AVteq EDC 100 Guía de inicio rápido
EASY SETUP GUIDE
EDC 100
AVTEQ.net
800-285-8315
Itemsincluded
x1
x2
A
G
C
DEF
H
Shelf
Body
Base
wheel with
brake
wheel without
brake
1
B
Itemsnotincluded:
-Phillipsscrewdriver
x4
x1
x2 x2 x4
x8
Place the Wheels (wheel
with brake in front) in
Bottom base Bin position
as shown
J
I
B
D
x1 x1
Support
display
5/16" x 2-1/2"
Phllips screw head
- 5/16" x 3/4"
Phillips screw head
- 5/16" washer
5/16" x 3/4"
Phillips screw head
Support Mount
E
ä
ä
ä
ä
FRONT
800-285-8315 AVTEQ.net
2
3
C
F
ä
A
A
H
H
B
ä
ä
ä
Locate the body A
inserting them into the
Base B, using the 5/16" x
3/4" Phillips screw head
(8x) H
Place the Shelf C
between the body A,
using 5/16" x 2-1/2"
Philips Screw head (4x)
F.
FRONT
800-285-8315 AVTEQ.net
4J
G
I
Customer Service
(800) 285-8315
Address:
9003 Governors Row
Dallas, TX 75247
Phone: (214) 905-9001
Place the Support
Display mount I-J at
the top between the
body A, using 5/16" x
3/4" Phillips screw head
and 5/16" washer (4x)
G.
I
