Baicells Nova430i Manual de usuario
Nova430i
Outdoor 4x250mW eNodeB
Quick Guide
P/N: 1701000170
Document version: 02
All rights reserved © Baicells Technologies Co., Ltd.
1
1.Product Overview
Introduction1.1
Baicells Nova430i is an advanced two-carrier outdoor eNodeB based on LTE TDD
technology, which is developed by Baicells. It is capable of operating in Carrier
Aggregation (CA) or Dual Carrier (DC) mode.
In CA mode, contiguous or non-contiguous channels are aggregated to provide up to 40
MHz bandwidth. This essentially doubles the downlink capacity when the CA 430i is
used with all CAT6/7 user equipment.
In DC mode, each carrier is treated as an independent cell, supporting 96+96 users, and
each supporting 5, 10, 15, or 20 MHz bandwidth. Using a Nova430i in DC mode
simplifies and streamlines the deployment of split sectors.
In addition to having the option to operate Nova430i in either CA or DC mode, HaloB (an
embedded MME option) comes as a default feature in the base software. Baicells's
patented HaloB solution migrates the necessary core network functions to the eNB.
Features1.2
Compact, all-in-one design of internal antenna and integrated GPS
Citizens Broadband Radio Service (CBRS) band covers with dual carrier.
Based on 3GPP international standard TDD LTE technology; provide high speed
data service; support a maximum aggregation peak rate of DL: 220Mbit/s, UL:
14Mbit/s with 2x20MHz spectrum, using CAT 6/7 or higher users.
Support flexible uplink and downlink time slot ratio: 1(2:2), 2(1:3), and high speed
data transmission.
Support 5MHz/10MHz/15MHz/20MHz operation bandwidth.
96 concurrent users per carrier, 96+96 in DC mode.
Support copper (RJ-45) backhaul, flexible to deploy.
PoE++ power supply, only one Ethernet cable required for data transmission and
power supply.
Security services to provide timely protection against potential security risks and
illegal intrusion.
Support simple and convenient local and remote web management.
2
Integration as required, easy to installation and deployment, accurate
coverage and improved network capacity.
Support network management functions, which includes the management,
monitoring and maintenance.
Appearance1.3
The Nova430i interfaces are described in Table 1-1.
Table 1-1 Nova430i Interface Description
Interface Name
Description
ETH
RJ-45 interface (FE/GE)
Used for power supply, debug or data backhaul.
PoE++, complied with IEEE 802.3bt standard
OPT
Reserved optical interface.
The Nova430i interface indicators are described in Table 1-2.
Table 1-2 Nova430i Interface Indicators
Identity
Color
Status
Description
PWR
Green
Steady On
Power on
OFF
No power supply
CELL1
Green
OFF
CELL1 is in inactivated.
Fast flash: 0.1s on,0.1s off
CELL1 is in deactivated.
Slow flash: 1s on,1s off
CELL1 is in activated.
CELL2
Green
OFF
CELL2 is in inactivated.
Fast flash: 0.1s on,0.1s off
CELL2 is in deactivated.
3
Identity
Color
Status
Description
Slow flash: 1s on,1s off
CELL2 is in activated.
ALM
Red
Steady On
Hardware alarm
OFF
No alarm
Technical Specification1.4
1.4.1 Hardware Specification
Item
Description
LTE Mode
LTE TDD
LTE Frequency
Band48, and partial band42,band43
Channel Bandwidth
5MHz, 10MHz, 15MHz, 20MHz per carrier
Output Power
24 dBm per antenna
Receive Sensitivity
-100 dBm
Synchronization
GPS
Backhaul
1 RJ-45 Ethernet interface (1 FE/GE)
MIMO
DL 2 x 2 on each carrier, 2 carriers
Dimension
309mm(H) x 227mm(W) x 104mm(D)
Installation Type
Pole or wall mount
Antenna Type
Built-in 4 high-gain LTE antennas
Horizontal Beamwidth 65±10°
Vertical Beamwidth 17°
Polarization: ±45°
Antenna Gain
13.5 ±0.8 dB
Power Consumption
Typical 20W, MAX 25W
Power Supply
PoE++, comply with IEEE 802.3bt standard
Weight
4.85kgs
MTBF
≥ 150000 hours
MTTR
≤ 1 hour
NOTE: The test method of receiving sensitivity is proposed by the 3GPP TS 36.104, which is based on
5MHz bandwidth, FRC A1-3 in Annex A.1 (QPSK, R=1/3, 25RB) standard.
1.4.2 Global Part Numbers
Model No.
Description
pBS3101S
Band48, 10MHz, 20MHz per carrier, DL 2 x 2 on each
carrier, 2 carriers, Built-in antenna.
4
1.4.3 Software Specification
Item
Description
LTE Standard
3GPP Release 15
Peak Rate
DC
2x20 MHz:
SA1: DL 2x80 (160)Mbps, UL 2x28 (56)Mbps
SA2: DL 2x110 (220)Mbps, UL 2x14 (28)Mbps
2x10MHz:
SA1: DL 2x40 (80)Mbps, UL 2x14 (28)Mbps
SA2: DL 2x55 (110)Mbps, UL 2x7 (14)Mbps
CA
2x20 MHz:
SA1: DL 160Mbps, UL 28Mbps
SA2: DL 220Mbps, UL 14Mbps
2x10MHz:
SA1: DL 80Mbps, UL 14Mbps
SA2: DL 110Mbps, UL 7Mbps
User Capacity
96 concurrent users in single carrier mode
96+96 concurrent users in DC mode
96 concurrent users in CA mode
QoS Control
3GPP standard Quality of Service Class Identifier (QCI),
support SC1
Modulation
UL: QPSK, 16QAM, 64QAM
DL: QPSK, 16QAM, 64QAM
Voice Solution
VoLTE
Traffic Offload
Local breakout
SON
Self-organizing network:
Automatic setup
Automatic Neighbor Relation (ANR)
PCI confliction detection
Network Mgmt
TR-069,SNMP
Maintenance
Support remote/local maintenance, based on SSH protocol
Support online status management
Support performance statistics
Support failure management
Support configuration management
Support local or remote software upgrading and loading
Support log
Support connectivity diagnosis
Support automatic start and configuration
Support alarm reporting
Support user information tracing
Support signaling trace
5
1.4.4 Environment Specification
Item
Description
Operating Temperature
-40°C to 55°C
Storage Temperature
-50°C to 65°C
Humidity
5% to 95%
Atmospheric Pressure
70 kPa to 106 kPa
Ingress Protection Rating
IP66
Power Interface Lightning Protection
Differential mode: ±10KA
Common mode: ±20KA
1.4.5 Regulatory Compliance
FCC Compliance
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Warning:
6
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance
40cm between the radiator & your body.
2.Installation
Install on Pole2.1
The position of the eNB on the pole should be at least 47 inches (120 cm) in height.
After installation, adjust the eNB to a proper angle by adjusting the adjustable bracket.
Install on Wall2.2
NOTE: The wall must bear at least 4 times the weight of the eNB.
