Badger Basket 66109 Guía de configuración rápida

1.0/0716/TG

SUPER ELECTRONIC PLAY

KITCHEN WITH ACCESSORIES

MODEL NUMBER*:

66109

If you need product

parts, see below or Page 2!

Assembly and Use Instructions. Adult Assembly Required.

Read all instructions before use. This manual is part of the

product and must be saved for future reference.

VERSION CODE*:

1.0/0716/TG

* Model and Version Code numbers

are needed if replacement parts

are requested

FOR REPLACEMENT PARTS:

Go to our web site: http://www.badgerbasket.com/parts

Or scan QR code at right with your smartphone

1.0/0716/TG

BEFORE YOU BEGIN ASSEMBLY:

Check all parts. If anything is missing or not satisfactory, please

DO NOT call the store or return the product to them.

Please go online to:

http://www.badgerbasket.com/parts

Most problems are resolved without you needing to leave home.

When contacting us, please have this instruction manual, your

product model number, and your Version Code ready.

Your Model Number is: 66109

Your Version Code is: 1.0/0716/TG

CARE INSTRUCTIONS:

Electronic parts should be cleaned carefully to avoid soaking or damaging the electronics.

All pieces can be wiped clean with lightly dampened cloth and mild detergent. Dry thoroughly.

WARNING - CAUTION

WARNING

ADULT ASSEMBLY REQUIRED. DUE TO THE PRESENCE OF

SMALL PARTS AND SHARP POINTS DURING ASSEMBLY, KEEP

OUT OF REACH OF CHILDREN UNTIL ASSEMBLY IS COMPLETE.

READ ALL INSTRUCTIONS before use of this product. Use only the parts provided by

Badger Basket. Keep instructions for future use. Do not use the product if it is damaged

or broken. Periodically inspect the product to ensure all parts remain tight. This item is a

toy only. No product is a substitute for adult supervision. Always supervise

your child during play. For children ages three (3) years and older.

Never sit on or stand on the Kitchen. This product is not a step stool.

BATTERY SAFETY INFORMATION:

• Kitchen requires nine (9) “AA” size batteries - 3 for TOP/STOVE, 3 for SINK, 3 for CENTER

SUPPORT. These batteries are NOT included.

• Kitchen requires three (3) “AG13/LR44” button cell type batteries for the lights on the ARM. These

batteries are included and installed by the factory. You can replace them as needed.

• Non-rechargeable batteries are not to be recharged.

• Rechargeable batteries are to be removed from the product before charging.

• If removable rechargeable batteries are used, they are only to be charged under adult supervision.

• Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel-cadmium) batteries.

• Do not mix old batteries and new batteries.

• Only batteries of the same or equivalent type as recommended are to be used.

• Be sure to insert batteries with the correct polarities.

• Exhausted batteries are to be removed from the product promptly.

• The supply terminals are not to be short circuited.

• Dispose of batteries safely.

• Remove batteries from the product if it will be unused for an extended period of time.

Badger Basket Company, PO Box 227, Edgar, WI 54426-0227 USA •Web: www.badgerbasket.com

Toll-Free (Mon-Thurs 7:00 AM-4:00 PM CST): 1-800-236-1310

Phone: 715-352-2311 •Fax: 715-352-3163

12 1

OVEN SIDE

F×2

POST

P×7

SHELF SUPPORT

Q×2

CENTER SUPPORT

SHELF

TOP LEFT

TOP CENTER/STOVE

TOP RIGHT/SINK

OVEN BACK

ARM

OVEN CONTROLS

HOOD

RACK

BASE CENTER

FOOT

D×7

OVEN DOOR

BASE LEFT

A BASE RIGHT

U - ACCESSORY SET

U1 - SMALL DISH

×3

U2 - LARGE DISH

×3

U3 - CUP

×4

U8 - POTATO U9-CUCUMBER U10 - EGG U13 - LARGE

FOOD BOX

U7 - BREAD

×2

U14 - CARROT U15 - FOOD CAN U16 - SPOONS U17 - POT

WITH LID

U20 - TOASTER

U5 - BOTTLE

×2

U12 - SMALL

FOOD BOX

U19 - TRAY

U24 - PAN WITH LID

U4 - TEA POT

U11 - LETTUCE

U18 - DISH

RACK

U23 - KNIFEU21 - LADLE U22 - SPATULA

TOOL REQUIRED

(NOT INCLUDED)

WATER FAUCET

IMPORTANT: The O1 and O2

are stored inside the P-POSTS!

O1x7 - LEG

O2x7 - LEG

CONNECTOR

A B C

EF F

3 4

DDD

O1O1

O2 O2

D D

OPTIONAL: Use the (O1) LEGS and (O2) LEG

CONNECTORS to vary the height of the kitchen. You

will find the (O1) and (O2) inside the (P) POSTS.

Remove them when you assemble the kitchen the first

time. Use the (O2) connectors to attach the (O1) legs

to the (D) feet. If not using the (O1) and (O2) now,

store them in a safe place with this assembly manual

for future use.

Kitchen is shown without the (O1)/(O2) legs and

connectors for the rest of assembly. If you are

using the legs/connectors, leave them in place

as you finish the rest of the assembly even though

they are not shown.

J H I

backside

OPEN

backside

OPEN

6 x AA Battery

12 1

backside

OPEN

3 x AA Battery

7 8

The sink can be filled with water and press the faucet

button to make the faucet work. To prevent damage to

the electronics, do not overflow the sink.

12 1

910

11 12

12 1

3 x AG13/LR44 Battery (included and installed at the

factory; replace with fresh batteries as needed).

Use the switch to turn on the flashing lights.

ASSEMBLED WITHOUT THE (O1)/(O2)

LEGS AND CONNECTORS

ASSEMBLED WITH THE (O1)/(O2)

LEGS AND CONNECTORS
