AVer FB2026
User Manual
Table of Contents
PRODUCT SPECIFICATIONS.............................................................................................1
PACKAGE CONTENTS.......................................................................................................5
PRODUCT INSTALLATION.................................................................................................6
MONITOR SETTING .............................................................................................................6
HARDWARE INSTALLATION....................................................................................................7
POWER OVER ETHERNET (POE)..........................................................................................9
IPASSIGNMENT................................................................................................................10
FINDING IPCAMERA BY USING “NXU LITE RECORDING SOFTWARE”........................................10
FINDING IPCAMERA BY USING “AVER IPCAM UTILITY”.........................................................13
USING NON-DHCPSERVER/ROUTER NETWORK................................................................15
INSTALL ACTIVEXCONTROL...............................................................................................17
USING THE IP CAMERA BROWSER INTERFACE..........................................................19
PREVIEW .........................................................................................................................19
SYSTEM >GENERAL .........................................................................................................21
SYSTEM >GENERAL >MAINTENANCE.................................................................................21
To Upgrade the IP Camera Firmware.......................................................................22
SYSTEM >GENERAL >DATE &TIME...................................................................................23
SYSTEM >USER MANAGEMENT .........................................................................................24
SYSTEM >USER MANAGEMENT .........................................................................................24
SYSTEM >NETWORK SETTING >SETTING...........................................................................26
SYSTEM >NETWORK SETTING >SEVER .............................................................................27
SYSTEM >NETWORK SETTING >DDNS.............................................................................28
SYSTEM >NETWORK SETTING >OTHER 1..........................................................................30
SYSTEM >NETWORK SETTING >OTHER 2..........................................................................32
SYSTEM >NETWORK SETTING >IPV6................................................................................36
SYSTEM >ADVANCE >HTTPS..........................................................................................37
SYSTEM >ADVANCE >SNMP ...........................................................................................39
SYSTEM >ADVANCE >ACCESS LIST ...................................................................................41
SYSTEM >ADVANCE >QOS/DSCP ...................................................................................42
SYSTEM >IMAGE..............................................................................................................43
SYSTEM >IMAGE>OSD ...................................................................................................43
SYSTEM >IMAGE >PREFERENCE.......................................................................................44
SYSTEM >IMAGE>ADVANCED ...........................................................................................45
SYSTEM >IMAGE>PRIVACY MASK .....................................................................................47
SYSTEM >VIDEO STREAM >GENERAL ...............................................................................48
SYSTEM >VIDEO STREAM >STREAM1................................................錯誤!尚未定義書籤。
SYSTEM >VIDEO STREAM >STREAM2...............................................................................53
SYSTEM >VIDEO STREAM >STREAM3...............................................................................55
SYSTEM >AUDIO..............................................................................................................56
SYSTEM >SD CARD.........................................................................................................57
EVENT >ARRANGEMENT >MOTION....................................................................................58
EVENT >ARRANGEMENT >PREFERENCE ............................................................................59
EVENT >SCHEDULE .........................................................................................................62
STATUS INFORMATION .......................................................................................................64
NETWORK CONFIGURATION..........................................................................................65
FACTORY DEFAULT .........................................................................................................67
TROUBLESHOOTING.......................................................................................................68
APPENDIX.........................................................................................................................69
FCC NOTICE (CLASS A)...................................................................................................70
COPYRIGHT......................................................................................................................70
NOTICE..............................................................................................................................70
WARNING..........................................................................................................................70
LIMITED WARRANTY .......................................................................................................71
LIMITATIONS OF WARRANTY .........................................................................................71
DISCLAIMER OF WARRANTY .........................................................................................71
LIMITATION OF LIABILITY ...............................................................................................72
GOVERNING LAW AND YOUR RIGHTS ..........................................................................72
1
Product Specifications
Full HD 1080P Real Time
Vari-focal Lens 3-10.5mm
3D+2D Digital Noise Reduction
Power over Ethernet (PoE)
H.264/MJPEG Compression
SD card backup (SD card is not included)
2-way audio
Digital Wide Dynamic Range
Power over EthernetAvailable
SDK for software integration
IR LED Built-in 25MAvailable
Free bundled 32-CH AVer NXU Lite recording software
IP66
2
Specifications
Hardware
CPU
Multimedia SoC
RAM
256MB
Flash
16M
Image sensor
1/2.7”Megapixel CMOS Sersor
Mini. illumination
Color : 0.38 Lux @ F1.4
B / W: 0 Lux @ F1.4(IR LED on)
Lens type
Vari-focal Lens 3~10.5mm @F1.4
ViewAngle
33.1°(W)~90.7°(T) Horizontal
18.7°(W)~49.1°(T) Vertical
I/O
1 DI / 1 DO
Audio
G.711(64K) and G.726(32K,24K) audio compression
Input : 3.5mm phone jack
Output: 3.5mm phone jack, Support 2-way.
Power Over Ethernet
Yes
Power Consumption
DC 12V Max: 2.76W(IR Off); 4.80W(IR On)
PoE Max: 3.84W(IR Off); 6.72W(IR On)
Operation Temperature
-10°C ~ 50°C
Dimensions
83mm ()x 117mm (H)
Weight
1000g
Network
Ethernet
10/ 100 Base-T
Network Protocol
IPv6, IPv4, HTTP, HTTPS, SNMP, QoS/DSCP, Access
list, RTSP, TCP/ IP, UDP, SMTP, FTP, PPPoE, DHCP,
DDNS, NTP, UPnP, 3GPP, SAMBA, Bonjour
3
System
Video Resolution
1920x1080@30fps,
1280x960@30fps,1280x720@30fps, 800x600@30
fps,640x480@30fps, 320x240@30fps,
176x144@30fps
Video Adjust
Brightness, Contrast, Hue, Saturation, Sharpness,
AGC, Shutter Time, Sense-Up, D-WDR, Lens
Distortion Correction, Flip, Mirror, Red Gain and Blue
Gain, De-noise, Anti-fog
Triple Streaming
Yes
Image snapshot
Yes
Full screen monitoring
Yes
Privacy Mask
Yes, 5 different areas
Compression format
H.264/ M-JPEG
Video bitrate adjust
CBR, VBR
Motion Detection
Yes, 3 Different Areas
Triggered action
Mail, FTP, Save to SD card, Samba,DO
Security
Password protection, IP address filtering, HTTPS
encrypted data transmission, QoS/DSCP
Firmware upgrade
HTTP mode, can be upgraded remotely
Simultaneous connection
Up to 10
Micro SD card management
Recording trigger
Motion Detection, IP check, Network break down (wire
only),Schedule
Video format
AVI, JPEG
Video playback
Yes
Delete files
Yes
4
Web browsing requirement
OS
Windows 7, XP
Microsoft® IE 8.0 or above
[Note] Please enable “Compatibility View”while using
IE 10 or above.
Hardware Suggested
Intel Dual Core 2.53G, RAM: 1024MB, Graphic card:
128MB
Mobil support
iOS 4.3 or above,Android 1.6 or above.
*SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
