AudioBahn ACS2035N Manual de usuario
ACS SERIES FULL-RANGE SPEAKERS
ACS2093N / ACS2092N / ACS2068N
ACS2063N / ACS2062N / ACS2050N
ACS2046N / ACS2041N / ACS2040N / ACS2035N
OPERATING INSTRUCTIONS
PLEASE RETAIN MANUAL FOR FUTURE USE AND REFERENCE
QUALITY, RELIABILITY, & PURE BLISS
2
Getting Started-------------------------------------------------------
Introduction-----------------------------------------------------------
Features and Specifications--------------------------------------
Mounting and Setup------------------------------------------------
Wiring-------------------------------------------------------------------
Removing the Tweeter---------------------------------------------
Choosing a Location------------------------------------------------
Installation-------------------------------------------------------------
General Wiring-------------------------------------------------------
Securing the Speaker----------------------------------------------
Troubleshooting------------------------------------------------------
Warning and Disclaimer-------------------------------------------
Warranty---------------------------------------------------------------
Welcome to Audiobahn Inc.. This manual has been designed to provide information for
the owner, salesperson, and installer. For those of you who want quick information on
how to install this product, please turn to the installation section of this manual. Other
information can be located by using the table of contents. We at Audiobahn Inc. have
worked very hard to make sure that all of the information in this manual is current, but,
as we are constantly finding new ways to improve our product, this information is subject
to change without notice. All updated information can be found on our web page in the
technical support section.
Getting Started
Table of Contents
2
3
4
5-8
9
10
11
12
13
14
15
17-18
16
Cast Composite Flame Basket
Cast Compositie Indigo Grille
Indigo Blue Poly-Carbon Cone
EPDM Rubber Surround
2 Layer High-Temp ASV Voice Coil
4-Ohm Impeadence
Outboard 12dB Matched Component Crossovers
Complete with Mounting Hardware
ACS2093N: 6x9" 3-Way
ACS2092N: 6x9" 2-Way
ACS2068N: 6X8" 2-Way
ACS2063N: 6.5" 3-Way
ACS2062N: 6.5” 2-Way
ACS2050N: 5.25" 2-Way
ACS2046N: 4X6” 2-Way
ACS2041N: 4x10" 2-Way
ACS2040N: 4" 2-Way
ACS2035N: 3.5" 2-Way
ACS2093N: 225 Watts RMS
ACS2092N: 200 Watts RMS
ACS2068N: 105 Watts RMS
ACS2063N: 110 Watts RMS
ACS2062N: 100 Watts RMS
ACS2050N: 80 Watts RMS
ACS2046N: 80 Watts RMS
ACS2041N: 100 Watts RMS
ACS2040N: 80 Watts RMS
ACS2035N: 60 Watts RMS
ACS2093N: 40 oz.
ACS2092N: 40 oz.
ACS2068N: 20 oz.
ACS2063N: 20 oz.
ACS2062N: 20 oz.
ACS2050N: 17 oz.
ACS2046N: 17 oz.
ACS2041N: 20 oz.
ACS2040N: 17 oz.
ACS2035N: 14 oz.
ACS2093N: 25Hz-25kHz
ACS2093N: 25Hz-25kHz
ACS2068N: 30Hz-22.5kHz
ACS2063N: 40Hz-25kHz
ACS2062N: 40Hz-22.5kHz
ACS2050N: 50Hz-22.5kHz
ACS2046N: 50Hz-22.5kHz
ACS2040N: 40Hz-22.5kHz
ACS2040N: 70Hz-22.5kHz
ACS2035N: 100Hz-22.5kHz
ACS2093N: 96dB
ACS2092N: 96dB
ACS2068N: 95dB
ACS2063N: 95dB
ACS2062N: 94dB
ACS2050N: 94dB
ACS2046N: 93dB
ACS2041N: 93dB
ACS2040N: 92dB
ACS2035N: 92dB
Power Handling
Frequency
Speaker Size
Specifications
Features
Features and Specifications
�
Magnet Weight
Sensitivity
Mounting and Setup
�
ACS2093N / ACS2092N
ACS2068N
All measurements are in millimeters.
Mounting and Setup
ACS2041N
All measurements are in millimeters.
ACS2046N
Mounting and Setup
�
All measurements are in millimeters.
ACS2050N
ACS2063N / ACS2062N
Mounting and Setup
�
ACS2035N
ACS2040N
Wiring
�
Audiobahn ACS series full-range speakers come with a separate crossover network.
The wires are marked for polarity. The solidblue wires are (-) negative, and the blue
wires with a silver stripe are (+) positive. If you take the cover off the crossover, you can
see that the wires are labeled inside, (IN) for Input, (W) for Woofer, and (T) for Tweeter.
Each set of wires has their own label with a + or - next to them. To mount the crossover,
use the supplied screws or double-backed tape to secure the crossover to a solid
mounting location. You can extend the wires if you need to mount the crossover further
away from the speaker. Try to keep the crossover as close as possible to the speaker.
+ Wire
- Wire
INPUT TWEETER
WOOFER
+
_
+
_
The speaker has 2 sets of terminals on it. The set of terminals with one large terminal,
and one small terminal, is for the woofer. The large terminal is (+) positive. The
connection for the tweeter has a plastic rectangular block that is approximately 3/4” x
1/2”. This connection has 2 small terminals in the block. There is also a small label in
plastic on the block indicating + and - wiring. Match the + and - on the block to the +
and - on the back of the basket of your speaker. The + terminal on your speaker will
have a red dot located next to it. Slide the block into place and your tweeter is now
securely wired.
+
_
