General Notes
Copyright
AT-Automation Technology GmbH, 1998-2020. This user guide is protected by copyright
and all rights are reserved. No part of this document and no part of the software shall be
reproduced, distributed, edited or translated into another language or computer
language by any means, electronic, mechanical, photocopying, recording, or otherwise
without consent in writing from the owners, AT-Automation Technology GmbH, Hermann-
Bössow St. 6-8, 23843 Bad Oldesloe, Germany.
Disclaimer
While care has been exercised in the preparation of this document to ensure that it is
fully correct and comprehensive, the owners assume no responsibility for errors or
omissions. Neither is any liability assumed for damages resulting from the use of the
information contained herein. No license is granted under any patents or patent right of
AT –Automation Technology GmbH.
Trademarks
All trademarks mentioned in this user guide are the property of the respective
companies.
Safety Instructions
Symbols and Notes
The following general safety rules must be taken into account during installation,
operation and maintenance. Failure to do so may cause damage to the operator, the
camera or the environment.
Warning Symbols and Safety Instructions
Warning
Only use the system inside buildings, installations or rooms.
Make sure that all cables are routed without risk of tripping.
Only connect the power cord to the mains voltage after finishing the
installation of the system.

April 28th, 2020
Page 5 of 49
Read the operating instructions before using the system.
Make sure that the operating staff has read the operating
instructions and understood the contents!
Observe the safety instructions.
Observe the locally applicable safety and accident prevention
regulations.
In case of uncertainty contact the manufacturer.
Caution: Hot Surfaces
As this device can generate temperatures above 50°C, there is a
risk of burning on the inside of the blackbody radiator (Blackbody).
Further Symbols
CE marking, see Declaration of conformity
RoHS
RoHS mark, the system complies with RoHS Directive 2002/95 / EC
WEEE mark, the system is registered according to the WEEE directive
under the WEEE-Reg. No. DE 13042735
Safety information
General remark

April 28th, 2020
Page 6 of 49
User Instructions
Installation Instruction
Mobile Package
The Mobile Package is designed to enable you to use the system in a large variety of
locations. Its compact design allows the system to be set up and dismantled quickly. The
system can be easily transported in the transport case in a vehicle or shipped as
required. To start with the system setup, take out the individual components from the
case. Check that they are complete by using the list provided in the scope of the
delivery.
Scope of delivery

April 28th, 2020
Page 7 of 49
The first layer contains the following listed components
A. Calibration certificates for camera and blackbody
B. Monitor
C. Sticker and sign set
D. Mouse and keyboard
E. Blackbody with control unit
A
B
C
D
E

April 28th, 2020
Page 8 of 49
The second layer contains the following listed components
F. Monitor stand with holder
G. Micro HDMI to HDMI cable
H. Power supply unit with USB-C for the embedded visualization PC
I. Power supply unit with M12 round connector for the infrared camera
J. Power supply unit with USB -> Micro USB cable to connect the user display
K. User display in the holding frame with infrared camera
L. Switchable multiple socket strip
M. Camera focus tool
N. 2 tripods in transportation case
F
G
H
I
J
K
L
M
N

April 28th, 2020
Page 9 of 49
System Setup
The system setup is divided into 4 steps. We recommend doing the installation with two
persons.
Step 1: Tripod
Set up the two tripods and make sure that you have a secure stand. To do this, unfold
the tripod legs and lock them at the central locking screw.
Step 2: Blackbody and user display with infrared camera
Mount the blackbody and the user display with the pre-installed adapter pins on one of
the two stands. To do this, insert the adapter pin into the holder provided at the top end
of the stand and fix it by tightening the wing screw. Attach the signs to one of the two
stands so that they are clearly visible to the user and approaching persons.

April 28th, 2020
Page 10 of 49
Wing screw
Central fixing
screw
