Audiothingies DoubleDrummer
User manual firmware version 1.0.3
Overview
Specifications
The DoubleDrummer is a 12-voice drum sound generator. It is divided into 4 main sections
The synthesis section
This section features 6 different instruments bass drum, snare drum, tom tom, clap, cowbell and hi
hat.
Each of these 6 instruments has been fine tuned to provide a wide range of sounds within a limited
set of 6 parameters per instrument for the best possible user experience.
The sample player engine
With 6 instruments and 56 internal drum sounds, these can be useful to provide more natural
sounding sounds that can be more difficult to synthesize within a limited parameter set, such as
cymbals for example.
But they’re also great for those “in ur face” 80’s kick and snare sounds.
Audiothingies DoubleDrummer user manual 2
The mixer
Each of the 12 instruments has its own mixer settings, with drive, bitcrusher, pan, main volume and
fx send level.
The FX’s
2 “AUX SEND” effects are available delay and reverb. Each one of the 12 instruments can be setup
to use either one or the other.
A multi FX containing samplerate reduction, bitrate reduction and a 2-pole lowpass filter is available
on the master bus.
Audiothingies DoubleDrummer user manual 3
Signal Flow
Audiothingies DoubleDrummer user manual 4
12 Instruments
6 Synthesis BD, SD, TT, CP, CB, HH)
6 Sample players 56 user samples – S1 to S6)
INSTRUMENT GENERATOR
MASTER BUS
Stereo Audio Outputs
PLATE REVERBFILTERED DELAY
MASTER FX
Drive, Samplerate reducer, Bitcrusher & Lowpass Filter
INSTRUMENT MIXER & FX
Drive, Bitcrusher,
Pan, Level, FX Send Level
AUX FX SEND SELECT
Delay or Reverb)
Front panel
On the front panel you will find
•2 x 24 characters LCD screen – Black on white
•6 encoders with pushbuttons
•9 pushbuttons with their associated LEDs
•1 volume knob
Audiothingies DoubleDrummer user manual 5
Rear panel
On the rear panel, from left to right on the above picture
•Audio outputs (use left output when using mono)
•MIDI connectors
•USB port – used for USB MIDI communication with a USB host and firmware updates (a
SYSEX file sent over USB MIDI)
•9V DC input socket (Center positive polarity, 2.1mm plug, 200mA minimum)
•Power switch
Audiothingies DoubleDrummer user manual 6
Quick start
1. Connect audio outs to a mix table, turn the volume knob fully clockwise.
2. Connect a MIDI keyboard / sequencer into the DIN MIDI Input.
3. Power the DoubleDrummer with a 9V DC, center positive, 2.1mm plug PSU
1. Play C1 on MIDI channel 1, you should hear the bass drum playing
The other notes triggering the different instruments are listed in the MIDI Map section of this
manual
2. Press Load
3. Turn encoder 6 or press encoders 4/5 to navigate thru the patches. Press Load again to load
selected patch, press Home to cancel and return to previously loaded sound.
Audiothingies DoubleDrummer user manual 7
Using the DoubleDrummer
Navigating pages
How to navigate throughout the DoubleDrummer architecture?
Parameters are mapped across different sections accessed by pressing a corresponding button on the
front panel.
When a section has several pages, you access them by successively pressing the same button several
times. When you are on the last page, it returns to the first one.
For example, pressing FX several times will make you travel the following pages DLY > REV >
MFX > DLY > REV > MFX etc.
Some sections (the ones labeled in red under the white round buttons) are accessible by
simultaneously pressing Home [shift] + another button. For example [shift] + FX will take you to the
System page.
The encoders can be pushed to access menus that are shortcuts to specific parameters (level/pan/fx
send/fx type and mute).
Editing parameters
The LCD provides up to 6 parameters to edit depending on the menu you are currently editing
Simply use encoders 1-6 to change their corresponding parameter value.
TIP: the encoder acceleration value can be changed in System menu, page 2
TIP2: you can temporarily disable the acceleration and lower the sensitivity of an encoder by
pressing [shift] while turning the encoder
Audiothingies DoubleDrummer user manual 8
Main page | HOME
This is where you land when you power your DoubleDrummer
P001 drv smp bit cut
InUrFace 15 0 0 120
You get the program number and name as well as shortcuts to 4 different parameters.
HOME page parameter shortcuts
These 4 parameters can be set per preset, among the FX (delay, reverb and master fx) parameter set.
To change these parameters, press and hold FX button
encoder en3 en4 en5 en6
assign smp bit cut res
Use encoders 3 to 6 to change the displayed parameter
Trigger activity Viewer
You also have access to a second screen by pressing HOME a 2nd time, this screen replaces program
number and name with a trigger activity viewer
[][][][][][] drv smp bit cut
[][][][][][] 15 0 0 120
The 6 trigger viewers on the upper line are tied to the synthesis instruments activity whereas the 6
trigger viewers on the bottom line show the S1 to S6 instruments activity.
Audiothingies DoubleDrummer user manual 9
Instrument parameters
Bass drum | BD
This instrument generates classic bass drum sounds.
B -P atk dcy hrm bnd tim
64 100 48 32 64 32
•BD-P pitch
•atk amount of clic transient
•dcy decay time
•hrm odd harmonics amount
•bnd pitch mod amount
•tim pitch mod decay time
Snare drum | SD
This instrument is capable of generating snare drum sounds, and is very versatile especially thanks to
its noise-related parameters.
S -P -decay- nze col emp
64 50 72 100 80 0
•SD-P tone pitch
•decay1 tone decay time
•decay2 noise decay time
•nze noise level
•col noise color
•emp noise emphasis (filter resonance)
Audiothingies DoubleDrummer user manual 10
