Baby Jogger PERFORMANCE SINGLE Manual de usuario

Important, Keep For

Future Reference

Assembly

Instructions

The Ultimate High Performance Jogging Stroller

Performance Single

Performance Single (Assem) 12/14/04 10:57 AM Page 1

2 1

• To assemble, simply unfold frame and insert the front of handle assembly into Front Tube

Connector and lock together, securing with Snap Locks.

Frame

Front

Tube

Connector

Snap

Locks

• Important, keep this booklet for future reference.

• Accessories which are not approved by the manufacturer or distributor

should not be used.

• WARNING: Prevent serious injury to your child by always using the

safety harness.

• WARNING: Any load attached to the handle affects the stability of the stroller.

• WARNING: It may be dangerous to leave child unattended.

• Always use your wrist strap – these strollers can really roll, and the

wrist strap gives you control if you should slip or fall down.

• The passenger should remain seated (no standing in the stroller).

• Watch out for cars – never assume that a driver can see you and your child.

• Never use Roller Blades while using a Baby Jogger Stroller.

• Intended for passengers up to five years of age weighing no more

than 100 pounds.

• This Jogger seats one passenger.

• WARNING: Recommended weight for seat pocket is 2 pounds and basket

is 10 pounds. Excessive weight may cause a hazardous unstable

condition to exist.

• It may be unsafe to use replacement parts other than those supplied or

approved by the manufacturer.

For the sake of your precious cargo, please read

these warnings before using your Baby Jogger.

Performance Single (Assem) 12/14/04 10:57 AM Page 2

2 3

1 Insert the footplate tab

into the footplate

holder slot

Footplate

3 Using a phillips head

screwdriver, attach

footplate to Jogger frame.

You will need to rest the

Jogger Handle on the floor

in order to get to the

bottom of the footplate.

2 Snap down onto

Jogger frame.

1 To install front wheel, lay

stroller back so handle is

resting on floor. Open the

calipers by flipping the

caliper lever toward the

rear wheels while pinching

calipers together.

2 Insert the front wheel into

the fork tips by aligning

the axle flats with the

fork tip flats.

3 Tighten by turning the

wheel lever while holding

the opposite side.

4 Close the wheel lever

making sure that it is

facing toward the back

of the stroller.

5 Close caliper by flipping

the caliper lever toward

the fork tips.

Front Wheel

Caliper

Lever

Wheel

Lever

Wheel

Lever

Performance Single (Assem) 12/14/04 10:57 AM Page 2

4 5

• To install, gently slide the

wheel’s axle into the hole

in the axle end until you

hear it click into place.

• To remove, simply push in

the spring lock while

pulling out the wheel.

Rear Wheels

• Simply adjust seat straps to

desired degree of recline.

• Pull on strap when you

want to return the seat to

its upright position.

Reclining Seat

Be sure to remove the board from the back of the seat before washing.

Spring

Lock

Spring

Lock

Performance Single (Assem) 12/14/04 10:57 AM Page 4

6 7

Adjusting safety harness:

• Loosen the shoulder straps from their plastic guides.

• Slide the end of each strap through pair of seat loops closest to your child’s shoulder.

Safety Harness

• Slide the end of the shoulder strap back into plastic guide.

Please note: If you feel the straps are too tight, you may adjust their length by sliding the

plastic guides toward the top of the seat.

• Lock both sides of the strap mechanism into the center buckle. To adjust the center strap,

move its plastic guide up or down.

WARNING: Avoid serious injury from falling or sliding out.

Always use safety harness!

Performance Single (Assem) 12/14/04 10:57 AM Page 6

1 Using a phillips head screwdriver, screw brackets to Jogger frame.

2 Fasten upper velcro straps

Canopy

Image shown with seat fabric removed for clearer viewing.

3 Snap to Jogger frame.

8 9

Adjusting the Brake

• If you don’t have good braking action, simply

squeeze the brake handle five or six times. If the

problem persists, loosen the brake’s cylinder ring

to adjust the small ring, and then move the small

ring away from the handle to tighten the cable.

(Please do not over tighten!) To lock the rings,

tighten the cylinder ring against the handle while

holding the small ring in place.

Hand Brake with Parking Button

• To use the parking button feature, simply squeeze the brake handle and push the park brake button.

Rear Wheel

Parking Brakes

• Simply push brake pedal down to engage

brake and lift up to release.

Brakes

Brake

Pedal

Small

Ring

Cylinder

Ring

Parking

Button

NOTE: Some Joggers

are shipped with the

Canopy, Seat and

Basket pre-assembled.

Assembly instructions

are given if any

pre-assemble items are

removed for cleaning

or replacement.

Performance Single (Assem) 12/14/04 10:57 AM Page 8

10 11

2 Fasten the two bottom velcro straps. One is located near

the front of seat and the other is near the footplate.

Seat

1 Snap eight frame snaps

to frame.

• Snap rear basket straps around frame.

• Fasten front velcro strap.

Basket

• Basket installation or removal requires releasing the bottom

section of seat as shown on previous page to reveal velcro strap.

Performance Single (Assem) 12/14/04 10:57 AM Page 10

12 13

Washing

• You can machine wash your stroller’s seat in cold water with a mild detergent.

To minimize shrinkage, simply reattach the seat to the frame to dry.

(Please do not put the seat in the dryer!)

• Be sure to remove the board from the back of the seat

before washing.

• You may clean the stroller frame using a soft, dry cloth, and

an occasional spray of household wax will maintain its

healthy glow.

Wheel Care

• Moisture – especially from the beach – can rust the wheel bearing case.

Spraying regularly with a silicone lubricant will keep your wheels looking healthy.

• Also, if you jog massive amounts of miles, your stroller will benefit from a

yearly visit to the bike shop for wheel alignment. Refer to the number

on the tire wall for the optimum pressure for your tires.

Storing

• Sunshine can fade seat fabric and dry out tires, so storing

your stroller indoors will prolong its good looks. However,

if you do store it outside, using a tarp will protect against

weather wear.

Stroller Care

Steering

• Steering your stroller is simple: it’s balanced to

turn with just a light touch on the handlebar.

For tighter turns, push down on the handlebar

and raise the front wheel to steer.

Wrist Strap

• Make sure wrist strap is around your wrist whenever

your baby is in the stroller. The Baby Jogger is

lightweight and ready to roll – with or without you – and

the wrist strap helps you gain control over your stroller.

In the Dark

• Since we are concerned about the safety of you and your

baby, we recommend that you not use your stroller at

night. However, if you choose to, please attach

reflective strips to the wheel spokes and the seat.

Bicycle lights can also be mounted on the handlebar.

In Motion

Performance Single (Assem) 12/14/04 10:57 AM Page 12

We wish you many happy journeys with your new

Baby Jogger! Your stroller is a great product, and

we are proud to manufacture it. If you have any

questions or comments, please give us a call at.

BJC P/S 08.10.04 (R1–12/04)

1.800.241.1848

Baby Jogger is a Division of Dynamic Brands

2042 Westmoreland Street • Richmond, VA 23230

T: 800.241.1848 • F: 804.262.6277

www.babyjogger.com

Thank You!

Performance Single (Assem) 12/14/04 10:57 AM Page 14
