User Manual for your
BZE290SS
FREEZER
NOTE: This User Instruction Manual contains important information,
including safety & installation points, which will enable you to get the most
out of your appliance. Please keep it in a safe place so that it is easily
available for future reference.
169895
Environmental note.....................................................3
Important safety information......................................4
Specifications of your freezer....................................6
Description of the appliance ......................................7
Using your Baumatic freezer......................................8
The freezer compartment..........................................10
Cleaning and maintenance.......................................13
Installation..................................................................14
Troubleshooting ........................................................18
Baumatic ltd. - Conditions of guarantee .................20
2
Contents
169895
NOTE: This User Instruction Manual contains important information, including safety &
installation points, which will enable you to get the most out of your appliance. Please keep
it in a safe place so that it is easily available for future reference. for you or any person not
familiar with the operation of the appliance.
This appliance is marked according to
the European directive 2002/96/EC on
Waste electrical and Electronic Equipment
(WEEE). By ensuring this product is
disposed of correctly, you will help
prevent potential negative consequences
for the environment and human health,
which could otherwise be caused by
inappropriate waste handling of this
product.
The symbol on the product, or on the
documents accompanying the product,
indicates that this appliance may not be
treated as household waste. Instead it
shall be handed over to the applicable
collection point for the recycling of
electrical and electronic equipment.
Disposal must be carried out in
accordance with local environmental
regulations for waste disposal.
For more detailed information about
treatment, recovery and recycling of this
product, please contact your local city
office, your hosehold waste disposal
service or the shop where you purchased
the product.
3
Environmental note
Conformity to W.E.E.E.
Directive
169895
Your safety is of the utmost importance to Baumatic. Please
make sure that you read this instruction booklet before
attempting to install or use the appliance. If you are unsure of
any of the information contained in this booklet, please contact
the Baumatic Technical Department.
IMPORTANT: Any installation work must be carried out by a
qualified electrician or competent person.
• Your appliance is only designed to be used in the home. It is
suitable for freezing and storing frozen food. If it is used for
any other purpose or it is not used correctly, then Baumatic
Ltd. Will accept no liability for any damage that may be
caused.
• Altering the specification of the appliance must not be
attempted for reasons of safety.
• Check the appliance for any signs of transport damage. If
you notice any damage, then you should not connect your
appliance to your mains supply and should contact your
retailer.
• Your appliance contains R600a refrigerant, which is a
natural gas that does not contain CFCs that can damage the
environment. However it is a flammable substance, therefore
care should be taken:
• During the transportation and installation of the appliance,
make sure that the refrigeration pipework does not get
damaged.
• If it does become damaged then sources of ignition and open
flames should be avoided. Also the room that the appliance is
4
Important safety information
Use of the appliance
Before using your
appliance
Refrigerant
169895
situated in should be thoroughly ventilated.
• Do not place any objects on top of the appliance, as this may
damage the table top.
• Packaging material should be kept away from children.
• Children should not be allowed to touch the controls or play
with the appliance.
• Do not pull on the power supply cable to remove the plug
from your mains supply socket.
• Do not pull out or insert the plug with wet hands.
• Do not attempt to use your appliance outdoors or any place
where it is likely to come into contact with the elements.
• Before cleaning the appliance or performing maintenance
work, ensure that the appliance has been disconnected from
your mains supply.
• Never allow the back coils of the appliance to come into
contact with the wall surface.
• Always ensure that the location where you are installing your
appliance is free of stored items such as papers and other
flammable materials.
• Never block the ventilation openings of the appliance, either
on the inside or its exterior.
• It is vital to keep your appliance well ventilated, so that there
is proper air flow between the bottom of the unit and the
plinth/kick plate which it is sitting on.
• Do not place electrical devices inside of the appliance.
5
Child safety
General safety
169895
You should not attempt to repair the appliance yourself, as
this could cause injury or a more serious malfunction. If you
require a service call then please contact the Baumatic Service
Department.
Congratulations on purchasing a Baumatic BR22/8 Built-in
Combi Fridge/Freezer!
• Frost free freezer
• Adjustable thermostat
• Electronic control
• Bacteria safe system
• Fast freeze function
• Temperature rise warning indicator
• Open door warning indicator
• 8 Freezer drawers
• Reversible door
• Adjustable feet
• Stainless steel front and sides
Dimensions of appliance mm (H x W x D): 1800 x 600 x 640
Energy efficiency class
Energy class: A
* Please refer to the installation instructions for more specific
information on the size of aperture that you will require.
IMPORTANT: When you install your appliance it is important to bear in mind its climatic
rating.
In order to find out the climatic rating of your appliance, you should check the rating plate. The
rating plate is located on the front left edge of the inside of the fridge section. You will need to open
the door of your appliance to be able to find it.
The rating plate will indicate the ambient temperature range that your appliance will function
correctly within.
6
Service
Specifications of your freezer
169895
1. Control panel & thermostat control
2. No frost freezing unit
3. Interior illumination
4. Freezing and storage drawers
5. Large storage drawer
6. Adjustable feet
7. Wheels
• The freezer drawers are protected against accidental
extraction.
• To remove a drawer from the appliance, open it and lift the
front part upwards. Then pull it out.
• Certain models are fitted with pull out slide guides which
facilitate opening.
• Pull out guide drawers are extracted by lifting the rear end and
pulling out at an angle under 45 degrees. You need to reinsert
them the opposite way, to put a pull out guide drawer back into
position.
7
Description of the appliance
169895
• Make sure that it has been installed by a suitably qualified
person, as per the information contained in Baumatic’s
installation instructions.
• After delivery, wait for three hours before connecting the
appliance to your mains supply. This will allow any refrigerant
gasses that may have been disturbed during the transportation
process, are allowed to settle.
• The outside of the appliance and the removable accessories
contained within it, should be cleaned with a solution of liquid
soap and water.
• The interior of the appliance should be cleaned with a solution
of sodium bicarbonate dissolved in lukewarm water. The
interior and accessories should be thoroughly dried, after the
cleaning process has been completed.
• There can be an odour when you first switch on the appliance.
It will lessen as the appliance starts to cool.
• When you first switch on the appliance, the compressor
will run continuously for approximately 24 hours or until the
refrigerator reaches a cool enough temperature.
• During this period of time, you should try not to open the
door frequently or place a large amount of food within the
appliance.
• If the unit is switched off or unplugged, you must allow at least
5 minutes before restarting the appliance on the thermostat or
connecting it to your mains supply.
A Temperature selector and on/off button
B Green LED (illuminates when the appliance is switched on)
C Freezer alarm off button (model with buttons only)
D Freezer alarm LED
E Fast Freeze button (model with buttons only)
F Fast Freeze LED
8
Using your Baumatic freezer
Before switching on
During first use
Control panel
169895
You switch on your appliance by connecting it to your mains
supply and setting the thermostat. The thermostat is located on
the right hand side of the control panel.
• The appliance is switched on by turning dial Atowards the
Max position.
• The green LED will come on when the dial moves past Min.
• The appliance is switched off when the arrow on the dial points
to the ON/OFF symbol . However the appliance is still under
mains power.
• The thermostat automatically regulates the temperature inside
the freezer, depending on what position you have turned the
thermostat control knob to.
• Position means that the appliance is switched off and will
not cool.
• Position Min will give you a higher temperature inside the
freezer.
• Position Max will give you a lower temperature inside the
freezer.
• Ideally the thermostat should be set to the Eco position.
• The freezer section can cool down to -18°C and lower.
• IMPORTANT: The ambient temperature of the room, the
temperature of food and the amount of food that has been
placed in the freezer and how often the door is opened, will all
affect the temperature being maintained by the appliance.
• On the maximum setting (position Max), your freezer will work
harder to maintain a lower temperature. There is no need to
run your appliance on this setting for prolonged periods and
you should return the thermostat knob to the Eco position.
9
Turning on the appliance
and setting the
thermostat
