Baumatic BFD61SS Manual de usuario

MANUAL FOR THE USE AND INSTALLATION OF YOUR DISHWASER

FOR BETTER AND EASIER UNDERSTANDING

OF THIS MANUAL AND DISHWASHER FUNCTIONS

KEEP THIS PAGE OPEN

AND ITWILL THEN BE EASIER TO FOLLOW.

On/off pilot light.

Start/stop button.

Other function buttons.

Rinse aid level indicator.

Salt level indicator.

Door handle.

Wash-stage visualisor.

Salt level regulator.

Upper basket.

Upper distributor.

Lower distributor.

Filter.

Salt dispenser.

Detergent tray.

Rinse aid tray.

Rinse aid indicator.

Salt indicator.

CONTENTS

Page

Water hardness: ...............................................................27

Wash products:......................................................28-29-30

How to place your crockery correctly:...............31-32-33

Important advice: ............................................................34

Starting the dishwasher: .................................................35

Programme selection: .....................................................35

Wash programme selection:.....................................36-37

How to solve problems:.............................................38-39

"Hello! I am your dishwasher. But

before I start some friendly advice."

CAUTION IN HARD WATER AREAS!

The water from your tap at home is in perfect condition but be careful, it contains lime,

and if we don't keep it under control it could have some harmful effects.

Before beginning,it is essential to find out about the water hardness of your area, that is,

the amount of lime in the water. The Water Company in your area or your Town Council

will give you this information.

But don't worry,in order to prevent any harmful effects from Lime,my water softening

device will always ensure perfect functioning..

Here I am,

to save you from

the washing-up.

These simple adjustments will ensure correct dishwasher function and are important.

ADJUSTING THE AMOUNT OF SALT

This 4-position regulator can be

found on the right hand side of the

dishwasher. Use a coin to select

the right position.

You can then select the right position on the salt regulator.The following table shows you

the correct positions.

O-13 HF (0-7 DH) 14-38 HF (8-21 DH) 39-50 HF (22-28 DH) 51-63 HF (29-35 DH) MORE 63 HF (36 DH)LIME LEVEL

NO SALT

REQUIRED

RESULT OF

THE TEST Positión 1Positión 2Positión 3Positión 4

HFWater hardness given in French degrees.

DHWater hardness given in German degrees.

DISHWASHING PRODUCTS

- Use the funnel provided with the dishwasher to fill the dispenser full of salt (about 1,5

Kg) and then fill with water.

- Always use a spoon to mix it properly.

1. SALT.

So that lime does not cause any harmful effects.

I was fitted with a Water Softener,which takes the lime out of your water and leaves

it clean for dishwashing; for my Water Softener to work you have to put salt in the salt

container. But remember, only if the water hardness requires it.

Remember! Make sure not to use cooking salt, use only special salt for dishwashers

available in all supermarkets.

To ensure I am always in peak working condition I

too need my own specific washing products.They are:

1. SALT

2. DETERGENT

3. RINSE AID

•

Where and how is the salt added first time use?

First you must take out my lower rack. Unscrew the

dispenser cap and take it off .

Important: This operation must be carried out only before the first

wash. Later you only need to top up the salt level.

- Once you have finished filling up with salt and water, make sure

you screw the cap back on securely and that no traces of salt are

left on the bottom of the dishwasher which could leave salt deposits.

ENGLISH

2.DETERGENT. The type of program will give you the quantity required.

•

When do I need more salt?

Don't worry about it.The indicator on your dishwasher will tell you.

•

Models with Luminous Indicator: in the control panel. When the light comes

on,fill the dispenser with salt.

As we have seen in the sections above, it is possible that the water hardness in your area does

not require you to add salt; in that case do not worry if you see the luminous indicator lit.

It is important to remember that you should always fill the salt dispenser before

using the dishwasher, never afterwards.

•

Models with Optical Indicator: This is located

in the cap of my salt dispenser .

The indicator is a green float which in its highest

positionindicatesthat Idonotneed salt. Conversely,

if the float has fallen and, therefore the green colour

is not visible, this means that you must add more

salt.

But lets get to work. First,fill me up with detergent. Do you see the detergent compartment

which is built into the inner door . That is where you put the detergent.

•

How much detergent do I need?

For a non-concentrated detergent in powder

or tablet form;

-For a pre-washed - none.

-For a delicate,economic or rapid wash; 1 measure

of 25 gr. (one and a half level soup spoonfuls or one tablet)

-For a normal or intensive wash,2 measures,1 of 25 gr.in the

dispenser (or one tablet) and another of 5 gr or 15 gr.

(a level soup spoonful or half a tablet) in the inner door.

For concentrated and liquiddetergent follow the detergent manufacturersrecommendations.

3. RINSE AID.

Cleans and adds brilliance.

The principal function of this product is to facilitate drying and prevent water drops

being left on the dishes after the wash, while at the same time giving all surfaces a

brilliant shine.

I have a compartment in the upper part of the inner door ,just to the right of the

detergent compartment.

Turn and take off the cap of this compartment, and add rinse aid up to the indicated

maximum. Be careful that it does not over flow; if this occurs dry the spilt drops with a

cloth so that the wash quality will be correct otherwise over foaming may occur.

•

How is the rinse aid intake regulated?

Once you have filled the compartment, you can adjust the level of rinse aid released by

moving the selector in the dispenser between numbers 1 to 6 (it leaves the factory in

position no. 2).

Before adjustment, I recommend that you judge for yourself by observing the final result

of each wash. If there are water drops or lime stains on the dishes, adjust the selector

to a higher number, conversely adjust to a lower number to reduce the quantity released

if the dishes show white, sticky streaks.

•

When do you have to add rinse aid?

Only when it is indicated on your particular dishwasher model.

•

Models with Transparent-Window Indicator: This is beside therinse aid compartment.

If it is clear it needs rinse aid; fill it taking care that it does not overflow. If it is dark it has

sufficient.

•

Models with Luminous Indicator: When the liquid runs out, this light on the

control panel comes on. This is a clear warning to refill with rinse aid.

•

Where and how is rinse aid added?

ENGLISH

With the basket at its highest level you will be able to put plates

with a diameter of up to 19 cm.in the upper basket and up to

31 cm.in the lower basket.

With the basket at its lowest level you will be able to put plates

with a diameter of up to 24 cm.in the upper basket and up to

26 cm.in the lower basket.

CORRECT LOADING OF THE DISHES

Because you should never play with your food.

To ensure good results, it is very

important toloadthedishes properly

in my racks. Each dish should be

individually located in either basket

with sufficient clearance between

each item for water to pass, this will

guarantee a perfect wash and save

you time and money.

2.Top range basket.

Without having to take the top basket out

of its rails, you can adjust the height of the

basket with a simple hand movement,even

when there is crockery in the basket.

oth to raise and lower the position, pull u

pwards from the centre of the basket.

•

Regulating the height of the basket.

Depending upon your dishwasher model, you will be able to adjust the height of the

upper basket so as to enable you to wash bigger plates.But how? It's easy!

1 Turn the wheel stop. (A)

2 Pull the basket towards you and it

will come out.

3Put the basket back at the height you

have chosen.

4 Turn the wheel-stop back to its

original position.(B)

1.Standard basket.

Regulating the upper basket means you can get

the height you want.
