Barco R9841770 Manual de usuario

BARCO PROJECTION

LAMP KIT FOR IQPROJECTORS

R9841770 - R9841771

R9841100 - R9841111

R9841760 - R9841761

INSTALLATION MANUAL

05112002 R5976375/01

Barco nv Intelligent Displays

Noordlaan 5, 8520 Kuurne

Phone: +32 56.36.82.11

Fax: +32 56.35.86.51

E-mail: [email protected]

Visit us at the web: www.barco.com

Printed in Belgium

stored in a retrieval system without the prior written consent of BARCO.

Federal Communication Commission (FCC Statement)

This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to Part 15 of the FCC rules.

These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with

the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area may

cause harmful interference, in which case the user will be responsible for correcting any interference.

Trademarks

Brand and product names mentioned in this manual may be trademarks, registered trademarks or copyrights of their respective holders.

All brand and product names mentioned in this manual serve as comments or examples and are not to be understood as advertising for

the products or their manufactures.

Revision Sheet

To:

Barco nv Intelligent Displays

Noordlaan 5, 8520 Kuurne

Phone: +32 56.36.82.11, Fax: +32 56.35.86.51

E-mail: [email protected], Web: www.barco.com

From:

Date:

Please correct the following points in this documentation (R5976375/01):

page wrong correct

R5976375 LAMP KIT FOR IQPROJECTORS 05112002

1. Safety

1. SAFETY

1.1 Safety Guidelines

This procedure is intended for use only by qualified service technicians who have been trained and authorized

by BARCO !

Hot Surface and Risk of Explosion:Switch the projector to stand by and let it cool down for at least 15 minutes

. These lamps consist of a quartz arc tube operating at very high temperature and high pressure (200 bar)

which may explode suddenly. There is a risk of personal injury and property damage from hot quartz arc tube

particles if handled incorrectly.

Risk of Electrical Shock: Power down the projector and unplug the power cord from the wall outlet. Once the

projector is cooled down and the power is off, continue with the replacement procedure.

Lamp Runtime Warning: Do not exceed the indicated maximum total lifetime of the lamp for safe operation in

normal power mode. Do not use it longer ! Always replace the lamp with the BARCO lamp kit for IQ projectors.

R5976375 LAMP KIT FOR IQ PROJECTORS 05112002 1

1. Safety

2R5976375 LAMP KIT FOR IQ PROJECTORS 05112002

2. Kit Content

2. KIT CONTENT

2.1 Contents

Overview

Depending on the Kitnumber ordered the kit may contain 1 or 2 lamps, the lamp power may also differ according to the type of iQ

Projector.

Kitnumber Description Quantity Manual

R9841771 120 W Lamp 1R5976375IQ200

R9841770 120 W Lamp 2R5976375

R9841111 200 W Lamp 1R5976375IQ300

R9841100 200 W Lamp 2R5976375

R9841761 250 W Lamp 1R5976375IQ400

R9841760 250 W Lamp 2R5976375

Image 2-1

Do not touch the cover glass with your fingers. If the lamp is touched, finger prints can be removed by cleaning

thelampwithalcohol.

R5976375 LAMP KIT FOR IQ PROJECTORS 05112002 3

2. Kit Content

4R5976375 LAMP KIT FOR IQ PROJECTORS 05112002
