Base aire UVC3 Manual de usuario

Installation & Operations ManualUVC3 Pro Ozone GeneratorTel: 1-888-641-8862Web: www.baseaire.comE-mail: [email protected]

Table Of ContentsDevice DescriptionOperationMistakes and shortcomingsMaintenanceTransportation And StorageTechnical AnnexElectrical wiring diagramLimited Warranty0102040506070809

.........................................................

1Device DescriptionThe ozone generator sucks in the surrounding air and performs a discharge procedure. After that, energy breaks the diatomic oxygen molecule into two single oxygen atoms in the form of free radicals.Atomic oxygen recombines with oxygen molecules (A) to form ozone.Due to their metastable bonds, unoxidized ozone molecules will also decompose into oxygen after a period of time without leaving harmful residues. In indoor spaces and under normal conditions, the half-life of ozone is approximately. 30 to 60 minutes. This means that the ozone concentration in indoor air is naturally reduced by at least half every hour.After the reactant oxidizes the oxygen atoms, the ozone molecules will be converted into oxygen molecules.The equipment has been designed and tested in accordance with applicable safety standards and bears the CE mark.Ozone is a very powerful oxidant with high reaction potential. This makes it an effective agent for decomposing destructive substances in the surrounding air. The free radicals bound in the ozone molecule are separated from the molecular compound (B) and react with all substances in the surrounding air, even if these substances are only present in a small concentration. The oxidative decomposition of pollutants in the air and immovable pollutants (for example, on the floor, wall or ceiling) will eliminate and eliminate odors by killing viruses, bacteria, molds, and carcinogenic/allergenic microorganisms.The UVC3 Pro ozone generator of the Baseaire series uses oxygen in the surrounding air as a molecular compound.Structure3251211910148761.Upper shell2.LED display3.Circuit board back cover4.Wind panel5.Bottom shell6.Plastic ﬂoor7.Foot pad8.Ozone generator9.Fan10.Air Inlet11.Suﬃx socket12.Handle

2OperationState Description Of SwitchThe default power-on is the shutdown state, at this time only the 4 borders shown in the figure below are lit (the LCD backlight is turned off after 30s of inactivity).After pressing the "POWER" key to turn on the machine, the default state is the HOLD working state, that is, it keeps running according to the set gear.When setting the timing "CLOCK", a file of 30 minutes, cycle between 00:00 and 02:00, that is, set the running time as the corresponding working time. When CLOCK is valid, HOLD is off and CLOCK is on.Note: When "PERIOD" is not set, PERIOD does not light, at this time it is a single scheduled shutdown.When the button "PERIOD" is set, it switches between 0, 12, and 24. 0 is invalid.12 hours means that the cycle will run again according to the time set by CLOCK after 12 hours of shutdown, which is equivalent to the cycle function.GearsThe default gear for starting is 1 gear, and the fan and ozone are 5 gears.The fan has no thyristor speed regulation, the delay after detecting the zero crossing determines the size of the gear.Ozone is PWM modulated, 16-18K range, 16K is the largest gear, 18K is the smallest.Place the Baseaire UVC3 Pro ozone machine in the center of the room.Make sure that the equipment and connecting cables are not damaged.Connect the power cable and connect the device to the power source. Observe the technical parameters.Set the timer to the required run time.Then turn on the device. The display panel will light up. The cleaning cycle will begin immediately. Once the preset time has passed, the Baseaire UVC3 Pro ozone machine will automatically shut down.1.2.3.4.5.1.2.3.1.1.2.3.Generally, ozone will automatically decompose into oxygen in about an hour. If a person stays indoors for a long time, it is generally subject to not being able to smell the strong ozone smell.Overall WorkflowWhen performing odor neutralization and cleaning cycles, follow the steps below

3WarningThe risk of ozone causing harm to the human body!During use, if you smell ozone outside the working area, the machine must stop working immediately. Ventilate the room thoroughly.!The following values are used as a general reference for determining the processing time:Type Of SmellThe treatment time is in min3Room size< 30 m152020404040-2403603603330 m < Room size< 60 m304040606060 - 480720720DisinfectantCar InteriorFrom Animals, Cooking And WasteBurning / chemicalThe Musty Smell After Water DamageSecondary Effects Of A Burning Smell And Organic MatterAmine / amide (urea), Open-chain Hydrocarbon Compound (e.g. Butyric Acid)Amino Acids / proteins Containing Nitrogen And Sulfur (vomit)

4Mistakes and shortcomingsIf the fault still occurs, please check the equipment according to the following list.The equipment has been checked for normal function several times during the production process.WarningElectric shock is life-threatening!In order to ensure the normal operation and trouble-free operation of the equipment, it must be cleaned and maintained regularly.Before performing any operation on the device, please unplug the power plug from the socket. Do not bypass any electrical safety devices!!ProblemCauseDevice does not workThe fuse is blownThe power plug is damagedSolutionReplace the damaged fuse and/or reopen the fuse. Be careful! The fuse does not need to be repaired, but it must be replaced at any time. In most cases, the fuse is triggered by a serious technical failure. Please authorized service personnel to replace each fuse!Let certified personnel inspect the equipment.

Loud noiseDisconnect the power supply of the device and check whether the power plug and connecting cable are damaged.

Plug the plug into the socket.The connection parameters do not match the technical specificationsCheck the connection to the main line.Connection parameters: 110 V/ 60Hz.Even if the cleaning process has been completed, the odor pollution still persists with the same intensitySend the equipment to a certified professional workshop for repair.

This device is placed in an uneven place.Reactor damagePower is not turned onDamage to the fan and/or its bearings.Place the device on a flat, solid, dry surface.

5MaintenanceElectric Shock Is Life-threatening!Before performing any operation on the device, please unplug the power plug from the socket. Do not bypass any electrical safety devices!Inhalation Of Ozone Can Cause Injury!After the equipment stops running, please wait for a while to ensure that the ozone concentration is lower than the specified value, and then perform maintenance and cleaning.Please perform regular maintenance and maintenance to ensure the normal operation and trouble-free operation of the equipment.The type and frequency of maintenance tasks basically depend on the operating environment and the time and type of use.During use, dust and moisture will accumulate inside or inside the component, which may affect its function and efficiency.In a dusty room or after repairing a fire (high humidity level), inspection and maintenance should be carried out immediately.!The basic principles for determining equipment operation and maintenance intervals:oftenPer hour1-2 times a weekIn an overly dirty environmentIn a humid roomRegardless of the operating conditions described, you should perform maintenance if one or more of the following signs appear:The noise level increases when the fan is runningThe substances produced during the ozone production process gradually disappear.Severely polluted soft magnetic stickersDirty electrodes (identifiable by hissing sound)House CleaningClean the case with a soft, damp, lint-free cloth. Make sure that no moisture enters the enclosure. Prevent electrical components from getting wet. Do not use any harsh cleaning agents, such as cleaning sprays, solvents, alcohol-based cleaning agents, or abrasives to soak the cloth.CleaningWithin the framework of regular maintenance work, it is not only necessary to check the normal condition of the equipment and its accessories, but also to thoroughly clean the equipment and its components.Proceed As Follows:Remove the screws on the dust cover.Disassemble and clean the fan. Always check whether the fan is working properly. If it is only slightly contaminated, you can use a vacuum cleaner or a tap to clean it. If the contamination is serious, clean the reaction generator with a soap solution. After cleaning, insert the fan only after it is completely dry!Remove the shell.Clean the fan1.2.3.

6Transportation And StorageIf you store or transport the device incorrectly, the device may be damaged.Pay attention to information about transportation and storage.TransportationBefore transporting the equipment, please observe the following regulations:Do not drag the device with the power cord during transportation to prevent the device from moving and vibrating to avoid damage to the electrode.Hold the power plug while unplugging the power cord from the power outlet.Turn off the deviceIf the device was in use before, please wait until the timing period is over before transferring the device.After transporting the equipment, please observe the following regulations:Install the equipment in an upright position after transportation.StorageWhen the device is not in use, please observe the following storage conditions:When the equipment is not in use, always disconnect the power supply.Store the Baseaire UVC3 Pro ozone generator in a dry place to avoid the influence of bad weather, and cover it to protect it from invasive dust. Clean ElectrodeThe electrode can be cleaned in the built-in state. Before cleaning the electrode, check for cracks. Do not use damaged parts!Ensure that the equipment is protected from splash water.Do not install this machine near flammable substances or gases.Use a dry (lint-free) or damp cloth to clean the components. After cleaning, make sure that no fibers (fluff) remain on the electrode.Do not use the device before the electrodes are completely dry.The following requirements must be met when installing the Baseaire UVC3 Pro ozone generator:Only use the Baseaire UVC3 Pro ozone generator according to the parameters provided in the "Technical Data" chapter.Make sure to place the device on a dry and vibration-free surface.Make sure that there are no obstructions at the air inlet and outlet.If possible, place the device in the center of the room to ensure optimal air circulation.

7Technical AnnexParameterPowerEnvironmental Humidity RequirementsOzone OutputOperating TemperatureSound Pressure LevelService LifeSize ForDimensions (L×W×H)Minimum Distance From Walls And Other Objects:Top ( a )Rear ( b )Sides ( c )Front ( d )Value110V / 60HZ< 55%130CFM / 220CMH10,000 mg/h 14℉ ~ 95℉< 65db20.000 h1000+ square feet10.2 x 7.1 x 8.7 in20 in20 in20 in20 inAirflow
