Baracoda D-Fly Manual de usuario
Data Capture
for Workforce
in Motion
D-Fly User Guide
©Baracoda
TM
– October 2008
Baracoda D-Fly – User Guide v1.6 - 2 -
Data Capture
for Workforce
in Motion
SUMMARY
SUMMARY 2
REVISION HISTORY 3
INTRODUCTION 4
1.
STYLUS 5
2.
BATTERY 5
3.
SWITCHING ON THE READER 5
4.
QUICK START UP GUIDE 6
4.1.
H
OW TO READ BARCODES
6
4.2.
T
HE DIFFERENT USAGE MODES
7
4.3.
T
HE DIFFERENT CONNECTION METHODS
8
4.4.
T
HE DIFFERENT READING MODES
9
4.4.1. T
RIGGER MODE
(
DEFAULT SETTING
) 9
4.4.2. A
IMING MODE
9
5.
STATUS DISPLAY SUMMARY 10
6.
THE DIFFERENT WAYS TO CONNECT D-FLY TO A HOST 11
6.1.1. F
OR USERS
:
C
OMPLETE
P
LUG
&S
CAN HARDWARE SOLUTIONS
11
6.1.2. F
OR USERS
:
SOFTWARE SOLUTIONS
11
6.1.3. F
OR DEVELOPERS
:
B
ARACODA
S
OFTWARE
D
EVELOPMENT
K
IT
(SDK) 12
7.
CONFIGURING YOUR SCANNER 13
7.1.
R
ESET YOUR SCANNER
. 13
7.2.
S
ECURITY
13
7.3.
S
YMBOLOGY
13
7.4.
D
ATA FORMAT
14
7.4.1. B
ARACODA
H
EADER
14
7.4.2. G
ENERAL
P
REFIX
/
S
UFFIX
14
7.4.3. S
YMBOLOGY
P
REFIX
/
S
UFFIX
14
7.4.4. B
ARCODE
I
DENTIFIER
14
7.5.
B
EEPS AND
LED
S
15
7.6.
P
OWER MANAGEMENT
15
7.7.
L
OW BATTERY
15
SAFETY / REGULATORY. 16
LIMITED WARRANTY. 18
Baracoda D-Fly – User Guide v1.6 - 3 -
Data Capture
for Workforce
in Motion
Revision History
Changes to the original manual are listed elow.
Document Date Description
1.0 10 July 07 Initial release
1.1 13 July 07 Correction a out Plug&Scan solutions
1.2 08 Aug 07 Update Safety/Regulatory information
1.3 07 March 08 Update graphic presentation
1.4 16 June 08 Update Safety/Regulatory information
1.5 25 Aug. 08 Add “The different connection method” section
1.6 15 Oct. 08 Modify the MASTER mode section.
Baracoda D-Fly – User Guide v1.6 - 4 -
Data Capture
for Workforce
in Motion
Introduction
The D-Fly is easy to use. Just press the trigger utton in order to switch on the scanner and simply press it again
to scan a arcode. The colours of the LED and the frequency of the flashing LED indicate the status of the
device. The Scanner will “ eep” in different ways and the LED will flash to indicate the status of the D-Fly
scanner. Some examples of D-Fly scanner status changes are “connected”, “good read”, “not connected”, and
more. The “No Data Loss Mode” function on the D-Fly will store the last fifty (50) arcode scans and this mode
can e activated or deactivated y the end user.
Barcodes are transmitted in real time to the remote host device or terminal using Bluetooth wireless
technology. You can download all software updates and additional documentation from our we site:
http://www.baracoda.com/
Baracoda D-Fly – User Guide v1.6 - 5 -
Data Capture
for Workforce
in Motion
1.
Stylus
You can use the stylus with your PDA, Ta letPC or other types of touch screens. The stylus is retracta le and
detacha le for security reasons.
In case of loss of your stylus, contact you locate reseller.
2.
Battery
Recharge the internal attery y using the included AC adapter. The Adapter rating is 5V, 500mA.
When the scanner is charging, the LED is red (solid).
When the scanner is fully charged, the LED is green (solid).
A full recharge (from completely drained atteries) takes approximately 1 hour.
When the original atteries wear out, please contact your Baracoda reseller for replacements.
3.
Switching on the reader
Remem er to fully charge the attery efore first use.
In order to switch on the scanner, please press the trigger utton.
The scanner will switch off after some period of inactivity. The default time period is ten (10) minutes of
scanner inactivity if the device is not connected via Bluetooth, and twenty (20) minutes of scanner inactivity if
the device is connected via Bluetooth and if the user don’t press the trigger utton. These default values can e
modified y the end user.
Stylus
Baracoda D-Fly – User Guide v1.6 - 6 -
Data Capture
for Workforce
in Motion
4.
Quick Start up guide
4.1. How to read barcodes
In order to switch on the scanner, please press the trigger utton.
Proper scanning position
Position the scanner so the light eam fully overlaps and crosses the ar code. The scanner will emit a eep
when the scan is successful.
Baracoda D-Fly – User Guide v1.6 - 7 -
Data Capture
for Workforce
in Motion
4.2. The different usage modes
Real Time mode
In real time mode, the arcode is decoded and transmitted to the remote host without any delay. If the
scanner is not connected, the data is lost (Status Led: red flash).
Real Time mode with No Data Loss option
If the No Data Loss option is activated and if the scanner is not connected or out of Bluetooth range, the
scanner will store the data. It can memorise up to 50 arcodes (UPC format) and later automatically upload
them to the remote host when a Bluetooth connection is esta lished to the host.
Every arcode sent to the host must e acknowledged y the host. If the host fails to send an
acknowledgement, the scanner will continue to transmit the arcode until the host does send an
acknowledgement.
This acknowledgment is disa led in the default settings. It is strongly recommended to set the No Data Loss
mode to ON. This configuration can e set with the BaracodaManager software or with the Programming
Guide.
Additionally, this protocol acknowledgment allows an end user to set an audio acknowledgment indicating that
the arcode has een successfully transmitted to the host.
Baracoda D-Fly – User Guide v1.6 - 8 -
Data Capture
for Workforce
in Motion
4.3. The different connection methods
There are two (2) different way to create a connection from a Host and a scanner:
-Slave mode (b default)
The Host (PC, BaracodaManager, …) is creating the connection onto the scanner.
-Master mode
The scanner is creating itself a connection to the recorded Host Bluetooth address. This connection
attempt is set after a scan of arcode. The configuration of Host address (on which the scanner will set
up a connection to) can e done:
oVia BaracodaManager software (v3.35 min).
oVia scan of arcodes.
All usage modes (Real Time, No Data Loss, Batch) are o viously availa le.
Baracoda D-Fly – User Guide v1.6 - 9 -
Data Capture
for Workforce
in Motion
4.4. The different reading modes
D-Fly has two (2) reading modes. These modes can e changed through oth the BaracodaManager software
and the Programming Guide.
4.4.1. Trigger mode (default setting)
Simply press the trigger when you want to scan a arcode.
4.4.2. Aiming mode
The Aiming mode has een developed for users who need to scan arcodes very close one to another and need
to avoid reading a wrong code. Once in this mode, in order to read a arcode user will have to press the trigger
twice. Pressing it the first time will switch on the eam ut will not switch on the decoder (thus allowing user to
aim at the correct arcode) while pressing the trigger the second time will activate the decoder thus allowing
the D-Fly to actually decode the arcode.
Baracoda D-Fly – User Guide v1.6 - 10 -
Data Capture
for Workforce
in Motion
5.
Status Display Summary
The D-Fly has a LED to indicate all of the functions descri ed elow.
Operating Mode
LED
Status
Description
Batter
Orange/green
Flash
In Charge
Green
Full
Charge completed
Red
Flash
Battery Low
Red
One single long Flash
Battery low, Switch Off
Scan barcode
Green
One Single long Flash
Good re
ad
Orange
Flash
No Host Transmission
Red
Flash
Barcode Lost
Green
Dou le Flash
Connected to Host
LED
