Avtech AVC733 Manual de usuario
User
User’
’s Manual
s Manual
Video Web Server
Video Web Server
733_V0.95
Please read instructions thoroughly before operation and retain
Please read instructions thoroughly before operation and retain it for future reference.
it for future reference.
MPEG
MPEG-
-4
4VIDEO WEB SERVER
VIDEO WEB SERVER
13
Thank-You Note Before You Get Start
First of all, we would like to express our gratitude to you for purchasing this product.
This product is designed to meet your personal needs with our great industry-designing
ability and our everlasting perseverance to the quality of all our products.
This manual will introduce to you how to install this apparatus. Please keep it well for
your future reference.
Now, we would like to invite you to personally experience all of the powerful functions
this product offers.
Firmware:
Firmware:
BootLoader: 0.1.0.0
Kernel: 0.1.2.3
HtmlFile: 0.1.1.6
Mpeg4: 0.1.0.4
Application:
Application: 0.1.2.2
IMPORTANT SAFEGUARD
IMPORTANT SAFEGUARD
CAUTION:
CAUTION:
To reduce the risk of electric shock, do not expose this apparatus to rain or moisture.
Only operate this apparatus from the type of power source indicated on the label. Failure to do so
may cause injury or death by electric shock and invalidates the warranty.
CAUTION
CAUTION
RISK OF ELECTRIC SHOCK
RISK OF ELECTRIC SHOCK
DO NO OPEN
DO NO OPEN
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
This exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature accompanying
the appliance.
CE Mark
This apparatus is manufactured to comply with the radio interference
requirements of EN55022, CISPR 22, and AS/NZS CISPR 22.
TABLE OF CONTENTS
TABLE OF CONTENTS
PARTS AND FEATURES
PARTS AND FEATURES
1.1 FEATURES ------------------------------------------------------------------------------------------------------------
1.2 PACKAGE CONTENTS --------------------------------------------------------------------------------------------
1.3 SPECIFICATION -----------------------------------------------------------------------------------------------------
1.4 PANEL ------------------------------------------------------------------------------------------------------------------
INSTALLATION AND CONNECTION
INSTALLATION AND CONNECTION
2.1 SYSTEM CONNECTION -------------------------------------------------------------------------------------------
2.2 CONNECT DVR TO VIDEO WEB SERVER ------------------------------------------------------------------
2.3 SOFTWARE INSTALLATION ------------------------------------------------------------------------------------
2.4 IP SETTING AND LAN CONNECTION ------------------------------------------------------------------------
2.5 CONNECT VIA INTERNET ---------------------------------------------------------------------------------------
OPERATION GUIDE
OPERATION GUIDE
3.1 SOFTWARE OPERATION -------------------------------------------------------------------------------------
3.2 PLAYBACK OPERATION -------------------------------------------------------------------------------------
3.3 ADVANCED SETTING -----------------------------------------------------------------------------------------
Network --------------------------------------------------------------------------------------------------------
DDNS ----------------------------------------------------------------------------------------------------------
SNTP ------------------------------------------------------------------------------------------------------------
FTP --------------------------------------------------------------------------------------------------------------
Mail --------------------------------------------------------------------------------------------------------------
General ---------------------------------------------------------------------------------------------------------
Peripheral ------------------------------------------------------------------------------------------------------
Account --------------------------------------------------------------------------------------------------------
File Path --------------------------------------------------------------------------------------------------------
Schedule Record --------------------------------------------------------------------------------------------
Trigger ----------------------------------------------------------------------------------------------------------
Information ----------------------------------------------------------------------------------------------------
Log File ---------------------------------------------------------------------------------------------------------
Event Record List -------------------------------------------------------------------------------------------
APPENDIX #1
APPENDIX #1 DVR PIN CONNECTION ----------------------------------------------------------
APPENDIX #2
APPENDIX #2 PTZ PIN CONNECTION -----------------------------------------------------------
APPENDIX #3
APPENDIX #3 IE BROWSER ----------------------------------------------------------------------
APPENDIX #4
APPENDIX #4 DDNS APPLY --------------------------------------------------------------------
1
1
2
3
4
5
6
6
10
11
14
15
15
16
16
17
17
18
18
19
19
20
20
22
22
22
23
24
25
26
--
PARTS AND FEATURES
PARTS AND FEATURES
1.1 FEATURES
1.1 FEATURES
1) Support MPEG4 compression format for real-time video stream
2) Compression format (MPEG4 / JPEG) is selectable for different network bandwidth
and applications
3) Support video / audio recording
4) Support alarm / motion trigger recording
5) Adjustable motion detect sensitivity
6) Whenever alarm system triggered, video streaming or pictures will be uploaded
over FTP,
email as an instant notification.
7) Support 3G & GPRS system for remote surveillance with mobile phone
8) Support TCP/IP, PPPoE, DDNS and DHCP for network connection
9) Support DDNS and function as a router
10) Support NTSC system / PAL system / AUTO detect video input signals
11) Support video access by APs (software) or HTML pages (IE explorer)
12) Full event record list for easy search and quick playback
13) Support schedule recording
14) Support multiple user access levels with security protection
15) Support multiple on-line users (up to 10 users)
16) Support watermark function
17) Support de-blocking and de-interlace function
18) Support watch dog function for automatic network reconnection.
19) ANR will reactivate recording function automatically when network is reconnected
20) Easy to upgrade firmware
1.2 PACKAGE CONTENTS
1.2 PACKAGE CONTENTS
Manual & Quick Start
NOTE :
Please check the package contents to make sure that all accessories are included.
1
Crossover LAN cable Adapter
Video Web Server
Licensed Software AP
1.3 SPECIFICATION
1.3 SPECIFICATION
Support TCP/IP, PPPoE, DDNS and DHCP for network connectionNetwork Connection
Yes
Watermark
Yes
De-interlace
Yes
De-blocking
733
733
SPECIFICATION
SPECIFICATION
Yes
Motion Trigger Recording
3 adjustable factors
Motion Detection
500 mA
Current consumption
DC 12V
Power Source
Password protection
Security
Triggered by GPIO Input, Action: E-mail video/images or
video/images upload to FTP site's specific accounts
Trigger & Action
Video through put : Up to 30(NTSC), 25(PAL) frames/ second
Performance
704x480, 352x240 (NTSC) / 704x576, 352x288 (PAL)
Resolution
TCP/IP, ICMP, SMTP, FTP, HTTP, DHCP, DDNS, PPPoE, SNTP
Protocols
Brightness, Contrast, Saturation and Hue
Video Adjustment
MPEG4 / JPEG
Image Compression
Ethernet (10/100 Base-T)
Network Interface
Yes
RS-485 Port
Yes
Watch dog
2 inputs / 1 output
Alarm Input
1 channel audio input
Audio Input
1 channel for analog & digital products,
1.0 Vp-p 75 composite, BNC
Video Input
Design and specification are subject to change without notice.
2
1.4 PANEL
1.4 PANEL
1) LAN:
Connect Video Web Server to the Internet or LAN with cable or connect
directly to PC with standard pass through cable.
2) VIDEO INPUT (1 channel):
Connect to video source, such as camera or DVR video output.
3) AUDIO INPUT (1 channel):
Connect to audio source, such as camera audio output.
4) ALARM I/O (optional for advanced applications):
Connect control devices, such as PTZ, DVR and external alarm signal input.
5) POWER:
Plug in the supplied power adaptor (12V / 500mA).
6) RESET (at the bottom of Video Web Server):
Press this button to default setting.
3
INSTALLATION AND CONNECTION
INSTALLATION AND CONNECTION
2.1 SYSTEM CONNECTION
2.1 SYSTEM CONNECTION
1)
1) Power:
Power: Connect to DC 12V regulated adapter.
2)
2) Video and Audio Input:
Video and Audio Input: Connect video and audio outputs of camera or DVR…etc.
Take DVR as an example, after connection, set the baud rate and ID of the DVR.
Make sure that the baud rate and ID as same as the settings of the VIDEO WEB
SERVER.
3)
3) Software Installation:
Software Installation: Install the software on PC.
4)
4) IP Setting:
IP Setting: Connect PC with Video Web Server for IP setting (Local Connection).
5)
5) LAN:
LAN: After IP setting, connect Video Web Server with ADSL or CABLE MODEM.
6)
6) ALARM I/O (Optional for advanced applications):
ALARM I/O (Optional for advanced applications):
Connect to control devices, such as PTZ, DVR and external alarm signal input.
[ CONNECTION APPLICATIONS ]
[ CONNECTION APPLICATIONS ]
4
2.2 CONNECT DVR TO VIDEO WEB SERVER
2.2 CONNECT DVR TO VIDEO WEB SERVER
1)
1) DVR Baud Rate and ID Setting:
DVR Baud Rate and ID Setting:
Set the baud rate and ID of the DVR. Make sure that the baud rate and ID as
same as the settings of the VIDEO WEB SERVER.
2)
2) DVR and Video Web Server PIN Connections (Optional for advanced
DVR and Video Web Server PIN Connections (Optional for advanced application):
application):
Connect DVR PIN with VIDEO WEB SERVER PIN.
For detailed PIN connection, please refer to “Appendix #2 ” and “Appendix #3”
PIN 1, 6:
PIN 1, 6: RS485-A, RS485-B
Use RS485-A & RS485-B serial communication signals to control digital units
just like that to control DVR.
PIN 4, 9:
PIN 4, 9: ALARM INPUT
Use PIN 4,,9 to receive the alarm input and then trigger Video Server to send
mail to users for auto e-mail warning system.
PIN 5:
PIN 5: GND
Ground
PIN 2, 3:
PIN 2, 3: NORMAL OPEN, NORMAL COM
Use PIN 2 or 3 to trigger external device to act.
Please see the example picture below for 1CH/4CH DVR.
It’s recommended to solder these joints
5
2.3 SOFTWARE INSTALLATION
2.3 SOFTWARE INSTALLATION
1) Put the attached CD into a CD-ROM and it will start to install application
program into PC.
2) Click “ “ twice.
3) Click “Finish” button to complete the setup.
And users will see the icon “ “ on the desktop.
Note:
Note:
After physical connection, please go to the next two sections for IP address settings.
2.4 IP SETTING AND LAN CONNECTION
2.4 IP SETTING AND LAN CONNECTION
1) Network setting for PC. (This following instruction is based on Win XP O/S.
If the O/S is Win 2000, the setup procedure is similar to that on Win XP O/S.)
Steps:
Start ÆControl Panel ÆNetwork and Internet Connections ÆNetwork
Connections ÆLocal Area Connection Status ÆProperties ÆInternet Protocol
(TCP/IP).
6
