Barbie 18062 Manual de usuario
For Ages 5 & Up
Electronic Learning Computer
Product does not have internet or data storage capabilities.
Ultimate
B-Book
Dear Parent/Guardian,
Thank you for choosing the Barbie™UUllttiimmaattee --BBooookk™.
Designed and engineered with extreme precision,
the UUllttiimmaattee --BBooookk™is packed full of learning,
offering stimulating games and activities that
make an invaluable contribution to your child’s development.
Some of the activities to further your child’s skills include language,
mathematics, music, memory and logical reasoning.
The UUllttiimmaattee --BBooookk™provides a dependable and
realistic introduction to computers and
encourages creativity and independent learning.
Learning with Barbie®is so much fun!
BARBIE and associated trademarks owned by and used under license from Mattel, Inc.
© 2002 Mattel, Inc. All Rights Reserved.
Chapter 8 11
Scrolling
Chapter 9 12
Games and Game Codes
Spelling 12
Vocabulary 13
Grammar 14
Keyboarding Skills 15
Math 16
Memory 18
Logic 20
Games 21
Music 23
Tools 24
Chapter 10 26
Troubleshooting
T
Table of Contents
able of Contents
Chapter 1 1
About your
UUllttiimmaattee --BBooookk™
Chapter 2 3
Getting Started
Chapter 3 5
Useful Features and Controls
Chapter 4 7
Game Selection
Chapter 5 8
Game Rules
Chapter 6 9
Two-Player Mode
Chapter 7 10
Make a Selection and Submit Your Answer
The
UUllttiimmaattee --BBooookk™
is supplied with
the following parts.
Please contact your retailer should any
parts be missing.
1 - Unit
2 - Mouse
3 - Mouse Pad
4 - Instruction Manual
1
About your UUllttiimmaattee --BBooookk
™
Features
60 Activities
• 17 Vocabulary/Spelling/
Grammar
• 22 Math/Logic/Memory
•
12 Games/Music
• 9 Tools and Computer
Skills
Multimedia
• Large LCD Display
• Digital Sound
Expandability
• Increase learning potential
with our Barbie™
Expansion cards
(each sold separately)
Chapter 1
Chapter 1
UNIT
LCD
Screen
Expansion Card
Drive
Instruction
Manual
Keyboard
Mouse Pad Mouse
Speaker
Directional Cursor Key
Contrast
Switch
Volume
Switch
ON/OFF
button
2
Unit
Mouse Jack
Expansion Card
Drive
AC Adaptor
Jack
Battery
Cover
Top
Handle
Reset Button
3
Caution
• Do not mix different types of batteries or old and new batteries.
• Only use batteries of the same or equivalent type as recommended.
• Remove all batteries when replacing.
• Remove batteries from the unit if the unit is not going to be used
for long periods of time.
• Do not dispose of batteries in fire.
• Do not recharge non-rechargeable batteries.
• Rechargeable batteries are to be removed from the toy before
being charged.
• Rechargeable batteries are only to be charged under adult
supervision.
• Remove exhausted batteries from the toy.
• Do not short-circuit the supply terminals.
Caution
• The unit must not be connected to a power supply greater than 9V.
• Only use the recommended adaptor.
• The adaptor is not a toy.
• Do not short-circuit the supply terminals.
• Toys liable to be cleaned with liquid are to be disconnected
from the transformer before cleaning.
Chapter 2
Chapter 2
Getting Started The
UUllttiimmaattee --BBooookk™
operates on 4 AA size batteries (not included) or a 9VAC adaptor
(sold separately).
+
-
AC Adaptor Connection
Plug the adaptor into the adaptor jack (center posi-
tive type) at the back of the unit. Plug the adaptor
into a wall outlet.
Please turn off the unit before plugging in the AC
adaptor. Otherwise the unit may be damaged.
Battery Installation
1. Make sure the unit is turned off.
2. Using a Phillips-head screwdriver, open the battery cover at the back of the unit.
3. Insert 4”AA” batteries. (Note the correct polarity: +, - ).
4. Replace the cover.
4
Auto-off
The learning PC will automatically turn itself off after a few minutes of no input from the player.
Mouse Connection
Ensure the unit is turned OFF. Slide back the mouse jack cover at the
back of the unit and plug the mouse into the mouse jack.
To ensure the mouse is kept clean, keep it on a clean mouse pad.
Cleaning and Maintenance
The unit should be regularly examined for damage to the cord, plug, enclosure
and other parts. In the event of such damage, the unit must not be used with the adaptor until
the damage has been repaired. Always disconnect the power supply before cleaning.
Wipe the unit with a dry cloth.
Do not get the unit wet.
Do not dismantle the unit.
Cleaning the Mouse
Turn the mouse upside down and unscrew the small screw to open the cover.
Take the ball out, wipe the ball and the inside of the mouse with a dry cloth to clean out all the dust.
Starting the Ultimate
-Book™
Turn on your UUllttiimmaattee --BBooookk™using the [On/Off] button
located at the upper right corner of the keyboard.
At the end of your session, remember to turn off the power using
the [On/Off] button.
Mouse Jack
5
Chapter 3
Chapter 3
Useful Features and Controls
The Keyboard
The keyboard operates in the same way as a real computer keyboard.
The Mouse
Move the mouse in the direction that you want to move the arrow cursor and click the button on the desired
selection. (See Chapter 7 -- Make a Selection and Submit Your Answer).
The Directional Cursor Key
The directional cursor key is used to make a selection in some games.
Cursor Arrow
The mouse or the cursor key can control the cursor arrow.
The Flashing Cursor
This shows you the position in which the next keyboard entry will appear.
Barbie™Expansion Cards
(sold separately)
Do not scratch or damage the metal contact plate of the Barbie™Expansion Card.
Only insert UUllttiimmaattee --BBooookk™Barbie™Expansion Cards into the Barbie™
Expansion Card drive.
1. Plug the UUllttiimmaattee --BBooookk™Barbie™
Expansion Card into the
Barbie™
Expansion
Card drive on the right side of the unit.
The current activity is interrupted and the Barbie™Expansion Card animation
begins.
After the title screens, a menu screen appears. On this menu screen are two direction
icons and a title of one of the activities included on the Barbie™Expansion Card.
2. Use the arrow cursor or directional cursor button to scroll through the titles.
3. Press [Enter] to play the displayed activity.
Expansion questions for the following activities are included on each Barbie™Expansion Card.
Name of Barbie™Expansion Card Activities
Grammar Card Capitalization, Punctuation, Phonetic Recognition
Spelling Card Spelling Rules, Word Formation, Word Recognition
Vocabulary Card Grammar Rules, Plurals, Antonyms
While the Barbie™Expansion Card is plugged in, only those activities included on the Barbie™Expansion Card
are available. To play other games in the learning PC, unplug the Barbie™Expansion Card.
N.B.: If you purchase an older Barbie™Expansion Card the activities written on the card will not match the
actual expanded activities. The above list is the correct version.
6
Barbie™Expansion
Card Drive
