Baumatic BSO670SS Manual de usuario

INSTRUCTION MANUAL

www.baumatic.com

PN:261800313457

BSO670SS

oven

14 Function Touch

control

- 1 -

INSTRUCTION MANUAL

BSO670SS

14 FUNCTION TOUCH CONTROL

Built in oven

NOTE: This User Instruction Manual contains important information,

including safety & installation points, which will enable you to get the most out

of your appliance. Please keep it in a safe place so that it is easily available for

future reference; for you or any person not familiar with the operation of the

appliance.

- 2 -

Contents

Environmental note 3

Important safety information 4 –8

Description of the appliance 10

Control panel 10

Description of display 10

Setting and changing the current timer 11

General instructions 12

Changing the oven function 13

Clock Functions 13

Setting the start and end time 14

Setting the minute minder function 10

Setting the duration function 11

Setting the end cook function 12-13

Setting the start and end time function 13-14

Other functions 15-16

Oven Functions 17-20

Automatic programmes 21

Cleaning and maintenance 23

Replacing the oven bulb 24

Door removal 25

Removal of the internal glass panel 25

Sliding rack kit assembly 25

Installation 26

Electrical connections 26

Installing the oven into the kitchen cabinet 27

Ventilation requirements 28

My appliance isn’t working correctly 29 –30

Oven main function cooking instruction 32-33

Technical data 33

- 3 -

Environmental note

oThe packaging materials that we use are environmentally friendly and can be recycled.

oPlease discard all packaging material with due regard for the environment

- 4 -

IMPORTANT SAFETY INFORMATION

Caution!

Do not use the oven until you have read this instruction manual.

The oven is intended for household use only.

General Information

This appliance is designed for domestic household use and can be built into

a standard kitchen cabinet or housing unit.

IMPORTANT: The adjacent furniture or housing and all materials used in

the installation must be able to withstand a minimum temperature of 85°C

above the ambient temperature of the room it is located in, whilst in use.

Certain types of vinyl or laminate kitchen furniture are particularly prone to

heat damage or discoloration at temperatures below the guidelines given

above.

Any damage caused by the appliance being installed in contravention of this

temperature limit, or by placing adjacent cabinet materials closer than 4mm

to the appliance, will be the liability of the owner.

For use in leisure accommodation vehicles, please refer to the appropriate

information given in the installation instructions for this appliance.

The use of this appliance for any other purpose or in any other environment

without the express agreement of our company. will invalidate any warranty

or liability claim.

Your new appliance is guaranteed against electrical or mechanical defects,

subject to certain exclusions that are noted in our company’s Conditions Of

Guarantee. The foregoing does not affect your statutory rights.

Repairs may only be carried out by Service Engineers or their authorized

service agent.

- 5 -

Warning and safety instructions

This appliance complies with all current European safety legislation. We do

wish to emphasis that this compliance does not remove the fact that the

appliance surfaces will become hot during use and retain heat after

operation.

This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction

concerning use of the appliance by a person responsible for their safety.

During use the appliance becomes hot. Care should be taken to avoid

touching heating element inside the oven.

Means for disconnection must be incorporated in the fixed wiring in

accordance with the wiring rules.

If the supply cord is damaged, it must be replaced by the manufacturer, its

service agent or similarly qualified persons in order to avoid a hazard.

WARNING: The appliance and its accessible parts become hot

during use.

Care should be taken to avoid touching heating elements.

Children less than 8 years of age shall be kept away unless

continuously supervised.

This appliance can be used by children aged from 8 years and above

and persons with reduced physical, sensory or mental capabilities or

lack of experience and knowledge if they have been given

supervision or instruction concerning use of the appliance in a safe

way and understand the hazards involved. Children shall not play

with the appliance. Cleaning and user maintenance shall not be

made by children without supervision.

- 6 -

If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualified persons in

order to avoid a hazard.

During use the appliance becomes hot. Care should be taken to

avoid touching heating elements inside the oven. - A steam cleaner

is not be used.

WARNING: Ensure that the appliance is switched off before

replacing the lamp to avoid the possibility of electric shock.

WARNING: Accessible parts may become hot during use. Young

children should be kept away.

Do not use harsh abrasive cleaners or sharp metal scrapers to clean

the oven door glass since they can scratch the surface, which may

result in shattering of the glass.

Only use the temperature probe recommended for this oven.

Child Safety

We strongly recommend that babies and young children are prevented from

being near to the appliance and not allowed to touch the appliance at any

time.

If it is necessary for younger family members to be in the kitchen, please

ensure that they are kept under close supervision at all times.

- 7 -

General Safety

This appliance is not intended for use by persons (including children) with

reduced physical sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction

concerning use of the appliance by a person responsible for their safety.

Do not place heavy objects on the oven door or lean on the oven door when

it is open, as this can cause damage to the oven door hinges.

Do not leave heated oil or fat unattended, as this is a fire risk.

Do not place pans or baking trays directly on the base of the oven cavity, or

line it with aluminum foil.

Do not allow electrical fittings or cables to come into contact with areas on

the appliance that get hot.

Do not use the appliance to heat the room it is located in or to dry clothing.

Do not install the appliance next to curtains or soft furnishings.

Do not attempt to lift or move cooking appliances by using the oven door or

handle, as this may cause damage to the appliance or result in injury to the

person lifting the appliance.

Cleaning

Cleaning of the oven should be carried out on a regular basis.

Great care should be taken whilst using this appliance and when following

the cleaning procedure.

IMPORTANT: The appliance must be disconnected from the mains before

following the cleaning procedure.

- 8 -

Installation

This appliance must be correctly installed by a suitably qualified person,

strictly in accordance with the manufacturer’s instructions.

oWe decline any responsibility for injury or damage, to person or

property, as a result of improper use or installation of this appliance.

oHeat, steam and moisture will be created during use of the appliance, take care to avoid

injury and ensure that the room is adequately ventilated. If the appliance is going to be

used for prolonged periods of time, then additional ventilation may be required.

oPlease consult with your qualified installer if you are in any doubt about the amount of

ventilation that you will require.

Declaration of conformity.

oCE: Appliance conforming to the European directives 89/336/EEC, 93/68/EEC, 2006/95/CE

and subsequent revisions and “RoHS” directive 2011/65/CE.

oThe manufacturer declares that the oven is built using certified materials and requires the

appliance to be installed in accordance with the standards currently in force. This appliance

must be used by a trained person for domestic purposes only.

*The RoHS directive stands for “the restriction of the use of certain hazardous substances in

electrical and electronic equipment”. This directive bans the placing on the EU market of

new electrical and electronic equipment containing more than the agreed levels of lead,

cadmium, mercury, hexavalent chromium, polybrominated biphenyl (PBB) and

polybrominated diphenyl ether (PBDE) flame retardants.

- 9 -

DESCRIPTION OF THE APPLIANCE

Control panel

Side shelf

Oven shelf

Oven door

Door Handle

Accessories

Side shelf left

Side shelf right

Oven shelf

Bake tray Rotisserie Rotisserie bracket
