BASE Varia
User Guide
For more information please go to
www.base.de
2
Prolonged exposure to music at full volume on the
music player may damage the listener’s hearing. Set your
phone volume safely. Use only headphones recommended
by TCT Mobile Limited and its affiliates.
Table of contents
1 Your mobile.............................................................................3
2 Text input ...............................................................................15
3 Phone call..............................................................................16
4 Contacts.................................................................................18
5 Messaging..............................................................................19
6 Email......................................................................................20
7 Getting connected..................................................................21
8 Locate my position using GPS satellites...............................23
9 Data backup...........................................................................24
10 Factory data reset ................................................................25
11 Applications..........................................................................25
This product meets applicable
national SAR limits of 2.0 W/kg. The
specific maximum SAR values can be
found on page 29 of this user guide.
When carrying the product or using
it while worn on your body, either
use an approved accessory such as
a holster or otherwise maintain a
distance of 1.5 cm from the body to
ensure compliance with RF exposure
requirements. Note that the product
may be transmitting even if you are
not making a phone call.
www.sar-tick.com
3
Your mobile
1.1 Keys and connectors
1
Back key
Touchscreen
Home key
Headset connector
Micro USB
connector
Volume up
Volume down
Power key
Menu key
Search key
4
• On Home screen, press to quickly access Settings
menu or Notification panel; to launch quick
search; to manage applications; to customize your
Home screen by adding applications or changing
wallpaper
• On other screens, press to view options list
Short press: Light up the screen; return to the
Home screen or back to the central
Home screen if it is extended
Long press: Enter the recently used applications list
Back to recently used screen
Short press: Lock the screen; light up the screen
Long press: When phone is off, power on the
phone. When phone is on, enter phone
options: Silent mode, Airplane mode,
Power off.
Press to adjust the volume
(in call/media playing mode)
Open search bar for searching within an application,
the phone or web.
5
1.2 Getting started
1.2.1 Set-up
Removing or installing the back cover
Removing or installing front deco
Attention: Front deco is a removable and flexible part, please
take care of it when removing or installing it.
Inserting or removing the SIM card
You must insert your SIM card to make phone calls. Please power
off your phone and remove battery before inserting or removing
the SIM card.
Place the SIM card with SIM1 chip facing downwards and SIM2
chip facing upwards, and then slide it into its housing. Make
sure that it is correctly inserted. To remove the card, press and
slide it out.
For dual SIM model, the SIM1 slot can support both 2G
and 3G network, while the SIM2 slot can only support
a 2G network.
6
Installing or removing the battery
• Insert and click the battery into place, then close the phone
cover.
• Unclip the cover, then remove the battery.
Installing and removing the microSD card
To release the microSD card holder, slide it in the direction of
the arrow and lift it. Then insert the microSD card with the gold-
en contact downward. Finally, turn down the microSD holder
and slide it in the opposite direction to lock it.
Charging the battery
Connect the battery charger to your phone and mains socket
respectively.
To reduce power consumption and energy waste,
when battery is fully charged, disconnect your charger
from the plug; switch off Wi-Fi, GPS, Bluetooth or
background-running applications when not in use;
reduce the backlight time, etc.
Standard charger
7
1.2.2 Power on your phone
Hold down the Power key until the phone powers on. It will take
some seconds before the screen lights up.
Set up your phone for the first time
The first time you power on the phone, you are prompted to set
up your phone in multiple ways: language, input method, mobile
data connection, account setup and synchronization, system
update, etc. You are required to sign into your Google account
to synchronize email, contacts, calendar and other Google
applications.
• Enter your user name and password, then touch Sign in. If
you forget your password, you can go to www.google.com to
retrieve it. If you don’t own a Google account, you can create
one by touching Create.
• Read the setup information on the screen.
• Mark/unmark the check box to choose whether you want to
take advantage of Google’s location service, then touch Next.
• Mark/unmark the check box to choose whether you want to
back up data with your Google account, then touch Next.
• Touch Finish setup.
This initial set up can be skipped and enabled via
Settings/Accounts & sync.
In power on screen without SIM card inserted, you can also
connect to a Wi-Fi network to sign into your Google account and
to use some features.
The first time you insert a new SIM card, you are given the
option to change the default SIM settings.
1.2.3 Power off your phone
Hold down the Power key from the Home screen until the phone
options appear, select Power off.
8
1.3 Home screen
You can bring all the items (applications, shortcuts, folders and
widgets) you love or use most frequently to your Home screen for
quick access. Press Home key to switch to Home screen.
Home screen is provided in an extended format to allow more space for
adding applications, shortcuts etc. Slide the Home screen horizontally
left and right to get a complete view of the Home screen. Small dots
at the lower left and right of the screen indicate which screen you are
viewing.
Status bar
• Status/notification indicators
• Touch and drag down to open
notification panel
Application tab
Touch to open applications list.
Long press to display
thumbnails.
Touch to access Messaging
Touch to access Call log if you have missed call(s)
Search bar
Touch to enter search options:
All, Web, Apps, Contacts, etc.
Touch to enter text search
screen.
Touch to enter voice search
screen.
Touch an icon to open an
application, folder, etc.
9
1.3.1 Using the touchscreen
Touch
To access an application, touch it with your finger.
Touch and hold
To enter the available options for an item, touch and
hold the item. For example, select a contact in Con-
tacts, touch and hold this contact, options list will then
appear on screen.
Drag
Place your finger on the screen to drag an object to
another location.
Slide/Swipe
Slide the screen to scroll up and down the applications,
images, web pages etc. at your convenience.
Flick
Similar to swiping, but flicking makes it move quicker.
Pinch/Spread
Place your fingers of one hand on the screen surface
and draw them apart or together to scale an element
on the screen.
Rotate
Automatically change the screen orientation from
portrait to landscape by turning the phone sideways to
have a better screen view.
1.3.2 Status bar
From status bar, you can view both phone status (to the right
side) and notification information (to the left side). When the
status bar is full, icon will appear, touch to display hidden
icons.
10
Status icons
For dual SIM model, status icons referring to either SIM1 or SIM2
will be identified by a color which you have defined.
GPRS connected Receiving location
data from GPS
GPRS in use Speakerphone is on
EDGE connected Roaming
EDGE in use No signal
3G connected Vibrate mode
3G in use Ringer is silenced
HSPA (3G+) connected Phone microphone
is mute
HSPA (3G+) in use Battery is very low
Connected to a Wi-Fi
network Battery is low
Bluetooth is on Battery is partially
drained
Connected to a
Bluetooth device Battery is full
Airplane mode Battery is charging
Alarm is set Headset connected
GPS is on Signal strength
