B&B Electronics McPC MediaLinX Manual de usuario

(

)

International Headquarters

B&B Electronics Mfg. Co. Inc.

707 Dayton Road

Ottawa, IL 61350 USA

Phone (815) 433-5100 -- General Fax (815) 433-5105

Website: www.bb-elec.com

support@bb-elec.com

European Headquarters

B&B Electronics

Westlink Commercial Park

Oranmore, Co. Galway, Ireland

Phone +353 91-792444 -- Fax +353 91-792445

Website: www.bb-europe.com

techsupport@bb-elec.com

Table of Contents

FCC RADIO FREQUENCY INTERFERENCE STATEMENT.........4

WARRANTY ...............................................................................................4

ABOUT THE MCPC MEDIALINX........................................................4

INSTALLING THE MCPC ....................................................................................6

HARDWARE MOUNTING..................ERROR! BOOKMARK NOT DEFINED.

POWERING THE MCPC.....................ERROR! BOOKMARK NOT DEFINED.

LED OPERATION ..............................................................................................9

SPECIFICATIONS.................................................................................11

FIBER OPTIC CLEANING GUIDELINES ......................................12

ELECTROSTATIC DISCHARGE PRECAUTIONS ........................ 13

SAFETY CERTIFICATIONS................................................................14

FCC RADIO FREQUENCY INTERFERENCE

STATEMENT

This equipment has been tested and found to comply with the limits for a Class B computing device, pursuant to

Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference

when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful

interference in which the user will be required to correct the interference at his own expense.

Any changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate

the equipment.

The use of non-shielded I/O cables may not guarantee compliance with FCC RFI limits. This digital apparatus does

not exceed the Class B limits for radio noise emission from digital apparatus set out in the Radio Interference

Regulation of the Canadian Department of Communications.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils

numériques de classe B prescrites dans le Règlement sur le brouillage radioélectrique publié par le ministère des

Communications du Canada.

WARRANTY

Limited Lifetime Warranty

Effective for products of B&B Electronics Manufacturing Company shipped on or after

May 1, 2013, B&B Electronics Manufacturing Company warrants that each such product

shall be free from defects in material and workmanship for its lifetime. This limited

lifetime warranty is applicable solely to the original user and is not transferable.

This warranty is expressly conditioned upon proper storage, installation, connection,

operation and maintenance of products in accordance with their written specifications.

Pursuant to the warranty, within the warranty period, B&B Electronics Manufacturing

Company, at its option will:

1. Replace the product with a functional equivalent;

2. Repair the product; or

3. Provide a partial refund of purchase price based on a depreciated value.

Products of other manufacturers sold by B&B Electronics Manufacturing Company are

not subject to any warranty or indemnity offered by B&B Electronics Manufacturing

Company, but may be subject to the warranties of the other manufacturers.

Notwithstanding the foregoing, under no circumstances shall B&B Electronics

Manufacturing Company have any warranty obligations or any other liability for: (i) any

defects resulting from wear and tear, accident, improper use by the buyer or use by any

third party except in accordance with the written instructions or advice of the B&B

Electronics Manufacturing Company or the manufacturer of the products, including

without limitation surge and overvoltage conditions that exceed specified ratings, (ii)

any products which have been adjusted, modified or repaired by any party other than

B&B Electronics Manufacturing Company or (iii) any descriptions, illustrations, figures as

to performance, drawings and particulars of weights and dimensions contained in the

B&B Electronics Manufacturing Company’s catalogs, price lists, marketing materials or

elsewhere since they are merely intended to represent a general idea of the products

and do not form part of this price quote and do not constitute a warranty of any kind,

whether express or implied, as to any of the B&B Electronics Manufacturing Company’s

products.

THE REPAIR OR REPLACEMENT OF THE DEFECTIVE ITEMS IN ACCORDANCE WITH THE

EXPRESS WARRANTY SET FORTH ABOVE IS B&B ELECTRONIC MANUFACTURING

COMPANY’S SOLE OBLIGATION UNDER THIS WARRANTY. THE WARRANTY CONTAINED

IN THIS SECTION SHALL EXTEND TO THE ORIGINAL USER ONLY, IS IN LIEU OF ANY AND

ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, AND ALL SUCH WARRANTIES AND

INDEMNITIES ARE EXPRESSLY DISCLAIMED, INCLUDING WITHOUT LIMITATION (I) THE

IMPLIED WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE AND OF

MERCHANTABILITY AND (II) ANY WARRANTY THAT THE PRODUCTS ARE DO NOT

INFRINGE OR VIOLATE THE INTELLECTUAL PROPERTY RIGHTS OF ANY THIRD PARTY. IN

NO EVENT SHALL B&B ELECTRONICS MANUFACTURING COMPANY BE LIABLE FOR LOSS

OF BUSINESS, LOSS OF USE OR OF DATA INTERRUPTION OF BUSINESS, LOST PROFITS OR

GOODWILL OR OTHER SPECIAL, INCIDENTAL, EXEMPLARY OR CONSEQUENTIAL

DAMAGES. B&B ELECTRONIC MANUFACTURING COMPANY SHALL DISREGARD AND

NOT BE BOUND BY ANY REPRESENTATIONS, WARRANTIES OR INDEMNITIES MADE BY

ANY OTHER PERSON, INCLUDING WITHOUT LIMITATION EMPLOYEES, DISTRIBUTORS,

RESELLERS OR DEALERS OF B&B ELECTRONIC MANUFACTURING COMPANY WHICH ARE

INCONSISTENT WITH THE WARRANTY, SET FORTH ABOVE.

ABOUT THE MCPC MEDIALINX

Part Numbers: 855-12733-RX, 855-12733-TX

855-15733-RX, 855-15733-TX

The above part numbers must be installed in pairs. As a pair,

the units provide secure data to be passed in one direction

only.

The McPC MediaLinX provides a single conversion between

10/100 Base-T twisted pair and 100 Base-SX/FX fiber. This

device Auto Negotiates speed and duplex on the copper port

and the fiber 100Mbps, FDX. The media converter supports

jumbo frames up to 1916 MTU.

The McPC MediaLinX is a fixed fiber transceiver model, includes

one 10/100Mbps RJ-45 connector and one 100Mbps SC fiber

connector which can support Multi Mode fiber. One model offers

a PCI bracket, the other model offers low profile PCI bracket,

and both must be installed in a PCI slot in a PC. No drivers are

required for this product line; it converts from fiber to copper

and uses a 4-pin peripheral power supply connector.

INSTALLING THE MCPC

Offering plug-and-play operation, the McPC MediaLinX comes ready to

install, utilizing power from the PC’s motherboard. To install the McPC

MediaLinX

Turn off the PC

Remove its cover

Find an empty PCI slot

Align the McPC MediaLinX in the slot

Screw the the McPC MediaLinX into the computer

casing’s bracket

Make sure the McPC MediaLinX does not extend past the edge of

the case

Attach the keyed mini-power connector to the McPC MediaLinX

Attach the male end of the “Y” connector to one of the computer’s

standard size power connectors

Replace the cover

10.

Attach the cables between the McPC MediaLinX) and the devices

that will be connected

AUTOCROSS

Whether using a crossover or straight-through CAT 5 twisted pair cabling, the

McPC MediaLinX will support both types of connections with AutoCross, a

feature that automatically selects between a crossover workstation or pass-

through connection depending on the connected device.

PCI Bracket

Low Profile Bracket

LED OPERATION

Each McPC MediaLinX includes two LEDs, located on the RJ-45

connector. LED functions are as follows for the TX Unit:

FX TX

FX LNK/ACT Glows green when a link is established on the FX (fiber)

port; blinks green when activity is detected on the fiber

port.

Although the copper and fiber ports may not be

physically connected, the FX (fiber) port will always

show a green LED, as the link is forced ON, to ensure

the connection.

TX LNK/ACT Glows green when a link is established on the TX

(copper) port; blinks green when activity is detected on

the copper port.

Each McPC MediaLinX includes two LEDs, located on the RJ-45

connector. LED functions are as follows for the RX Unit:

FX TX

FX LNK/ACT Glows green when a link is established on the FX (fiber)

port; blinks green when activity is detected on the fiber

port.

TX LNK/ACT Glows green when a link is established on the

TX(copper) port; blinks green when activity is detected

on the copper port.
