Avaya S8700 Series Manual del propietario

May 2003

Job Aid

Issue 3

Installation Tool Information—

S8700 Media Server

Avaya™ S8700 Media Server with MCC1 or SCC1 Media Gateway

This job aid provides information on tools required for installing an Avaya™ S8700 Media Server with MCC1 or

SCC1 Media Gateway. It covers the following items:

■Magneto Optical Server Tool

■Cable Pass Through Kit

Magneto Optical Server Tool

The Magneto Optical Server Tool (MOST) is used to transfer translation files from a Magneto Optical disk to an

Avaya S8700 Media Server. This tool is used only when migrating call processing translations on a DEFINITY

ECS to an Avaya S8700 Media Server with MCC1 or SCC1 Media Gateway. Refer to Magneto Optical Server Tool

(MOST) for information on connecting the tool to the media server.

The MOST tool is not shipped with every system but should be available locally.

The MOST tool consists of:

■External Magneto Optical drive

■SCSI PCcard

■External SCSI cable

Job Aid

May 2003 Issue 3

1. S8700 Media Server

2. SCSI PCcard

3. PCMCIA Connector

4. SCSI Cable and connector

5. Bottom connector on Magneto Optical drive

6. On/Off button

7. External Magneto Optical drive

Figure 1. Magneto Optical Server Tool (MOST)

1234

ON ECE

+5VDC

OUT

U1 U2

1 2

cadlopt KLC 081402

Job Aid

May 2003

Issue 3

Ordering Information

Cable Pass Through Kit

The Cable Pass-Through Kit is used to facilitate passing cables from the back to the front of an Avaya SCC1 Media

Gateway. This kit is used for the following cable types and situations:

■The ribbon cable used to connect to the TN2312AP IPSI circuit pack in the SCC1 media gateway B and to the

TN775D Maintenance circuit pack in SCC1 media gateway A. (See Using the Cable Pass-Through Kit for the

ribbon cable)

■The CAT5 Ethernet cable that connects to the faceplate of the TN2312AP IPSI circuit pack and a port on the

Avaya Ethernet switch. (See Using the Cable Pass-Through Kit for the CAT5 cable)

For specific installation instructions refer to the Install IPSI and Maintenance Circuit Packs subection within the

Migrating to the S8700 Media Server section on the S8700 Media Server Library CD.

The Cable Pass-Through Kit is similar in construction to the pass-through tool in the Fiber Pass-Through Kit that is

used during ATM installations.

Table 1. Magneto Optical Server Tool

Comcode Description

700226269 Magneto Optical Server Tool

Job Aid

May 2003 Issue 3

Figure 2. Using the Cable Pass-Through Kit for the ribbon cable

CLK

ALARMS

EMERTR

MAJ

MIN

WRN

ACK

OFF

AUTO

cadsrib2 KLC 032602

602

Job Aid

May 2003

Issue 3

Figure 3. Using the Cable Pass-Through Kit for the CAT5 cable

Ordering Information

Table 2. Cable Pass Through Kit ordering information

Comcode Description

700219413 Cable Pass Through Kit

CLK

ALARMS

EMERTR

MAJ

MIN

WRN

ACK

OFF

AUTO

cadscat2 KLC 032602
