Aven SharpVue Plus Manual de usuario
Aven
MANUAL
SharpVue Plus
SharpVue XT
2
Table of contents
System information 3
Systems and accessories 3-4
Unpackaging and assembly 5
Remote control 6
Pair the remote to the system 7
On screen magnification display 7
Safety information 7
Warranty 8
Aven Software 8
-Toolbar 9-11
-System set up 11
-Measuring 11
-Calibration 12
-Change colors 14
Technical facts 14
Contact Aven technology 15
3
System information
SharpVue Plus and SharpVue XT are both standalone high definition optical inspection
systems.
The camera system has functions such as: Autofocus On/Off, Possibility to Change focus
when Autofocus is off, Artificial Cross, built in LED lighting, Save Image/Video directly to your
PC with the software, Digital zoom on/off. (No led lighting in SHARPVUE XT).
Both systems can store image without a PC direct to memory stick.
It is possible to choose any monitor that has a DisplayPort or use an adaptor.
When used with a computer you can just install the included Aven Software and
make measurement, drawing and much more.
Systems and Accessories
This manual is valid for the following systems:
SharpVue Plus 30x. part number: 26700-136. Has a 30x optical zoom camera and a 3D lens
SharpVue XT 30x. part number: 26700-137. Has a 30x optical zoom camera and a 3D lens
Continue to next page for accessories...
4
360 Tilt Table have part number: 26700-135-TTB. For a perfect angle of the object you are
working with under your system, try our stabile and easy maneuverable tilt table. The table
plate is covered with an ESD secure material that prevents static damage to the object you
are working on and helps you keep it in place.
With the tilt table, a 4D lens gives you different options due to height of object.
Diameter: 9 in | Height: 57 mm | Weight: 2.3 lbs
360 Tilt Table With Riser have part number 26700-135-TTBV2. For a perfect angle of the
object you are working with under your system, try our stabile and easy maneuverable tilt
table. The table plate is covered with an ESD secure material that prevents static damage to
the object you are working on and helps you keep it in place. Includes a metal height
adjustment base.
Diameter: 9 in | Riser Height: 16 mm | Total Height: 73 mm | Weight: 2.3 lbs
X-Y Gliding Stage have part number: 26700-135-XYTB. A Steady X-Y Gliding Stage for
easy control of the magnified object. This X-Y Gliding Stage is small and easy to move.
The table plate is covered with an ESD-secure material that prevents static damage to
the object you are working with. Size: Horizontal Movement: 190.mm Vertical
Movement 235 mm Table Dimension: 420x410 mm. Weight=5kg
5
Unpacking and assembly
The system is delivered with the following items:
Inspection system
Remote control
Power Supply
Monitor Cable (Displayport)
PC cable (USB –USB mini)
Aven Software on a USB memory stick
Place the camera unit on proper location. Place the X-Y Gliding Stage or tilt table if you
prefer to use one. Connect the monitor cable from the monitor to the camera unit.
Connect the power cable from you power supply. You are now ready to start.
If you wish to use a computer. Connect your computer with the USB cable (USB mini to
SharpVue Plus/SharpVue XT, USB to computer). You need to install the included Aven
software from the USB memory stick. Read more under Software Page 8.
Picture of the Connectors.
You can now start the system by pressing the button at the top of the camera unit or
backside on the SharpVue XT, you can also turn the LED lamp on/off with the button on the
back of the SharpVue Plus.
6
Remote Control
Z+ Zoom in. Z - Zoom out. Increase brightness. Decrease brightness. Press Func short
and autofocus will go off / on. When autofocus is off, & will change functions to adjust
focus as a manual focus. OK change magnification to wide and show an artificial cross.
Next press on OK the magnification goes back to previous magnification. A quick press to
Mode camera will change between color and greyscale.
A longer press on the Mode button stores pictures to the memory stick if its inserted.
A long Press to the Func button and you will get the menu to be shown.
Brightness up
Brightness down
Zoom in
Zoom out
7
Menu:
Lens: Your choice of lens, default is +3.
Show Zoom: How long the OSD ZOOM info will last on the screen.
Show Brightness: How long the OSD Brightness info will last on the screen
Zoom Speed: Controls how fast the system will zoom.
Screen Diagonal: Set this after your monitor.
Show clock: OSD for date and time on the screen.
Digital Zoom: Default off, can set the Digital zoom to On.
Aspect ratio: Default 16:9, can change to 16:10
Adjust date / time: Set time and date.
Show USB device: Gives information about the amount of free space left on the memory stick.
Digital Zoom: Turn Digital Zoom on / off, Off is default.
If your system is connected to Ethernet, the IP address will be showed on the bottom of this menu.
Pair the remote to the System.
If you need to change battery in the remote you need to pair the remote to the system. Hold the
remote on the back of the System while the power is on then press the OK button on the remote
for 5 seconds. When the light on the remote starts flashing red –the remote is paired.
On screen magnification display
If you are using the “Show Zoom”, notice that you should choose what Lens and what monitor
you are using to get the values correct.
Safety information
Never connect the product with power if it has been exposed to water, rain or other liquids.
Contact your supplier before using the product.
Place the power cord in such a way that no pinching occurs.
If the product is moved from cold too warm, condensation may occur. Wait about 30 minutes
before using the product.
When placing the product choose a stable table with at least 45 cm depth.
If no normal function can be set after troubleshooting, turn power off and contact your local
supplier.
8
Warranty
2 years warranty for factory faults.
Aven Software.
Installation: SharpVue Software only works on Windows 10. We recommend that your PC has
1920x1080 as minimum resolution, if you use the PC with an external monitor, don’t use
Extended or dual mode unless the resolution on both Displays are the same.
Click on the SharpVue Appxbundle file, accept the Camera, Mic, folder request.
You can now start the SharpVue application. If a previous version been installed, we
recommend that it uninstalled before a new one is installed. On some Windows 10
PC’s it can be necessary to set the settings to Allow sideload apps.
9
Toolbar (Live picture)
Unlock / Lock the autofocus.
Manual focus.
Show Crosshair.
Freeze / Unfreeze.
Color / Grey.
Digital Zoom On/Off.
Go to Draw mode, measure, compare images, overlays and more.
Settings menu, see more under section on Page 16.
Show Live image fullscreen, no buttons on screen
Zoom (Wide) or (Tele)
Save Image As.. You can choose where to save your pictures.
Preset and recall preset. Set with Right click, Recall with left. Store Zoom value.
Record video.
Save image to jpg, files will remember indexed and store zoom data.
10
Toolbar (Draw mode)
Draw a rectangle. No measure values
Draw a Circle, with measure value. 3 clicks will measure the circle
Draw line only vertical, with measure value.
Draw line only horizontally, with measure value.
Draw line free Horizontal / vertical with measure value and angle from horizontal base.
Cancel , marked with a Index ( #) for what action to cancel .
Save image with information.
Open a golden image to use a comparison, will reload zoom data if used.
Full screen, (Default)
Compare Live image with a stored image (golden) horizontal.
Compare Live image with a stored image (golden) Vertically.
Compare live image vs stored golden sample, images will swap, swap time adjustable.
Zoom, zoom in the editable image, see more section page 14.
Insert Text. See more on page 13
Mark image with dots.
