DE60TN HF Drivers

LF Drivers LF Nd Drivers Coaxials HF Drivers Horns

220 W continuous program power capacity

1.4” horn throat diameter

75 mm (3 in) aluminium voice coil

500 – 18000 Hz response

107 dB sensitivity

Shorting copper cap for extended HF response

Specifications

Throat Diameter (1) 36 mm (1.4 in)

Nominal Impedance (2) 8 ohm

Minimum Impedance 8.6 ohm

Nominal Power Handling (3) 110 W

Continuous Power Handling (4) 220 W

Sensitivity (1W/1m) (5) 107 dB

Frequency Range 0.5 -18 kHz

Recommended Crossover (6) 1.2 kHz

Voice Coil Diameter 75 mm (3 in)

Winding Material Aluminium

Inductance 0.14 mH

Diaphragm Material Titanium

Flux Density 1.6 T

Mounting and Shipping Info

Four M6 holes 90° on 102 mm

(4 in) diameter

Overall Diameter 156 mm (6.1 in)

Depth 66 mm (2.6 in)

Net Weight (1 unit) 4.1 kg (9.0 lb)

Shipping Weight (2 units) 8.8 kg (19.3 lb)

Shipping Box (2 units) 210x210x190 mm

(8.3x8.3x7.5 in)

1Driver mounted on B&C ME90 horn

2Also available in 16 ohms, data upon request

32 hours test made with continuous pink noise signal (6 dB crest factor)

within the specified range . Power calculated on rated minimum

impedance.

4Power on Continuous Program is defined as 3 dB greater than the

Nominal rating.

5Applied RMS Voltage is set to 2.83V for 8 ohms Nominal Impedance.

612 dB/oct. or higher slope high-pass filter.
