Baratza Maestro Plus Manual de usuario
Conical Burr Coffee Grinder
Operations Manual
Skilled in the art of grinding
Operations manuals are available in the following languages at
www.baratza.com
English .pdf Spanish .pdf French .pdf
1
Thank you for purchasing the Maestro Plus Conical Burr Cof-
fee Grinder. With the Maestro Plus, it’s now easier than ever
to make professional quality coffee. Below are detailed descrip-
tions of the features that make the Maestro Plus stand out from
other grinders in its class.
Precise, conical burrs
The slow rotating conical burrs of the Maestro Plus preserve
the aroma and avor of the freshly ground beans. Forty steps of
adjustment provide the ne tuning needed for Espresso, Drip, and
French Press Coffee.
Front mounted pulse button
Front-mounted pulse button makes it easy to grind directly into
an espresso brew basket. The discharge chute is designed to
accommodate any home or commercial espresso brew basket.
The Maestro Plus also has a sixty second timer, with segmented
graphics, for easily repeatable grind times.
Innovative burr calibration system
The range of grind and the accuracy of the settings is truly im-
pressive. The Maestro Plus has 40 distinct settings of grind from
Espresso to French Press. An innovative calibration system al-
lows all the manufacturing tolerances of the grinder to be elimi-
nated, resulting in identical, accurate performance from each
grinder. Furthermore the Maestro Plus ring burr is supported
on three points, providing a stable platform for a more accurate
grind.
2
Table of Contents
Introduction ............................................................................................. 1
Table of Contents .................................................................................... 2
Parts Identication .................................................................................. 3
Safety Information.................................................................................... 4
Initial Operation ....................................................................................... 5
Setting the Grind Control ........................................................................ 5
Adjustable Self Timer .................................................................. 6
Front Mounted Pulse Button ....................................................... 6
Care and Cleaning .................................................................................. 7
Cleaning the Housing and Hopper .............................................. 7
Cleaning the Burrs ...................................................................... 7
Remove the Ring Burr ................................................................ 7
Replacing the Ring Burr ............................................................. 8
Replacing the Bean Hopper ....................................................... 8
Automatic Cleaning .................................................................... 9
Troubleshooting .................................................................................... 10
Warranty and Service ........................................................................... 11
Notes .....................................................................................................12
BEFORE USING YOUR GRINDER
Prior to using your Maestro Plus grinder for the rst time you should
wash the bean hopper and ground coffee bin in warm soapy water. See
the section on Care and Cleaning for instruction on how to remove and
reinstall these parts.
3
Whole Bean Hopper
Grind Adjustment Scale
Pulse Button
Adjustable Self-Timer
Ground Coffee Bin
Hopper Lid
Grind Setting Indicator
•
•
•
•
•
•
•
Solid Steel Base
•
Grind Adjustment Ring
Parts Identication
Burr Alignment and Lifting Tabs
Removable Ring Burr
Silicone Seal (cutaway)
Grind Adjustment Tab
Center Cone Burr
•
•
•
•
•
•
•
4
Important Information
Please read the information below very carefully. It contains im
portant tips for the use, the safety and the maintenance and care
of this appliance. Please keep these operating instructions for
future reference.
Use only with 120-Volt current. Use only on alternating current
(AC).
Only clean the grinder housing with a dry or slightly damp cloth.
Do not use this grinder for anything other than its intended use
(i.e. grinding whole roasted coffee beans).
Disassemble your grinder only as directed in the care and
cleaning section of this manual. If you cannot remedy a mal
function check www.baratza.com and visit our FAQ page. If you
call us at 877-701-2021.
Baratza will not accept any liability for damage or injury if the
grinder is used other than for its intended purpose or is
improperly operated or repaired. All warranty claims will be void.
For Your Safety
Do not operate the grinder with a damaged cord or plug, or if
the grinder malfunctions.
Do not leave your grinder unattended while turned ON.
Shut off and unplug the grinder from the electrical outlet when
not in use and before cleaning.
To unplug, grasp plug and remove from the outlet-never pull on
cord.
Keep your grinder out of the reach of children.
Do not immerse the grinder, plug or cord in water or any other
liquid.
Caution
Always unplug the electrical supply cord prior to cleaning.
�
•
•
•
•
•
•
•
•
•
•
•
5
Initial Operation
Place the Maestro Plus Grinder on a level surface. Insert the plug into a
120V AC outlet. Remove the lid from the hopper by lifting off. Pour the
desired quantity of roasted whole coffee beans into the hopper up to a
maximum of 8 oz. Replace the lid. Ensure the ground coffee bin is fully
inserted.
Setting the Grind Control
Slowly rotate the bean hopper
clockwise or counter clockwise
to align the indicator on the bean
hopper with the desired number
setting on the grind scale. Select
the correct grind for the brew pro-
cess you are using. 40 grind set-
tings are available. The settings
shown in the table below can be
used as a general guideline. The actual grind size for a particular setting
will vary depending on many factors, including: degree of roast (light vs.
dark), freshness, humidity, type of bean, oil content, etc. With use, you
will determine the setting that is right for your taste, brewing style and
your favorite beans.
Note: Partially ground coffee beans may remain between the burrs after
the grinder is turned off, adjusting the grind may be easier when the
grinder is running. Avoid running the grinder at very ne settings without
beans as it can damage the burrs.
Setting Type of Coffee Grind
1 to 14 Espresso Fine
16 to 32 Filter / Drip Medium
34 to 40 Press Coarse
6
Adjustable Self Timer
The Maestro Plus is equipped with a 60
second timer switch. Each segment around
the timer represents about 10 seconds of run
time. The grinder switches off automatically
once the time has elapsed. If you want to
interrupt grinding before the time has elapsed,
simply turn the timer switch counterclockwise
until the grinder switches off.
The quantity of ground coffee you need depends on
the type of bean, coarseness of the grind, brewing
method and personal taste. With use, you will nd
the most suitable settings for your personal taste.
Front Mounted Pulse Button
For short duration grinding, the Maestro Plus is
equipped with a front mounted pulse button. It can
be used for grinding directly into an espresso-brew-
ing basket. Remove the grounds bin and position the espresso-basket
inside the grinder directly below the pulse button (see photo). Push
and hold the pulse button to grind. Grinding will stop when the button is
released.
Note: It is important that the espresso
basket is held below the discharge
chute so the coffee powder can free fall
into the basket. Holding the basket up
tight to the discharge chute will cause
coffee to back up and jam your grinder.
7
Care and Cleaning
Cleaning the Housing and Hoppers
Switch the grinder off and remove the plug
from the power supply. Remove any remaining
beans from the bean hopper (it may be easiest
to tip the grinder over and pour the beans into
a bowl.). Remove the hopper by twisting it in a
counterclockwise direction as far as it will turn,
and then lift the bean hopper from the housing.
Wash the hopper, hopper lid, and ground coffee
bin in warm soapy water, rinse and dry.
Caution
Do not put the bean hopper, hopper lid, or
ground coffee bin in the dishwasher. Hand wash
only. Do not immerse the grinder housing in
water.
Cleaning the Burrs
If the grinder is used daily, the burrs should be
cleaned every few weeks. Cleaning enables the
burrs to achieve the most consistent grind pos-
sible. Cleaning also removes coffee oils, which
can degrade the avor of the ground coffee. Do
not wash the burr.
Remove the Ring Burr
Pull the silicone seal off the top of the ring Burr.
Remove the ring burr by lifting it straight up out
of the grinder by the lifting tabs. If the burr does
not lift out, ensure that the grind adjustment tab
is turned fully counterclockwise.
8
Cleaning the Ring Burr
Use the bristle brush (included with your grinder)
to remove any loose coffee residue on the ring
burr, the center cone burr and in the adjustment
area. Vacuum or blow out the residual coffee.
Wash the silicone seal in warm soapy water and
dry.
Replacing the Ring Burr
Replace the ring burr by lining up the red tab on
the ring burr with the red arrow on the adjustment
ring, if it is not aligned rotate the adjustment ring
fully counter clockwise. Wiggle and push down
rmly on the ring burr to ensure that it seats prop-
erly.
Replacing the Silicone Seal
After replacing the ring burr, replace the silicone
seal by lining up the two slots in the silicone seal
with the small tabs on the top of the ring burr and
slide the seal onto the ring burr.
