MDSC-2242
42-inch full HD large-screen surgical display
Barco's MDSC-2242 is a 42-inch
large-screen surgical display with LED
backlight, featuring full HD resolution.
Purpose-built for the operating room, the
MDSC-2242 can visualize a wide range
of analog and digital video sources,
including HD endoscopic video, room
and boom camera video, patient and
surgery information, radiology and
pathology images, with ultimate detail.
Color-calibrated, artifact-free images
Thanks to its high brightness, high contrast and high resolution, the
MDSC-2242 presents surgeons with accurate, realistic images and
excellent depth perception. It also offers the fastest, lag-free
transmission of surgical images and the highest image quality available
today.
Our next-generation motion adaptive de-interlacing and noise reduction
algorithms, using full 10-bit image processing and a 12-bit look-up table,
make the MDSC-2242 ideal for consulting PACS images in the OR.
Multi-source, multi-display imaging over IP
With its broad input connectivity, the MDSC-2242 offers the highest
flexibility for multi-modality imaging (PiP & PaP), enabling reproduction
of images from multiple sources and to multiple displays in the
integrated operating room.
The 42-inch display is one of Barco's network-enabled surgical displays
and offers integrated functionality (optional) for use with Nexxis digital
OR, ensuring smooth distribution of uncompressed video and data over
the IP network without delay.
MDSC-2242
42-inch full HD large-screen surgical display
Designed for use in the operating room
Barco's MDSC-2242 allows easy cleaning and disinfection thanks to its
anti-reflective protective front glass.
The fan-less design avoids the spread of contaminants in the operating
room.
Product specifications MDSC-2242
屏幕技术 TFT AM LCD with LED backlight
活跃屏幕大小（对角线） 1067 mm (42")
活跃屏幕大小（H x V） 930 x 523 mm (36.6” x 20.6")
屏幕高宽比 16:9
分辨率 2MP (1920 x 1080)
像素度 0.4845 mm
彩色成像 Yes
色彩支持 1073 million (10-bit)
色阶度 72% NTSC
视角 178° Hor / 178° Ver
最大灯光 500 cd/m² (typical)
对比度 4000:1 (typical)
响应率 8 msec (GtG - typ)
Dot钟表 (max) 165 Mhz
伽玛曲线 Native, 1.8, 2.0, 2.2, 2.4, X-ray
机箱颜色 White RAL 9003
视频输入 Video input signals:
-DVI-I Single-Link (Digital & Analog – HDMI video support with HDCP)
-Component Video RGBS / YPbPr (4xBNC)
-S-video (4-pin Mini DIN)
-Composite video (1xBNC)
-3G-SDI (1xBNC)
-DisplayPort (VESA std 1.1a)
-Optional: integrated Nexxis network adapter
Video input formats:
-VGA & DVI: Up to 1920x1200 at 60Hz (reduced blanking)
Maximum pixel clock: 165MHz
Maximum Hor freq: 90kHz
Maximum Ver freq: 75Hz
-Standard PAL and NTSC for S-Video, Composite and Component
-Component YPbPr/ RGBS: HDTV - up to 1080i & 1080p
-SDI Format Supported: 625/25 PAL, 525/29.97 NTSC, 1080i50,
1080i59.94, 1080i60, 720p50, 720p59.94, 720p60, 1080p50, 1080p59.94,
1080p60
-SDI Compliance: SMPTE 425M (Level A), SMPTE 424M, SMPTE 292M,
SMPTE 259M-C, SMPTE 296M, ITU-R BT.656, ITU-R BT.601
-Displayport 1.1a: up to 1920 x 1200 60Hz
视频输出 DVI-D
S-video (4-pin Mini DIN)
Composite video (1xBNC)
3G-SDI (1xBNC)
Visualization modes Picture-in-Picture, Picture-by-Picture, Zoom
演示控制 OSD menu / Infrared remote control / serial RS-232 interface (D-sub 9-pin)
Product specifications MDSC-2242
电力要求（标称） Power source (integrated power supply): 100 – 250 VAC / 47-63 Hz
auto-switch
Power supply for external module: +5VDC ±10% @500mA (max) through
the DVI connectors DVI-in & DVI-out
电力消耗（标称） less than 150 W
OSD语言 English, French, German, Spanish, Italian
无底座维数(W x H x D) 1015 x 608 x 90 mm ( 40” x 23.9” x 3.5”)
无底座净重 24 kg (52.9 lbs)
包装无底座净重 30 kg (66.1 lbs)
安装标准 VESA 600 and 200
屏幕保护 IP21 / Front face: IPx5
Protective, non-reflective tempered glass
推荐模式 Endoscopy, Laparoscopy, X-ray, CT, MR, US
校准 IEC60601 3rd Edition
Approvals/Marking: CE, C-UL-US, DEMKO
Safety (Medical equipment): IEC60601-1, UL60601-1, CSA-C22.2 nr
601-1-M90
Electromagnetic Compatibility: EMC Medical EMC Standards:
IEC60601-1-2, EN55011 /CISPR 11, FCC CFR47 part 15 & 18/Class A
Environment: ROHS-2, REACH, WEEE compliant
温度 Operating: 0° - 40° C / Storage: -20° - 60° C
湿度 Operating: 10% – 90% R.H. / Storage: 5% – 90% R.H.
键盘/鼠标 7-key membrane, side-right
备件 User Manual, Infrared Remote Control, DVI Dual-Link cable 3.0m, Mains
cables (EU (CEBEC/KEMA) & US (Hospital grade UL))
可选附件 wall mount
保修期 3 years
