Bazooka NOS6 Manual de usuario
Models: NOS6, NOS8, NOS8A,
NOS8P, NOS8W, SCUBA8
Dear Frien ,
Thank you for selecting Bazooka® Mobile Au io for your car stereo
system. This Bazooka subwoofer represents our continue commitment
to efficiency an esign. An innovative manufacturing process we
evelope for the Bazooka provi es consumers with state-of-the-art
speaker system esign. At Bazooka Mobile Au io, we take pri e
manufacturing the most revolutionary bass speaker systems ever create ,
featuring our patente Bass Tubes® enclosure esign, an we hope
you will take pri e in owning them.
Several years ago, we realize that efficiency was the wave of the future
in autosoun , so we ma e a commitment to esign, manufacture, an
eliver the most efficient speaker systems possible.
To ay we market our patente speaker systems worl wi e an the
high quality of the Bazooka bran is well respecte by consumers an
ealers of all nationalities.
When properly installe , Bazooka Mobile Au io systems will give you
years of clean uninterrupte soun repro uction. Therefore, I urge you
to take a few minutes of your time to review this instruction booklet.
It was esigne to give you a better un erstan ing of our pro ucts
an to explain how to apply them properly.
Thank you again for choosing Bazooka. Our early commitment to quality
has ma e them the pro uct of choice, an I am sure you will agree that
you have ma e the right one! Enjoy!
Sincerely,
JON C. JORDAN
Presi ent
BAZOOKA Mobile Au io
1
2
WARRANTY
All SAS® subwoofer products are covered under warranty for ONE full
year from the date of purchase. Terms and conditions of the warranty
are as stated on the warranty card included in the box with the product.
SAS recommends that you use only authori ed BAZOOKA® dealers to
install this product. Improper or incorrectly performed installation voids
this warranty.
BASS TUBES ENCLOSURE
BAZOOKA® subwoofer speaker systems exclusively incorporate the
revolutionary Bass Tubes® patented subwoofer enclosure design available
only from SAS.®
PRACTICE SAFE LISTENING
Continuous exposure to high volumes of sound may cause permanent
hearing loss. High powered auto sound systems are capable of producing
sounds well over 130 dB. Even short periods of play at high volume
levels can impair your ability to hear necessary traffic sounds and may
constitute a ha ard. Please use common sense and practice SAFE
LISTENING !
If you have any questions contact
the SAS Technical Support Department at:
Phone - 800 THE-TUBE Fax - (225) 272-9844
Email - [email protected] Website - www.bazooka.com
In Canada: (604) 988 2966
15049 Florida Blvd., Baton Rouge, LA. 70819
CONTENTS
Warranty pg 2
System Features pg 3
Spe ifi ations pg 3
Pre Installation pg 4, 5
Finishing The Look Part 1 pg 5
Finishing The Look Part 2 pg 6
Vehi le Pla ement pg 7
Mounting The Subwoofer pg 8
Wiring pg 9, 10
Woofer Size 6.5 (NOS6) 8 (NOS8, NOS8W, NOS8P)
Voice Coil Size 1 high power. /high temp. 2 high pwr. /high temp.
Magnet Size 20 oz. 36 oz.
Frequency response* 39-1500 hz. 39-1500 hz.
Efficiency* 100 B* 102 B*
Power Han ling 6-100 watts/channel 6-300 watts/channel
Dimensions 18x6.75x8 27.5" x 8.5" x 10"
Weight 11 lbs. 23 lbs.
Impe ance SVC 4 ohm SVC 4 ohm
SYSTEM FEATURES
6 or 8 PURE-PISTON WOOFER
150 WATT HIGH POWER AMP (NOS8A ONLY)
TURBO COOLED VOICE COILS
BASS REFLEX, DUCTED PORT ENCLOSURE
CORNER LOADING
COPLANAR OUTPUT
HIGH OUTPUT EFFICIENCY
MOISTURE RESISTANT ENCLOSURE AND WOOFER
MAXIMIZED SPACE EFFICIENCY
1 YEAR WARRANTY
LARGE MAGNET FOR INCREASED POWER HANDLING
* The efficiency levels of all Bazooka subwoofer speaker systems are measure in the
typical environment: In the low bass region with one watt of power.
3
SPECIFICATIONS: PASSIVE UNITS
SPECIFICATIONS: NOS8A
Woofer Size 8
Voice Coil Size 1.5 high power./high temp.
Magnet Size 28 oz.
Frequency response* 39-250 hz.
Efficiency** 102 B*
Power Han ling 150 watts
Dimensions 18.325" x 8.5" x 10"
Weight 20 lbs.
Impe ance 4 ohms
INSTALLATION
Please take time to read through this manual and plan out your installation
before you begin!
Locate an area in the rear of the vehicle where you would like to place the
Ba ooka speaker systems. The location you have selected must meet the following
requirements in order for the Ba ooka to be properly installed in the vehicle:
1.) The woofer (grill end) should be facing into a corner. (See vehicle placement
recommendations on page 5)
2.) Ideally, there should be 2 to 4 inches between the woofer and the corner it
is pointing into.
3.) The mounting area should be carefully checked to be sure that the mounting
screws will not damage the gas tank, electrical wiring, fuel lines, or the spare tire
during the mounting of the strap bases.
4.) Ensure that the mounting base brackets are 13 apart and square before
mounting. Incorrect placement of the brackets will make final mounting difficult
or impossible (See mounting on page 8).
5.) The bracket mounting bases should be screwed securely to a rigid surface
that is part of, or anchored to, the structure of the vehicle.
Be sure that your application meets all of these requirements before you continue
the installation procedure!
4
5
FINISHING THE LOOK (Step 1)
In or er to complete the look of your subwoofer, you will nee to install
the inclu e wire loom over the wire and attach the nozzle to the top of
the tank.
To begin, the wiring nee s to be route THROUGH the nozzle. If necessary,
begin by fee ing the wire through the nozzle as shown in the picture
below. Continue fee ing wire through as you push the nozzle into the top
of the tank until you hear a click. O the NOS8A, the amou t of
wiri g a d small area of the ozzle ca make this difficult. To make
this easier, Bazooka recomme ds twisti g the ozzle assembly
arou d to make the wiri g coil up i side the ozzle a d take up
less space. Be sure ot to rotate the ozzle so much that it pulls
the wires loose from their co ectio s. Usually, o e-a d-a-half
tur s is all that is ecessary.
On the NOS8A, you will also nee to install the valve knob onto the gain
control at this point.
Valve Gain Knob
Twist if Necessary
6
Next, install the wire loom by p shing the loom onto the wire, as
shown in below. Starting from the free end and working your way up
to the no le. (Note: P lling the wire loom will res lt in binding,
making it more diffic lt to p t the loom in place.) Remove the
locking nut from the no le by turning counter-clockwise ¼ turn. Once
the wire loom is passed along the length of the wire and through the
locking nut, fold the wire loom over itself at least 5/8 of an inch, so
the end of the loom is flush with the locking nut. Slide the remaining
wire and loom through the locking nut, and screw the locking nut into
place by turning ¼ turn clockwise.
FINISHING THE LOOK (Step 2)
Braided wire loom
Locking
Nut
5/8
Fold over
HATCHBACK INSTALLATION
tube size is exaggerate for emphasis
TRUCK INSTALLATION
tube size is exaggerate for emphasis
SEDAN INSTALLATION
tube size is exaggerate for emphasis
VEHICLE PLACEMENT RECOMMENDATIONS
7
8
Space floor mount brackets 13 apart
(inside edge to inside edge)
Floor Mount
Bracket
Mounting the NOS Tube:
Once you have found a suitable location, you need to mount the NOS
Tube. Mounting the unit ensures that it will give you years of trouble-
free performance, and also guarantees that your unit is correctly
oriented for it to operate properly. To begin, mount the bases parallel
on the floor of the vehicle with the bases EXACLTY 13 inches apart,
from inside edge to inside edge. Mounting these brackets incorrectly
will make the final mounting steps difficult or impossible. The tall
bracket should be mounted towards the front of the vehicle, to stand
the back of the unit up, mimicking an actual NOS installation. Once
the brackets are mounted firmly to the vehicle, place the NOS Tube on
the brackets, and secure them with the enclosed mounting straps. The
straps simply screw into the brackets with the supplied hardware.
Red
Black
RCA
Gree /White
Ora ge
RCA
Brow /Grey
POWER WIRE (NOS8A nly)
The power wire must be fuse an connecte irectly to the positive
terminal of the battery to provi e a power source with a low voltage
rop an low noise. Do not make the power connection at the fuse
block or any point other than the battery. Improper power sources can
re uce output an cause istortion.
The fuse hol er shoul be connecte to the battery's positive terminal.
The fuse is esigne to prevent fire or amage to your car, shoul the
battery wire short to groun . Wait to insert the fuse into its hol er
until all wire connections have been ma e.
If it is necessary to lengthen the battery wire, a the require length
between the amplifier an the fuse hol er, not the fuse hol er an
the battery. If you nee to exten the battery wire, use 12 gauge or
larger for NOS8A, it is best to use as short a wire as possible. Be sure
you DO NOT run the power wire next to the input cables of the amplifier,
this will in uce noise. Avoi running the power wire near the ra io's
9
WIRING DIAGRAM (NOS8A Only)
RED 12 GAuge
BLACK 12 Gauge
Ora ge 16 Gauge
Gree /White RCA
Brow /Grey RCA
+ 12 Volt Battery
Chassis Grou d
Remote Tur -O
Right RCA I put
Left RCA I put
