AT-SB727
Wireless Stereo Disc Player System
User Manual
English
4
Notes on use
Be sure to read the connected device’s user manual before use.
Minimize the volume on your device before connecting the product.
Do not subject the product to strong impact.
Do not store the product in direct sunlight, near heating devices, or in hot, humid, or dusty places. Additionally, do
not allow the product to get wet.
The product should be positioned on a flat, level surface and not installed vertically, etc.
Do not touch the record or attempt to move the product when in use.
When not in use, remove the record and store the 45 RPM adapter and tonearm under the cover. Also, attach the
provided protector to the cartridge.
When carrying the product, hold the carrying handle firmly and do not grasp the cover.
Do not touch the stylus of the cartridge with your finger.
Do not allow the cartridge's stylus to bump against the platter or the edge of the record.
With long-term use, the product may become discolored due to ultraviolet light (especially direct sunlight) and wear.
Make sure to hold the plug when connecting and disconnecting the USB charging cable. The USB charging cable
may become severed or an accident may occur if you pull on the cable itself.
When in use, do not attempt to connect or disconnect the USB charging cable.
When you are not using the USB charging cable, disconnect it from the product.
If you use the product near an electronic device or transmitter (such as a mobile phone), unwanted noise may be
heard. In this case, move the product away from the electronic device or transmitter.
If you use the product near a TV or radio antenna, noise may be seen or heard in the television or radio signal. In this
case, move the product away from the TV or radio antenna.
Ensure that the plug is inserted all the way to the base.
To protect the built-in rechargeable battery, charge it at least once every 6 months. If too much time passes between
charges, the life of the rechargeable battery may be reduced, or the rechargeable battery may no longer be able to be
charged.
Charge the product in a well-ventilated place (10 to 35°C (50 to 95°F)) away from direct sunlight. Otherwise, the
battery may deteriorate, possibly resulting in shorter periods of continuous use or failure to charge.
If the battery runs out soon after charging the product, the rechargeable battery may have reached the end of its
service life. If this is the case, the rechargeable battery will need to be replaced. (Battery replacement must be
performed by a professional in some countries and regions.)
This product can be used only in the countries where certified or where it complies with the Radio Law of the country
in question. It cannot be used in countries other than those in which it is sold.
5
For a more comfortable Bluetooth communication
experience
The effective communication range of this product varies depending on obstructions and radio wave conditions. For a
more enjoyable experience, please use the product as close as possible to the Bluetooth device. To minimize noise and
sound disruptions, avoid placing your body or other obstacles between the product’s antenna and the Bluetooth device.
6
Part names and functions
Main unit
9
5
8
6 7
2
1
3
4
5
1
Power supply indicator lamp
Lights or flashes in white when the power turns on.
2
Speed indicator lamp
Turns off when the platter speed is 33-1/3 RPM and lights in white when 45 RPM.
3
Power supply button
Turns power on and off.
4
Platter speed button
Select the platter speed (33-1/3 or 45 RPM).
5
Tonearm fixing screw
6
Wireless function button
Used to connect the product with Bluetooth devices.
7
Carrying handle
8
Stereo line output terminal
Connect the RCA audio cable.
9
Charging terminal
Connect the USB charging cable.
Part names and functions
7
Main unit (with cover open)
3 4
5 6 7
21
1
Open button
Slide to open the cover.
2
Cover
3
Tonearm
4
Headshell and cartridge
The cartridge is attached to the headshell.
5
Platter
6
Spindle
7
Protector
Part names and functions
8
Accessories
3
21
1
USB charging cable (Approx. 1.5 m (4.9'), USB Type-A / USB Type-C™)
2
RCA audio cable (Approx. 1.2 m (3.9'))
3
45 RPM adapter
9
Preparation for use
Removing the tonearm fixing screw
When purchased, the product includes a screw for fixing the tonearm. Remove the fixing screw before using the
product.
Safely store the removed screw and reinstall it when transporting the product for repairs in the event of a
malfunction, etc.
1
1
Tonearm fixing screw
Setting up the turntable
Position the product on a level surface. Do not attempt to use it in a vertical position, etc.
To avoid the effects of vibrations and acoustic pressure, do not mount the product next to such items as speakers.
The product may pick up radio static if placed next to a radio. Therefore, try to keep the product away from radios.
If the product is near equipment (cell phone, etc.) that emits strong radio waves, noise may occur.
Charging
Fully charge the battery when using for the first time.
Preparation for use
10
When the rechargeable battery is running low, the color of the power supply indicator lamp will change to red.
Charge the battery as soon as possible.
It takes about 12 hours maximum to charge the battery fully. (This time may vary depending on usage conditions.)
Charge the product in a well-ventilated place (10 to 35°C (50 to 95°F)) away from direct sunlight. Otherwise, the
battery may deteriorate, possibly resulting in shorter periods of continuous use or may fail to charge.
1Connect the included USB cable (USB Type-C side) to the product’s charging terminal.
The included USB cable is designed for exclusive use with the product. Do not use any other USB cable.
When inserting the USB cable into the USB power adapter or charging terminal, insert it directly (horizontally).
1 2 3
1
USB Type-C
2
USB Type-A
3
USB power adapter (sold separately)
2Connect the included USB cable to a commercially sold USB power adapter and plug it into an outlet
to start charging.
While charging, the power supply indicator lamp lights/flashes as follows. (It may take several seconds for the
power supply indicator lamp to light.)
Power supply indicator lamp Status
No change (white) Charging / Charging complete (power ON)
Flashing red Charging (power OFF)
Off Charging complete (power OFF)
Flashing red quickly Charging error
3When charging is complete, disconnect the USB power adapter from the outlet.
4Disconnect the USB cable from the product’s charging terminal.
Preparation for use
11
When charging, make sure to use the included USB cable. The product may not charge with cables other
than the included USB cable.
Placing a record
1Slide the open button forward and open the cover.
1 2
1
Cover
2
Open button
2Pull out the tonearm until a click is heard.
Do this while the power is off. Turning the power on before moving the tonearm will cause the platter to start
rotating.
Be careful not to damage the cartridge’s stylus tip, the platter, or the record.
1
Preparation for use
12
1
Tonearm
3Remove the 45 RPM adapter.
1
1
45 RPM adapter
4Place the record on the platter so that the center hole aligns with the spindle.
Place the 45 RPM adapter above the record when playing LP records.
Place the 45 RPM adapter below the record when playing 45 RPM records.
LP 45 RPM
5Close the cover.
