Barco Encore Controller SC Manual de usuario

Interactive backdrop solution for

content-rich productions

iPresent

iNTELLIGENT

iNNOVATIVE

iNTEGRATED

iNTERACTIVE

iPresent_brochure_herwerking_no_led_04092007:iPresent.qxd 04-09-2007 11:01 Pagina 2

Create a direct,

involving viewer experience

Get rid of your blue screen virtual environment and create a direct, involving

viewer experience which will allow your “talent” to easily interact with live on-

air content with a minimal or no preparation before going live.

Barco’s backdrop solutions bring on-stage video walls in TV studios to the

quality level needed for interactive use in high-demanding, rich-content

productions. Thanks to their high resolution, superior flexibility and excellent

on-camera performance, Barco’s solutions permit great interactive use and

increase accessibility for the audience.

Rear-screen projection sytem

Barco's rear-screen projection system

for backdrop applications consists of

specifically adapted rear-projection

modules, combined with a high

performance show controller and

allows broadcasters to use the wall as

a high-quality alternative to a

traditional onstage video wall or blue

screen.

This complete backdrop solution is able

to show a multitude of video and

graphical windows and produces

smooth transitions from one display

wall layout into another.

iPresent_brochure_herwerking_no_led_04092007:iPresent.qxd 04-09-2007 11:01 Pagina 3

Native ultra-high resolution

The high resolution rear-projection

modules support 3200K color

temperature to match with the studio

lightning, provide excellent on-camera

performance and offer wide viewing

angles for maximum flexibility of

camera positions.

As the display wall can also be used in

normal daylight conditions, it is

possible to switch to 6500K color

temperature.

The high quality projection modules

incorporate dual lamp with hot stand-

by capability and are based on the

latest DLPTM technology.

A built-in second lamp will make you

rely for 100% on the availability of the

iPresent wall when broadcasting live.

iPresent_brochure_herwerking_no_led_04092007:iPresent.qxd 04-09-2007 11:01 Pagina 4

Encore video processor

The Encore Video Processor

incorporates universal inputs that

accept both analog and digital video.

Motion adaptive deinterlacing is

provided for both standard and HD

source video. Incoming videos are

processed by Barco’s proprietary

Athena scaler.

Encore presentation system

The Encore show controller is the most

advanced video processing and

presentation controller on the market

today. The controller provides source

selection, advanced windowing

features, seamless switching, video

effects and integrated control for

professional video presentations.

Encore’s modular, scaleable

architecture allows the controller to

support a wide variety of show

configurations. The controller can

efficiently support from 1-32 screens

with any combination of independent

display or seamless tiled display

elements.

Each mixer can

be used in normal

or split mode

Full machine

control

Joystick for

intuitive image

adjustments

Complete show control

This scaler supports smooth real-time

PIP movements and re-sizing based

upon user specified Key Frames. The

basic Encore configuration supports six

independent PIP or Key images or

three transitioning PIP images.

Seamless transition effects, Z-order

control, window borders, drop

shadows and a variety of keying

effects are fully supported. Two

unscaled background channels provide

a high resolution backdrop that also

supports seamless transition effects.

Down Stream Key (DSK) effects are

supported by a third un-scaled high-

resolution input channel.

Encore Controller LC

iPresent_brochure_herwerking_no_led_04092007:iPresent.qxd 04-09-2007 11:01 Pagina 5

•Up to 12 independent windows with

z-level control

Each window can be resized and positioned in

real time. Flying window effects are controlled

via keyframes

•Expandable from 1 to 32 screens

Encore supports any combination of

single-screen, multi-screen or edge-blended

wide-screen applications

•Native high resolution background

Background transition effects are independent

of the windowing channels

•Special effects

Seamless transitions, window border effects

and advanced keying features are supported

•Modular system architecture

Encore can be expanded as your needs change

and system configurations can be tailored to

efficiently meet application requirements

•Total event management

Encore Controllers provide easy to operate

real-time control

Small Controller Large Controller

Encore Processors supported 6 32

Inputs supported 24 64

Destinations supported 6 32

Available Presets 64 90

Available Destinations 4 8

Available User-defineable Keys None 100

320 x 240 graphic displays 1 2

Light Sticks 2 3

Encore Controller SC

iPresent_brochure_herwerking_no_led_04092007:iPresent.qxd 04-09-2007 11:01 Pagina 6

Barco Control Rooms has become the industry standard in the field of monitoring

solutions for Control & Operation Centers in telecom, traffic, surveillance, public utili-

ties, broadcasting, finance and service providing companies. Barco Control Rooms is

renowned for its flexible, market-specific approach, successfully implemented in over

a thousand control rooms worldwide.

Fully committed to quality, Barco Control Rooms offers full technical support as well

as on-site training. With its head offices in Belgium and Germany, Barco Control

Rooms is represented in more than 30 countries across the globe. With a yearly R&D

effort of 10% of its turnover, Barco Control Rooms ensures it remains at the forefront

of technology.

www.controlrooms.barco.com

Ref. no. R599766 September 2007

Barco Control Rooms is an ISO 9001 registered company.

The information and data given are typical for the equipment described. However any individual item is subject to change without any notice.

Photographs by courtesy of Dubai TV (UAE), London Stock Exchange (UK), Sky News (UK) and VTM (Belgium)

Barco Control Rooms - Belgium

Noordlaan 5, 8520 Kuurne

Phone (32) (56) 368211

E-mail sales.controlrooms@barco.com

Germany Phone (49) (721) 62010

USA Phone (1) (678) 4758000

Brazil Phone (55) (11) 38421656

Japan Phone (81) (3) 57628720

Hong Kong Phone (852) 23970752

www.barcocontrolrooms.com
