Nio

Next-generation diagnostic medical display system

Diagnostic conﬁdence

within reach

Innovation at an exceptional value

With the next generation of Nio diagnostic display systems, Barco brings cost-effective

medical imaging to its full potential. Presenting an exceptional combination of

innovation and performance, Barco’s Nio display systems offer radiologists the most

dependable and comprehensive diagnostic display solution on the market.

The proven technology of Barco’s Nio display systems signiﬁcantly improves your

diagnostic reading routine for a multitude of medical imaging applications, including

PACS, MRI, angiography, computed tomography and mammography.

Why choose Nio?

• Cost-efﬁcient, ﬂexible solution for

diagnostic imaging

• FDA cleared display technology

• Complete product line (2MP, 3MP,

5MP) available for a wide variety

of applications

• Perfect color matching between

displays

• Automated calibration

• High-speed image rendering for

maximum workﬂow efﬁciency

Complete peace of mind

Built to deliver maximum peace of mind, Nio display systems come

with a 5 year warranty. In addition, Barco offers an array of dedicated

support services to help you reduce unscheduled downtime and

keep your expenses under control. Barco’s global organization is your guarantee for

professional support, wherever you are, whenever you need it.

High-quality imaging

NIO display systems offer high-brightness, image crispness and an excellent viewing

angle. This makes Nio the ideal solution for a multitude of medical applications and

environments. The energy-efﬁcient Nio display systems come in a new, attractive

design in single-head or matched dual-head conﬁgurations. All Nio systems have a

solid and handy tilt and swivel base and can be used in portrait or landscape viewing

mode.

Nio 5MP in BlueBase or ClearBase viewing mode

Nio 5MP display systems are available in BlueBase and ClearBase viewing modes,

allowing radiologists to select the color temperature best suited for their application.

Both viewing modes are approved for use with digital mammography.

Perfect color matching

Barco carefully color matches the displays in every multi-head Nio display system to

guarantee that the color characteristics of all displays in the system are consistent. This

allows radiologists to perform their work without the distraction of color differences

inherent in LCD panels.

Protective front cover

Nio display systems are equipped with a protective front cover, which protects your

valuable LCD against damage from intensive use in clinical rooms. The cover also

allows for easy and safe cleaning. Its non-reﬂective coating will improve the diagnostic

experience, while keeping reﬂections very low.

Long-term image conﬁdence

Thanks to its high luminance and Barco’s Backlight Output Stabilization (BLOS)

technology, Nio is the ideal solution for a wide range of medical imaging applications.

BLOS guarantees fast power-up and continuously stabilizes the luminance output of

the LCD’s backlight. This signiﬁcantly improves the overall optical efﬁciency of all Nio

display systems and provides long-term image stability.

FDA cleared display technology

Fully committed to quality and diagnostic conﬁdence, Barco offers a Nio display system

family that is fully FDA 510(k) cleared for use in medical imaging applications.

Innovative technology for

complete peace of mind

MediCal QAWeb provides ...

... consistent QA management

MediCal QAWeb provides remote yet secured and HIPAA-compliant access to all display

settings. It ensures effortless diagnostic conﬁdence for the radiologist.

... compliance with the latest QA standards

Diagnostic display systems are permanently monitored for continuous compliance with

DIN 6868-57, AAPM TG18, and JIRA standards.

... effortless asset management

Centralized management of diagnostic displays becomes truly effortless. Asset

management tools provide a comprehensive overview of the workstations connected

to the MediCal QAWeb Server.

... various service levels to ﬁt your needs

Various service levels provide support for improved logistics, service management and

even remote diagnosis and issue solving.

... a unique and innovative business model

The innovative MediCal QAWeb concept suits the needs of every healthcare facility. A

simple pay-as-you-go fee guarantees the continuous quality and performance of all

PACS display systems.

In combination with an optional optical sensor, QA administrators can also perform

DICOM calibrations and DICOM compliance tests with the highest accuracy.

Fully transparent calibration and QA

Nio now comes with an innovative softcopy QA concept that brings a new degree

of transparency to your QA routine. MediCal QAWeb is the industry’s ﬁrst and most

complete secured online service offering, guaranteeing maximum diagnostic conﬁdence

and uptime of your PACS display systems by providing automated DICOM calibration,

Quality Assurance, display asset management, problem solving and reporting. With

MediCal QAWeb, calibration and QA settings can also be changed remotely without

having to be present at the workstation.

High performance

for high expectations

High-speed image rendering

Nio display systems are driven by the high-speed BarcoMed Nio display controller,

featuring Barco’s proprietary AURA technology. With 64-bit PCI performance and

image download speeds up to 230 MB per second, the BarcoMed NIO is the fastest

display controller in its league. The BarcoMed Nio display controller is compatible with

Windows 2000 Professional, Windows XP Professional, Windows 64-bit XP Professional

and Windows Server 2003.

Nio systems can also be combined with the BarcoMed Nio PCI Express display controller,

which provides improved graphics performance and image download speeds up to

320 MB/second. The 10-bit display controller renders the complete data set with

1024 simultaneous levels of gray.

Nio displays Nio 2MP Nio 3MP Nio 5MP

LCD PANEL

Technology TFT AMLCD IPS TFT AMLCD Dual Domain IPS TFT AMLCD Dual Domain IPS

Native resolution 1600 x 1200 2048 x 1536 2560 x 2048

Pixel pitch 0.270 mm 0.207 mm 0.165 mm

Active screen diagonal 540 mm (21.3”) 528 mm (20.8”) 540.9 mm (21.3”)

Active screen width 432 mm 423.9 mm 422.4 mm

Active screen height 324 mm 318 mm 337.9 mm

Viewing angle (H/V, typ) 170° (10:1 contrast) 170° (10:1 contrast) 170° (10:1 contrast)

VISUAL CHARACTERISTICS

Dark room contrast typical 700:1 typical 900:1 typical 800:1

Luminance

500 cd/m2 Calibrated,

900 cd/m2 Max.

target value luminance

500 cd/m2 Calibrated,

1000 cd/m2 Max.

target value luminance

500 cd/m2 Calibrated,

700 cd/m2 Max.

target value luminance

Light output stabilization Backlight Output Stabilization

(BLOS®)

Backlight Output Stabilization

(BLOS®)

Backlight Output Stabilization

(BLOS®)

CONNECTIVITY

Analog video input n/a n/a n/a

Digital video DVI connector DVI connector DVI connector

ENVIRONMENTAL

Operational temperature 0°C to + 40°C

(32°F to 104°F)

0°C to + 40°C

(32°F to 104°F)

0°C to + 40°C

(32°F to 104°F)

Within specs +15°C to +35°C

(59°F to 95°F)

+15°C to +35°C

(59°F to 95°F)

+15°C to +30°C

(59°F to 95°F)

APPROVALS

Safety CE, UL60601, CSA C22.2 No 601.1,

IEC60601

CE, UL60601, CSA C22.2 No 601.1,

IEC60601

CE, UL60950, CSA C22.2 No

60950-1, IEC60950-1

Emission EN 60601-1-2 EN 60601-1-2 EN55022 limit A, FCC level A

Medical FDA 510 (k) FDA 510 (k) FDA 510 (k)

SECURITY

Kensington® lock slot for

added security Included Included Included

Protective cover Included Included Included

Nio display controllers BarcoMed Nio BarcoMed Nio PCIe

SYSTEM REQUIREMENTS

Bus compatibility PCI 2.2 universal

signaling PCI Express® x8

Power consumption < 15 W < 15 W

Form factor 106 x 176 x 16 mm (4.2” x 6.9” x 0.6”) 106 x 176 x 16 mm (4.2” x 6.9” x 0.6”)

Operating system Windows® 2000, XP, X64 Windows® 2000, XP, X64

Platforms Intel® architectures Intel® architectures

CHARACTERISTICS

Graphics accelerator Barco Aura Barco Aura

Display memory 128 MB 128 MB

Look-Up Table 10 bits in/ 10 bits out 10 bits in/ 10 bits out

Pixel depth 10 bit 10 bit

Electrical standard Single Link DVI complying to v1.0 speciﬁcation Single Link DVI complying to v1.0 speciﬁcation

Direct 3D HW support na na

OpenGL® HW support na na

VIDEO OUTPUT

Connectors Two DVI-D connectors Two DVI-I connectors

Supported resolutions Up to 2048x2560 Up to 2048x2560

VGA at boot-up VGA at boot-up

APPROVALS

Approvals and

compliance

FCC-B, CE, EN55022 A,

EN 50082-1

FCC-B, CE, EN55022 B,

EN 61000-6,

IEC 60601-102

ENVIRONMENTAL

Operational

temperature

10°C to 60°C

(50°F to 140°F)

10°C to 60°C

(50°F to 140°F)

About Barco medical

imaging systems

Si gma

In search of continuous improvement

Technical speciﬁcations are subject to change without prior notice

Barco, the global market leader in

visualization solutions for Picture

Archiving and Communications Systems

(PACS), has been developing visionary

medical imaging solutions for more than

15 years. Designed to help healthcare

professionals meet a wide spectrum

of imaging needs, Barco’s solutions

range from premium, high-resolution

diagnostic display systems to innovative

3D visualization and analysis software.

The company’s reputation and

commitment to quality and service have

earned the trust of customers from all

over the world, who partner with Barco

to meet their most demanding imaging

challenges. A strong emphasis on support

is the cornerstone of Barco’s customer

commitment. Barco’s development

and production process is supported

by a worldwide network of research,

development and support services.

Barco’s Medical Imaging division is ISO

9001:2000 & ISO 13485 certiﬁed.

Europe, Middle East, Africa

& Latin America

Phone: +32 56 233 557

sales.medical.eu@barco.com

North America

Phone: +1 678 475 8000

sales.medical.us@barco.com

Taiwan

Phone: +886 2 8221 6868

sales.medical.apac@barco.com

South Korea

Phone: +82 2 2175 8900

sales.medical.apac@barco.com

China

Phone: +86 21 5465 5501

sales.medical.apac@barco.com

Singapore

Phone: +65 6243 7610

sales.medical.apac@barco.com

Australia

Phone: +61 3 9646 5833

sales.medical.apac@barco.com

Japan

Phone: +81 3 3279 0771

www.barcomedical.com

Otros manuales para Nio 3MP

Este manual sirve para los siguientes modelos

Otros manuales de Monitor de Barco

Barco

Barco MDSC-1119 Manual de usuario

Barco

Barco Coronis 3MP LED MDCG-3221 Manual de usuario

Barco

Barco MDNC-2221 Manual de usuario

Barco

Barco MFCD 1218 Manual de usuario

Barco

Barco LCD 5521 V4 Manual de usuario

Barco

Barco MFCD-1219 Manual de usuario

Barco

Barco X Series Guía del usuario

Barco

Barco Coronis 5MP Mammo Manual de usuario

Barco

Barco MDSC-8527 Manual de usuario

Barco

Barco MDCC-4330 Manual de usuario

Barco

Barco Coronis 21-inch Installation & user manua Manual de usuario

Barco

Barco RHDM-1701 Manual de usuario

Barco

Barco Nio systems Manual de usuario

Barco

Barco OLite 510 Manual de usuario

Barco

Barco MRFD-248HB Manual de usuario

Barco

Barco SF-10V Manual de usuario

Barco

Barco Encore Controller SC Manual de usuario

Barco

Barco MDMG-5221 Manual del propietario

Barco

Barco SEER Manual de usuario

Barco

Barco MDSC-1119 Manual de usuario

Barco

Barco Nio 5MP LED Manual de usuario

Barco

Barco MDRC-1219 HB Manual de usuario

Barco

Barco NX--4 Manual de usuario

Barco

Barco DM-1126 Manual de usuario

Manuales populares de Monitor de otras marcas

Linear Acoustic

Linear Acoustic LQ-1000 Manual de usuario

AOC

AOC I2579V Manual de usuario

Gateway

Gateway FPD1520 Manual de usuario

Furuno

Furuno Mu 120c Manual de usuario

Asus

Asus VB171D - 17" LCD Monitor Manual de usuario

Dell

Dell S2230MX Instrucciones de uso

Philips

Philips 107C64 Manual de usuario

Dell

Dell S2409WFP Manual de usuario

EverFocus

EverFocus EN-7517E Manual de usuario

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manual de usuario

Dell

Dell Precision 7680 Manual de instrucciones

LG 50PM1M - - 50" Plasma Panel Manual de usuario

Bosch

Bosch DDU 9 Manual de usuario

Acer

Acer A231HL Manual de usuario

Philips

Philips 86BDL4152T Manual de usuario

NEC

NEC AccuSync LCD5V Manual de usuario

Emay

Emay SleepO2 Manual de usuario

IBM

IBM 6360 Instrucciones de instalación
