AudioBahn ABP101N Manual de usuario

SINGLE SUB ORTED SYSTEM

ABB101N / ABB121N

OPERATING INTSTRUCTIONS

PLEASE RETAIN MANUAL FOR FUTRE USE AND REFERENCE

QUALITY, RLIABILITY, & PURE BLISS

Features and Specifications



ABB121N

Single 12"

Ported Bass System

ABB101N

Dual 10"

Ported Bass System

High Quality MDF Construction

Black Carpeted Covering

Extended Low Frequency Slotted Ports

Audiobahn Embroidery

12” IMPP Cone with EPDM

Rubber Surround

45 oz. Strontium Magnet

2" 4 Layer Voice Coil

Bumped Back Plate

Extended & Vented Pole Piece

Gold Binding Post Terminals

Power Handling: 400 Watts RMS

Sensitivity: 94.5dB

Frequency Response: 25Hz-1kHz

Impedance: 4 Ohm Mono

Dimensions:

High Quality MDF Construction

Black Carpeted Covering

Extended Low Frequency Slotted Ports

Audiobahn Embroidery

10” IMPP Cone with EPDM

Rubber Surround

45 oz. Strontium Magnet

2" 4 Layer Voice Coil

Bumped Back Plate

Extended & Vented Pole Piece

Gold Binding Post Terminals

Power Handling: 300 Watts RMS

Sensitivity: 93dB

Frequency Response: 29Hz-1kHz

Impedance: 4 Ohm Mono

Dimensions:

14 7/8"(H) x 18 7/8"(W) x 9 7/8"(D)

Wiring And Hookup

The box is wired in a mono 4 ohm operational mode. Looking at the back of the box you will see the

terminals. The left terminal is negative (-) and the right terminal is positive (+) for each set.

The mounting position of your ported enclosure will have a great effect on the sound performance produced.

TRUNK MOUNTING

Placing the box in the trunk provides a good overall performance.

PASSENGER COMPARTMENT MOUNTING

Placing the box in the passenger compartment provides optimum sound, but reduces the area for passenger

seating, if not taking it all away.

Facing the box towards a wall will increase the low frequency sounds. When mounting in a trunk or back of

any vehicle, you will tend to get much better performance and better low end frequency response when you

face the box towards the back of the vehicle.

MOUNTING

Mounting or securing the box is a good idea. This will prevent the box from sliding around. If it does move

around, it can hit obstacles, and wires can come loose and damage the system. It is also good to have it

secured in case of an accident so it is not thrown into any passengers.

You can mount the box by attaching brackets and fastening it with screws or bolts straight to the frame or

other solid piece in the car. You can also use velcro strips. Attach the sticky side of the velcro to bottom of

the box, and the carpet in the vehicle should hold it in place.
