consult your manufacturer to insure the proper 0 (zero) pressure return is identied.

To maintain maximum operational efciency, your tractor needs to have 42 GPM (Gallons Per Minute)

overall, with 2 remotes each at 21 GPM and 2,000 PSI (Pounds per Square Inch) in order to operate the

tractor-supplied hydraulic system.

IMPORTANT TRACTOR-SUPPLIED HYDRAULIC SYSTEMS INFORMATION

TRACTOR-SUPPLIED HYDRAULICS - BBI COPY

IMPORTANT!

Signature of Dealer Dealer Name Date

Signature of Customer Customer Name Date

MagnaSpread Options:

8’, 10’ Single-axle

10’, 12’, 14’, 16’ Tandem-axle

Tractor-supplied or self-contained

hydraulic systems

OPERATOR MANUAL

This manual is valid for all MagnaSpread

Pull-Type congurations

Your serial number can be found here:

MagnaSpread Pull-Type

TABLE OF CONTENTS

2 TABLE OF CONTENTS

3 A MESSAGE FROM BBI

4-6 DELIVERY AND WARRANTY CHECKLISTS

7 WARRANTY

8-10 SAFETY INSTRUCTIONS

11 TRACTOR PREPARATION AND HOOK-UP

12 HYDRAULIC CONFIGURATION

13-17 IDENTIFYING COMPONENTS

18-21 FIELD TESTING

22-23 MACHINE OPERATION

24-25 LUBRICATION AND MAINTENANCE

26-28 CHAIN TENSION ADJUSTMENT

29 TIPS & TRICKS

30 PARTS AND SHIPPING

31 PARTS IDENTIFICATION AND ORDERING

32-48 ASSEMBLY AND PARTS IDENTIFICATION

49-54 GROUND SPEED TABLES AND RATE CHARTS

MagnaSpread Pull-Type

The BBI team takes pride in producing superior spreaders that will provide many years of

service. In bringing the best spreaders to the industries of agriculture, poultry, and construction,

we carefully select components with a proven performance record and availability. Our skilled

employees give special attention to detail in design and assembly to make certain our equipment

will meet or exceed your expectations in the eld.

Our parts department stands ready to serve you with replacement parts at affordable prices. We

stock a large inventory to assure support for our customers, and take pride in offering “same day

service” for those orders received before mid-afternoon.

At BBI, we provide quality service with a friendly atmosphere. BBI stands hand-in-hand with our

dealers in the eld. Our local dealers are your rst point of contact and empowered to solve your

problems. If that fails, we are prepared to serve you at any time. We strive to quickly provide

solutions for your needs in order to minimize any downtime or delays.

Our company takes safety very seriously, and we give great concern to our products in an

ongoing effort to reduce any potential safety issues, whether with equipment or in the workplace.

We design our equipment intentionally to minimize pinch points and provide guards where they

do exist. BBI places decals on our equipment to identify and caution against areas containing

pinch points and hazardous moving parts.

Please be sure that those who operate BBI equipment receive proper training. Never conduct

maintenance or repairs unless the equipment is fully disabled with the power source turned

off. Never stand inside the unit while in operation or moving. Since we design our spreaders to

project materials in patterns ranging from 30 to 90 feet, depending on the specic equipment,

standing too close to equipment can result in injury. Please use extreme caution when operating

all equipment.

Thank you for choosing BBI spreading equipment. You will be glad you did.

Richard B. Hagler

President

“Driving Value”
