MAGIC DABMUX plus
Ensemble Multiplexer
Training
Version: 3.200 (19 November 2021) Bernhard Seiz
info@avt-nbg.de
www.avt-nbg.de
Support Hotline
+49 911 2571 110
Support-Portal
avt-nbg.zammad.com
Support E-Mail
support@avt-nbg.de
General
Hardware
Features
Web-Interface
Status
Settings
System
Multiplexer
Service-Extraction
Transmitter
Redundancy
Front-Display
System
Maintenance
Troubleshooting
Support
Contents
info@avt-nbg.de
www.avt-nbg.de
Support Hotline
+49 911 2571 110
Support-Portal
avt-nbg.zammad.com
Support E-Mail
support@avt-nbg.de
General
Hardware
Features
Web-Interface
Status
Settings
System
Multiplexer
Service-Extraction
Transmitter
Redundancy
Front-Display
System
Maintenance
Troubleshooting
Support
General
4
Front
DAB Ensemble Multiplexer
2 multicolour LEDs (Power and Status)
TFT colour display (320x240 Pixel) for status and basic configuration
Keypad and combination knob
5
Rear
Redundant power supply
Integrated wide range PSU with power
switch AC 100 -230V +/-10V, 30 W
power input
Connection for an external PSU
DC 12 V, 30 W
Module slot
RST, B1, B2
Reset-and Boot Mode switches
SD-Card slot
To restore the Firmware
2x USB 2.0
For future applications
3 LAN Interfaces
System control exclusively via LAN1
Fan
6
Optional E1 Module
1 x ETI Input, BNC, asymmetric, G.703/G.704
1 x ETI Output, BNC, asymmetric, G.703/G.704
1 x Clock Input 2.048 MHz/10 MHz, BNC, TTL
Bypass-Relay (ETI-Input →ETI-Output)
7
Optional LAN Module
Two additional 10/100 Mbit/s Ethernet-interfaces
3 IP-Addresses can be configured for each interface
VLAN Support
Quality of Service Support
8
DSP-based DAB Ensemble-Multiplexer
Requires 1U in 19“ Racks, Depth: 23 cm
Can be installed in a 19" rack without any space in between
3 x TI high performance DSPs
3 x Gigabit-Ethernet Interfaces
3 IP-Addresses can be configured for each interface
VLAN Support
Quality of Service Support
TI-RTOS operating system by Texas Instruments
Properties
9
DAB Ensemble Multiplexer
According to ETSI EN 300 401 Version 2.1.1
Synchronisation via NTP
25 x Integrated PAD-Inserter
Supported Services:
Dynamic Label, Dynamic Label Plus
SlideShow, Categorized SlideShow
Feed: FTP, HTTP API
4 x Integrated NPAD-Inserter
Supported Services:
SlideShow, SPI (EPG), TPEG
Journaline® (Fraunhofer Licence already
acquired, Implementation in 2022)
Simplified insertion of Station-Logos (SPI)
Feed: FTP, HTTP API, UDP, TCP
Announcement Support & Switching
Interface: HTTP API, UECP (only TA)
Service Linking und Linkage Actuator
Support
Interface: HTTP API, FTP
TII (MNSC)
Non-disruptive configuration
Manual
Scheduler
HTTP API
DAB System Manager
Input protocols
AVTMUX (Secure Streaming)
4 x EDI (Sub-Channel extraction)
NPAD (UDP/TCP)
Output protocols
4 x EDI (ETI) (Simulcast or Multicast)
Features (1)
10
Audio
Up to 25 external Audio-Encoders
can be connected.
Data rates: 16 kbit/s – 192 kbit/s
Control Software
HTML5 Web-Interface
Modern GUI
4 Login Levels
DAB System Manager
Administrator
Operator
Gast
Monitoring
Web-Interface
SNMP v1, v2c
EMBER+
Features (2)
