Audio Technica 6000 Series Manual de usuario

WirelessSystemMonitor

1.Importantinformationaboutthishelpdocument

2.Foryoursafety

3.Preparationforsystemuse

4.GUIofWirelessSystemMonitor

5.Registeringdevicesandmanagingfrequencies

6.Operatingenvironment

7.Troubleshooting

8.Aboutlicensing

1.Importantinformationaboutthishelpdocument

PleasereadthishelpdocumentalongwiththeATW‒R6200SUserManual.Forthe

latestinformationaboutthesoftwareof“WirelessSystemMonitor”,seetheAudio‒

Technicawebsite.

2.Foryoursafety

WirelessSystemMonitorshouldbeusedinalocalnetwork.Ifyouconnecttothe

Internetviarouters,etc.,securitymeasuresshouldbetakentopreventaccessfrom

outside.ThereisapossibilitythatapersonwhoisnotauthorizedtouseyourPCoran

outsidercouldunintentionallyoperateorcausedamagetoﬁles.Werecommendthat

yousetapasswordusingthescreensaver,etc.

3.Preparationforsystemuse

3.1InstallingWirelessSystemMonitor

3.2Connectingdevicesandsettingnetwork

3.3StartingWirelessSystemMonitor

3.1InstallingWirelessSystemMonitor

(1)FromtheAudio‒Technicawebsite,downloadthelatestversionofthesoftwarefor

WirelessSystemMonitor.

(2)Closeanyrunningprogram.Also,closeanyprogramrunninginbackground.

(3)Unzipthedownloadedprogramandexecute“atwsm‒x.x.x.msi”init.

(4)Performtheinstallationbyfollowingtheinstructionsonthewizard.

3.2Connectingdevicesandsettingnetwork

3.2.1HowtoconnectaPCwithATW‒R6200S

3.2.2Settingdevices

3.2.1HowtoconnectaPCwithATW‒R6200S

(1)TurnoﬀthePCandATW‒R6200SbeforeconnectingthemtoahuborrouterwithDHCP

server.

(2)ConnecttheATW‒R6200StoahuborrouterwithDHCPserverandthePCtoahubor

routerwithDHCPserverusingLANcables.

(3)IfyouaddanyadditionalATW‒R6200Sreceivers,connectLANcablestoavailableports

onthehub.

(4)TurnonthehuborrouterwithDHCP,ATW‒R6200andPC,inthisorder.

(5)Afterthesuccessfulconnection,thelinkLEDonthereceiver'sNetworkInterfacejackwill

lightupanditsactiveLEDwillblink.

3.2.2Settingdevices

SettingahuborrouterwithDHCPserver

SettingATW‒R6200S

SettingPC(Windows)

(Note)IfyouwanttoautomaticallyassignIPaddressesintheLAN,youshouldenable

theDHCPserveroneithertheATW‒R6200S,orahuborrouterwithDHCPserver.

■MorethanoneDHCPservershouldnotexistinaLAN.Thefollowingtabledescribesvalid

conﬁgurationsfortheDHCPserver.

■IfyouusetheDHCPserverontheATW‒R6200SorallthedevicesettingsusestaticIP

addresses,ahubwithouttheDHCPserverfunctionmaybeused.

PC Huborrouterwith

DHCPserver ATW‒R6200S

First

installation

Secondor

subsequent

installation

Pattern

DHCP

server ‒ AutoIP AutoIP

Pattern

DHCP

client DHCPserver AutoIP AutoIP

Pattern

DHCP

client ‒DHCP

server AutoIP

*1ForAutoIPonATW‒R6200S,see“ObtainanIPaddressforATW‒R6200S

automatically”.

*2ForDHCPclientonPC,see“ConﬁguringDHCPclient”.

*3DHCPclientandAutoIPmaybesetasstaticIPaddresses.

SettingahuborrouterwithDHCPserver

■EnablingtheDHCPserveronthehuborrouterwithDHCPserver

WhenyouenabletheDHCPserveronthehuborrouterwithDHCPserverinuse,refertothe

device'susermanualtoconﬁguretheDHCPserver.Alternatively,consultwithyournetwork

administrator.

■EnablingtheDHCPserverontheATW‒R6200S(see“EnablingtheDHCPserveronATW‒

R6200S”)

DisabletheDHCPserveronthehuborrouterwithDHCPserver.

SettingATW‒R6200S

EnablingtheDHCPserveronATW‒R6200S

IfmultipleATW‒R6200Sreceivershavebeenconnected,enabletheDHCPserverononly

oneofthem.SetastaticIPaddressontheATW‒R6200StobetheDHCPserver.

(1)Set[IPSelect]of[Network]to[STATIC].

1)Fromthemainmenu,turnthecontroldialtoselect[Network]andpressthe

controldial.

2)Select[IPSelect]andpressthecontroldial.

3)Select[STATIC]andpressthecontroldial.

(2)SettheIPaddressat[IPAddress]of[Network].
