AudioBahn AVDVD10P Manual de usuario
TRAY LOADED MULITI-FORMAT DVD
PLAYER WITH REMOTE
AVDVD10P
INTRODUCTION
FEATURES
SAFETY INFORMATION
CONTRASTS BETWEEN DISC TYPES
SUPPORTING FUNCTIONS OF DISC
3
6
6
7
8
INSTALLATION 5
WARNINGS 4
OPERATION AND USE 8
FRONT PANEL DIAGRAM 9
BACK PANEL DIAGRAM 10
WARNING / DISCLAIMER 23
WARRANTY 24-25
CLEANING DISCS 6
Table of Contents
Table of Contents
2
SYSTEM CONNECTIONS
REMOTE CONTROL DIAGRAM
ADVANCED SETUP
PLAYING MP3 FILES
10
12
16
19
VIEWING KODAK PICTURE CDs 20
TROUBLESHOOTING 21
SPECIFICATIONS 22
BUTTON LOCATIONS AND FUNCTIONS 13
Warnings
4
CAUTION
RISK OF ELECTRIC SHOCK. DO NOT OPEN
To reduce the risk of electric shock, do not remove cover (or back).
No user serviceable parts inside. Refer servicing to qualified
service personnel.
The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert user to
the presence of uninsulated dangerous voltage
within the product enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of impor-
tant operating and maintenance (servicing) instruc-
tion in the literature accompanying the appliance.
Special note regarding use of player in vehlclrs
We strongly advise against using the player while driving.
Most countries and states have laws which prohibit or sev-
erely restrict the use of the player in vehicles while driving.
WARNING:
ATTENTION: TO PREVENT ELECTRIC SHOCK,
MATCH WIDE BLADE OF PLUG TO
WIDE SLOT, FULLY INSERT.
LASER: This Digital Video Disc Receiver employs
a Laser System. To ensure proper use of
this product, please read this owner s
manual carefully and retain for future
reference. Should the unit require maint-
enance, contact an authorized service
location-see service procedure.
Use of controls, adjustments or the perfor-
mance of procedures other than those
specified may result in hazardous radiation
exposure.
To prevent direct exposure to laser beam,
do not try to open the enclosure.
Visible and invisible laser radiation when
open and interlocks defeated.
DO NOT STARE INTO BEAM
'
DANGEROUS HIGH VOLTAGES ARE
PRESENT INSIDE THE ENCLOSURE.
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT OPEN
THE CABINET. REFER SERVICING
TO QUALIFIED PERSONNEL ONLY.
Installation
5
1. Fix the unit horizontally.
2.Hangtheunit.
The device
Fixed face
Fixed face
The device
NOTE: Must attach the device well.
3.Fixthe4Pcs screws.
Bottom of the device
4. The positions of rubber foot.
Put the square plug into socket (note the direction of the lug when
connecting) and connect RED cable with VBAT
NOTE: Must pay attention to power s polarity and connecting
cable colour to avoid damage the device or other equipment and
'S +, black cable
VBAT'S- or ACC'S- and yellow cable with ACC'S+.
'
5. Connecting with power.
DC+
DC+GND -˄˅
+
-
VBAT
DC OUTPUT
12-24V˄˅
RED
BLAC K
+
-
YELLOW
ACC
DC OUTPUT
12-24V˄˅
input power DC 12V-24V. If connected to power of alternator
only, when alternator off, the car DVD player will standby.
The device has 2Pcs mounting hardware and 4Pcs screws.
NOT USED
Features / Safety / Cleaning
6
Features
10-bit video D/Aconverter, 96KHz/24bit audio D/A
converter, Dolby AC-3 decoder, DTS digital Output.
Video output, Coaxial digital audio output,
2channel stereo audio output.
Front L/R audio in, video in.
TVtuner.(option)
Last scene memory, Shock Memory(DVD/4sec, CD/
10sec).
Parental lock
Compatibility of DVD, CD, VCD, Picture CD,
MP3 file, JPEG file and disc formats of CD-R,
CD-RW and CD-G(only audio).
DVD/Tuner/Aux Mode Select(tuner option).
NTSC/PAL compatibility
Playback functions of Multi-angle Multi-language
Pause, Fast Forward/Backward Search, Slow, Step,
Zoom, etc.
DC jack, Molex type jack.
Remote eye sensor jack.
Safety Information
Cleaning Discs
When a Disc becomes dirty, clean it with a cleaning
cloth. Wipe the Disc from the center out, in a straight
line.
Do not use solvents such as benzine, thinner, comm-
ercially available cleaners, or anti-static spray inten-
ded for analog discs.
Always keep the tray closed to avoid dust on the lens.
The lens may cloud over if you suddenly move the
CARDVD Player from cold to warm surroundings.
Playing a Disc is not possible then. Leave the power
on for about one hour with no Disc in the Player until
normal playback is possible.
Do not expose the system to excessive moisture,
rain, sand, or heat sources.
Place the CARDVD Player on a firm, flat surface.
Keep the CARDVD Player away from domestic
heating equipment and direct sunlight.
When placing the CARDVDPlayerinacabinet,
allow about one inch of space all around the CAR
DVD Player for ventilation.
ACCESSORIES:
Remote eye sensor 1PCS
RCA Cable(1.2m) 1
Rubber foot 4
DC Power Cable(Molex type) 1
Remote 1
Batteries(AAA1.5V) 2
Mounting brackets 2
screw 4
OWNER S MANUAL 1
PCS
PCS
PCS
PCS
PCS
PCS
PCS
PCS'
Contrasts Between Disc Types
DVD SVCD
VCD CD LD
Recording Digital/MPEG2 digital digital Analog
Capacity
Double
layer
Mono
side,
8.5GB
Mono
layer,
double
Side,
9.4GB
Double
sides,
double
layer,
17GB
650MB 650MB
Play time
133
min
45min 74min
1side:60min
2side:102min
Disc
diameter
12cm/8cm 12cm
12cm
/8cm
30cm
/20cm
Horizontal
resolution
500lineorabove
350
line
430
line
scale
Multi-scales One
Subtitle
language
32 subtitle language 8Utmost 16
Sound Dolby decoder/ linear PCM
Linear
PCM
Linear PCM,
FM
Sound
quality
44.1KHz, 48KHz,96KHz16,20,24bit
44.1KHz
/16bit
channels
Dolby digital/linear PCM:8
Dolby digital/5+1 linear PCM:8
42
Linear
PCM:2
analog:2
242
min 266
min 484
min
One side,
mono
layer
4.7GB
Supporting Functions / Operation
DOLBY digital surround sound
NTSC zone code & TVsystem
ALL
NTSC
Numbers of sound language
Numbers of subtitle language
2
Picture scale mode
16:9 LB
Parental lock
R RESTRICTED
View angle
4
Close caption
(Only NTSC)
CC
Supporting function of disc
DVD discs can support many functions, different
makers, and different function support. Prevalent
marks of a few functions as follows:
Operation and Use
1Connect the DVD Player directly to the LED
.
2. Play Discs
3. Playing An Auxiliary A/V Source:
ǃ
Turn on the LED power and press the POWER key
of CARDVD Player. Set the TVto the correct Video In channe
l
A/Vcable between CARDVD player and LED set.
See your TVmanual for details. Or, change TV
channels until you see the manufactory's LOGO
on the TVscreen.
Press on either the remote or the front panel
to open and close the drawer.
If the disc is a DVD, the unit will play the MENU or TITLE
of the disc.
If the disc is VCD or SVCD, the unit will begin play as
authored.
If the disc is a music CD the unit will play sequentially from
track 1.
Press the key on the remote. Shuffle to input watching
the programs from other outside A/Vdevices.
OPEN/CLOSE
AV
or Monitor
or Monitor
or Monitor
to
Front Panel Diagram
AUDIO
VIDEO
POWER EJECT
PLAY/PAUSE STOP SKIP
EARPHONE
8
9
10
1
234567
2. Earphone output jack
3. Infrared I.R.
4. Play/pause button
6. Skip button
7. External A/Vinput
8. Eject button
1. Power button 5. Stop button 9. DVD disc holder
10. Power indicatior
