Baxi Single Channel Digital Programmer Instrucciones de montaje
en
United Kingdom
These instructions should be read in conjunction with the Boiler Installation and Service Instructions.
Please leave with the user when completed.
Instruction manual for Installers and Users
Single Channel Digital Programmer
Override
Extra Hour
Mode
DAY/ PROG RUN
TIME
OK
Holidays
OFF
am
Thu
AUTO
ONCE
CONT
EXT HOUR
+1
+2
+3
ON1
Select
2 EcoBlue Accessories 7212551
Contents
3EcoBlue Accessories
7212551
ection Page
1. Introduction
1.1 General energy information 4
1.2 Description of the device 4
1.3 Designated use 5
1.4 Technical data 5
2. itting the Controller
2.1 Installation and mounting 6
2.2 General siting information 6
2.3 Wiring and wall mounting 6
3. Operation & Configuration
3.1 Quick start guide 7
3.2 Guide to button functions 7
3.3 Commissioning 8
3.4 To alter the time and date 9
3.5 To show a digital time display and change
AM/PM time display to 24 hour clock 10
4. Setting the Heating Programmes
4.1 Running a default programme 11
4.2 Selecting a programme type and
a default programme 12
4.3 Weekly programming days or blocks 13
4.4 5-2 programming 13
4.5 Daily programming 13
4.6 Setting time periods 14
5. Operating Mode
5.1 Using the mode button 15
5.2 Override mode 15
5.3 Extra hour mode 15
5.4 Holiday mode 16
6. Installer Information
6.1 Installer menu 17
6.2 Disposal 19
4 EcoBlue Accessories
1. Introduction
7212551
Warning
Danger! Risk of electric shock! Installation must be carried out by a person competent to do so!
Before removal from backplate, the device must be disconnected from the power supply!
Interferences and changes to the device will invalidate the warranty and guarantee rights.
Maximum diameter of the cable for the terminals is 2 x 2.5 mm2.
Read and observe these instructions fully to ensure the correct operation of the device and a safe
operation.
1.1 General energy information
What is a programmer?...an Explanation for Householders
(as recommended by the Energy Savings Trust)
Programmers allow you to set ‘ON’ and ‘O ’ time periods. Some models switch the central
heating and domestic hot water on and off at the same time, while others allow the domestic hot
water and heating to come on and go off at different times. Set the ‘ON’ and ‘O ’ time periods to
suit your own lifestyle. On some programmers you must also set whether you want the heating and
hot water to run continuously, run under the chosen ‘ON’ and ‘O ’ heating periods, or be
permanently off.
The time on the programmer must be correct. Some types have to be adjusted in spring and
autumn at the changes between Greenwich Mean Time and British Summer Time. You may be
able to temporarily adjust the heating programme, for example, ‘Override’, ‘Advance’, or ‘Boost’.
These are explained in the manufacturer’s instructions. The heating will not work if the room
thermostat has switched the heating off. And, if you have a hot-water cylinder, the water heating
will not work if the cylinder thermostat detects that the hot water has reached the correct
temperature.
1.2 Description of the device
Your single channel programmer provides timing control for your central heating, letting you set ON
and O periods to suit your own lifestyle.
Backlit LCD Display
Real Time Clock
Up to 3 ON/O per day
Automatic summertime / wintertime changeover
Daily, weekly and week-weekend programming possibility
Different running modes: O , AUTO, ONCE, CONTINUOUS and HOLIDAYS
Manual override function
Manual extra hour function
3 different pre-programmed profiles, customisable by user
1. Introduction
5EcoBlue Accessories
7212551
1.3 Designated use
The programmer is used to control central heating zone systems or combi boilers.
Suitable for use in dry rooms only!
Do not install in the vicinity of devices which generate inductive discharges (motors, transformers,
etc.)
1.4 Technical data
Dimensions H x W x D (mm) 95 x 148 x 36
Weight g (approx.) 285
Power supply 230 V AC / 50-60 Hz
Power consumption < 3 W
Power reserve >2h
Switching capacity 3 A 250 V ~ resistive, cos φ = 1
3 A 250 V ~ inductive, cos φ = 0.6
Time display 24 h or 12 h AM/PM format
Time setting resolution:
- Time of day 1 min.
- Programmes / min. switching 1 min.
Programmes Selectable (daily , weekly, or week-weekend)
Number of switchings per day 3 ON/O pairs
(2 ON/O pairs selectable)
Operating temperature range 0°C ... + 45°C
Ambient temperature -20°C ... + 55°C
Humidity range 10 to 90% RH, non condensing
Accuracy Type ± 1 sec./day at +20°C
Terminal capacity 2 x 2,5 mm2
Protection type IP 30
European standards EN60730-2-7
Compliant with building regulations
(Part L UK) (Part J Scotland)
6 EcoBlue Accessories
2. itting the Controller
7212551
2.1 Installation and mounting
Warning
Danger! Risk of electric shock! Installation must
be carried out by a person competent to do so!
2.2 General siting information
Identify a suitable site to locate the unit. ig. 1
gives guidance on optimum positioning and siting
restrictions.
Do not place behind curtains.
Do not place above or below sources of heat.
2.3 Wiring and wall mounting
Undo the retaining screw underneath the
programmer. ig. 2(a). Insert a screwdriver as
shown and carefully prise the programmer loose
and lift away from backplate.
Wiring can be routed from behind or if surface
mounted, through the breakout tab to the left of
the retaining screw at the bottom of the back
plate.
ix the backplate to the wall using the screws
provided.
Connect the wiring into the backplate connectors
as shown in ig. 3.
The input to terminal 1 may be supplied from the
mains supply or from the boiler wiring
connections as appropriate to the appliance
used.
Please consult the relevant boiler instructions for
further guidance.
Replace the programmer on the backplate and
press firmly down to fully engage the contact pins
and tighten the screw underneath the
programmer.
1.5 m
NL1234
N
INPUT
OFF
ON
OUTPUT TO ROOM
THERMOSTAT / BOILER
timeswitch /
programmer
wallplate
L
Fig. 3. Wiring diagram
Fig. 2. Mounting the controller
Fig. 1. Siting
a
d
e
c
b
3. Operation & Configuration
7EcoBlue Accessories
7212551
3.1 Quick start guide
1. Connect mains power.
2. Press OK three times.
The default Standard programme runs.
You can control the unit with the Override, Extra
Hour or Mode buttons.
Please read the full instructions if you want to
know more.
3.2 Guide to button functions
A Day of the week indicator
B Current day, month, year
C Central heating operating mode indicator
D Central heating override button
E Central heating extra hour button
Central heating operating mode button
G Central heating indicator lamp
H Central heating extra hour indication
I Central heating programming period indication
J Select indicator lamps
K Select
L OK button
M “-” and “+” button
N1Holiday button
O1Holiday icon
P Information text line
Q Analogue clock / current time
R Warning icon
Override
Extra Hour
Mode
DAY/ PROG RUN
TIME
OK
Holidays
OFF
am
Thu
AUTO
ONCE
CONT
EXT HOUR
+1
+2
+3
ON1
Select
A
D
R
Q
P
O1
N1
M
E
F
G
H
I
J
LK
BC
Override
Extra Hour
Mode
OK
Select day with + and -
buttons and confirm with OK.
DAILY The same ON/O time schedule is used every day.
WEEKLY A different time schedule can be programmed for
each day.
5-2 One time schedule is used for Mon- ri and a different
one can be used for Sat & Sun.
OK
2
Select your program type with +
and - buttons and confirm with OK.
OK
1
Select month with + and -
buttons and confirm with OK.
OK
3
Select year with + and -
buttons and confirm with OK.
OK
4
Select hour with + and -
buttons and confirm with OK.
OK
5
Select minutes with + and -
buttons and confirm with OK.
OK
6
The date and time are saved.
The programmer goes to
RUN mode
OK
7
8 EcoBlue Accessories
3. Operation & Configuration
3.3 Commissioning
Connect the programmer to the power. The product name and version are displayed briefly.
7212551
3. Operation & Configuration
3.4 To alter the time and date
9EcoBlue Accessories
7212551
Press the SELECT buttons until DAY/TIME light is lit.
DAY/ PRG RUN
Select
TIME
1
Select day with + and -
buttons and confirm with OK.
OK
2
Select month with + and -
buttons and confirm with OK.
OK
3
Select year with + and -
buttons and confirm with OK.
OK
4
Select hour with + and -
buttons and confirm with OK.
OK
5
Select minutes with + and -
buttons and confirm with OK.
OK
6The date and time
are saved.
Press the right hand
SELECT button to
select RUN mode.
OK
7
DAY/ PRG RUN
Select
TIME
10 EcoBlue Accessories
3. Operation & Configuration
3.5 To show a digital time display and change AM/PM time display to 24 hour clock
7212551
DAY/ PRG RUN
Select
TIME
OK
1
OK
2
OK
3
Press the SELECT
buttons until
RUN light is lit.
Press and hold + & - buttons
together for 10 seconds. Press OK
Press OK
OK
4
Press -
OK
5
Press OK
OK
6
Press OK
OK
7
Press + or -
OK
8
Press OK
Press + seven times
to exit menu.
