The RC-LGI Interface allows easy integration of conventional infrared repeating systems with LG/Zenith flat panel

televisions.

TECHNOLOGY

INSTALLATION MANUAL

RC-LGI Interface

INSTALLATION

With the power off to both the infrared connector block and the television, connect the RC-LGI interface following

the wiring diagram below. Once all connections are made. Power can be restored to all the units. The system

sensitivity can be adjusted via the trim pot on the input side of the RC-LGI.

2006 - 11/22/06

WIRING DIAGRAM

12VDC POWER SUPPLY

TO IR INPUT ON BACK

OF TELEVISION

TO EMITTER JACK ON

IR CONNECTING BLOCK

ADJUSTMENT POT

FOR SYSTEM FINE TUNING

OUT TO IR TARGET(S)

RC-LGI

(IRB-4 shown not included)

OUT

WARRANTY

Your AUDIOPLEX TECHNOLOGY RC-LGI Interface is covered by a Lifetime Warranty against defects in workmanship

and materials. Any defects will be remedied without charge for labor or parts.

Damage incurred by shipping or accident is not considered to be a defect, and not covered by this warranty. AUDIOPLEX

TECHNOLOGY is not responsible for defective operation caused by abuse or by modification or service by an unauthorized

person or agency.

The unit must be properly installed and operated according to instructions for the warranty to apply. Any necessary servicing

must be done by AUDIOPLEX TECHNOLOGY. The products must be returned expenses prepaid, with written authorization

from the company. The unit must be shipped with the proof of purchase and in original carton and packing material to avoid

damage.

AUDIOPLEX TECHNOLOGY

404 GWH PO BOX 440 MELVIN VILLAGE, NH 03850 800-257-2077 FAX: 603-544-8901
