Avantree BTHS-NB17 Manual de usuario

Product Overview 1

Ear Fin Fitting 1

Specications 1

Basic Operations 2

LED Indicators 2

Pair and connect 3

To add another device 4

Reconnect 5

ANC Function 5

Clear the headphone pairing history 6

Charging 6

Troubleshooting 7

BTHS-NB17

User Manual

··················································································································

···························································································································

·····················································································································

··························································································································

························································································································

·····································································································································

··········································································

··································································································································

········································································································

Wireless ANC Neckband

Earphones

ANC

Product Overview

Ear Fin Fitting

Specications:

• BT Version: 5.0

• Proles Supported: HSP, HFP, A2DP, AVRCP

• Operation Range: Up to 10 meters, Class II

• Charge Voltage: DC 5V / 0.5-2A

• Charging Time: About 1.5 hours

• Playtime: 9 hours with ANC on, 13 hours with ANC o

• Standby Time: Up to 160 hours

• Battery Capacity: 220mAh

• Noise Canceling: 28dB

• Frequency Range: 20Hz~20KHz

• Headphone Size: 27x15x430mm

• Net Weight: 38g

ANC

Basic Operations

Power ON/OFF

Enter Pairing mode

Manually re-connect

Play/Pause

Volume up/down

Previous/Next Track

Answer/End a call

Reject a call

Voice Control(Phone feature:

Siri, Google assistant)

Press and hold for 2S

From o, hold for 4S until LED ashes BLUE and RED alternately

Click once

Click / once

Press and hold / for 1S

Click once

Press and hold for 1S

Double Click

Function

General

Music control

Call control

Operation

LED Indicators

Working Status

Power ON

Power OFF

Pairing in progress

Connected

Disconnected

Low battery

Charging

Fully charged

BLUE LED on 1S

RED LED on 1S

RED and BLUE LED ashes alternately

BLUE LED ash twice every 5S

BLUE LED ash once every 1S

RED LED ashes twice every 5S

RED LED steady on

RED LED o

LED Indicator

“Power ON”

“Power OFF”

“Pairing”

“Connected”

“Disconnected”

“Battery Low”

Voice Prompts

Pair and connect

1. Get NB17 into PAIRING MODE - From o, press and hold for 4S until LED ashes BLUE and RED alternately.

(Fig.1)

(First-time use: it will automatically enter pairing mode once powered on)

2. Activate Bluetooth on your device, search and select “Avantree NB17” to connect. Once connected, LED will

ash BLUE twice every 5s, you will hear a voice prompt “Connected”.(Fig.2-4)

(Fig.1)

ashes BLUE and RED

hold 4S

connected

L R

4:30 4G

Settings Bluetooth

Bluetooth

huawei

Avantree NB17

Bose Bluetooth Audio... Not Connected

Now discoverable as “iPhone(2)”

MY DEVICES

OTHER DEVICES

To pair an Apple Watch with your iPhone, go to the

Watchapp.

4:30 4G

Settings Bluetooth

Bluetooth

huawei

OPPO R9s

Avantree NB17 Connected

Now discoverable as “iPhone(2)”

MY DEVICES

OTHER DEVICES

To pair an Apple Watch with your iPhone, go to the

Watchapp.

Bose Bluetooth Audio... Not Connected

(Fig.3) (Fig.4)(Fig.2)

1. Connect the rst device as above.

2. Set NB17 into PAIRING MODE again and repeat steps 1&2 above to connect the 2nd device.(Fig.5-7)

3. Turn on the Bluetooth of rst device, it will automatically reconnect. Otherwise, please connect it on the phone

manually. (Fig.8-9)

Note: This feature only works for two mobile devices, such as cellphones and tablets. We do not recommend using

this feature with PCs or Bluetooth transmitters.

To add another device

ashes BLUE

and RED

hold 4S

L R

PM 2:00

Bluetooth

Penetration Test

Allow peripheral devices to be checked

AT&T

T-mobil

Connected

MoreSeach Devices

Devices Name

Received Devices

My Devices

Available Equipment

Avantree NB17

AB Shutter3

iPhone(2)

Honor 9

PM 2:00

Bluetooth

Penetration Test

Allow peripheral devices to be checked

AT&T

T-mobil

No target device found? View possible

causes No target device found? View possible

causes

MoreSeach Devices

Devices Name

Received Devices

Available Equipment

Avantree NB17

AB Shutter3

iPhone(2)

Honor 9

(Fig.5) (Fig.6) (Fig.7)

4:30 4G

Settings Bluetooth

Bluetooth

OPPO R9s

huawei

Avantree NB17 Connected

Bose Bluetooth Audio...Not Connected

Now discoverable as “iPhone(2)”

MY DEVICES

OTHER DEVICES

To pair an Apple Watch with your iPhone, go to the

Watch app.

PM 2:00

Bluetooth

Penetration Test

Allow peripheral devices to be checked

AT&T

T-mobil

Connected

MoreSeach Devices

My Devices

Available Equipment

Avantree NB17

AB Shutter3

iPhone(2)

No target device found? View possible

causes

(Fig.8) (Fig.9)

Normally, when turning headset on, it will automatically reconnect to the most recently paired device. Otherwise,

please try to manually reconnectby clicking once.(Fig.10-11)

Reconnect

Hold for 1S to activate / deactivate the ANC function. White LED will be steady on when ANC function is

activated.(Fig.12)

Note: This feature is unavailable when the battery of the headphone is low.

White LED

ANC Function

4:30 4G

Settings Bluetooth

Bluetooth

OPPO R9s

huawei

Avantree NB16 Not Connected

Bose Bluetooth Audio... Not Connected

Now discoverable as “iPhone(2)”

MY DEVICES

OTHER DEVICES

To pair an Apple Watch with your iPhone, go to the Watch

app.

(Fig.10)

Hold 1s

(Fig.12)

(Fig.11)

Make sure NB17 is powered on. Press and hold and together for about 5S until RED and BLUE LED ash

simultaneously for about 2S(looks pink). It will then automatically power o to indicate a successful reset. For

next use, please manually turn it on and it will automatically enter pairing mode.(Fig.13-14)

Clear the headphone pairing history

When the LED ashes RED every 5S and you hear a voice prompt “Battery Low”, you should fully recharge the device

for about 1.5 hours. The LED will remain RED while charging and turn o when charging is complete.

You can plug it into a USB wall charger/car charger (DC 5V / 0.5-2A) or computer USB port that is powered on.

(Fig.15-16)

Charging

Looks PINK

L R

hold 5s

(Fig.13) (Fig.14)

every 10s

low battery

DC 5V / 0.5-2A

(Fig.15) (Fig.16)

Troubleshooting

- Ensure NB17 is in pairing mode correctly - LED will ash BLUE and RED alternately.

- For Smart phone, tablet and PC

• Turn the Bluetooth feature o and then on.

• Delete your Avantree NB17 headphones from the Bluetooth list on your device. Try to pair it again.(Fig.17-18)

- Set Avantree NB17 as the default device or output device on the PC. (Fig.19)

Headphones do not pair with Bluetooth device

• Clear the headphones pairing history

• No sound with PC?

4:30 4G

Settings Bluetooth

Bluetooth

OPPO R9s

huawei

Avantree NB17 Not Connected

Bose Bluetooth Audio... Not Connected

Now discoverable as “iPhone(2)”

MY DEVICES

OTHER DEVICES

To pair an Apple Watch with your iPhone, go to the Watch

app.

4:30 4G

Bluetooth Avantree NB16

Forget This Device

(Fig.17) (Fig.18)

Sound

2 - Avantree NB17

Select a playback device below to modify its settings:

Ready

Bluetooth Audio

Ready

Realtek High Denition Audio

Default Device

Playback Recording Sounds Communications

Congure Congure

Default Device

Default Communication Device

Set Default

Speakers

(Fig.19)

- When using NB17 to make voice calls through apps, please set NB17 Hands-Free as Microphone and Speakers

device.(Fig.20)

- Pay attention that ANC function is controlled independently by button. ANC function will not turn o even if the

earphones are powered o. When ANC function is on, white LED will stay white. You need to manually turn ANC

o if you don’t want to use it, or the playtime will not last as long as described.

• ANC LED steady on even when the headphones are o

(Fig.20)

Settings

Test video

Audio

Speakers

Microphone

Teat audio

O

(Avantree NB17)
