Audio international DVD-010 Manual de usuario

7300 Industry Drive, North Little Rock, AR 72117

Phone: 501-955-2929 Fax: 501-955-2988

Guide to Operations

Digital Video Disc Player

Model #’s: DVD-010, DVD-011,

DVD-012, DVD-013

Document #560017

AUDIO INTERNATIONAL, INC. ______ 12/97

Document #560017, Rev. IR, Model No.: DVD-010 (-011, -012, -013)

The DVD-010, DVD-011, DVD-012, and DVD-013 has been

engineered to meet aircraft use requirements.

READ THIS MANUAL COMPLETELY BEFORE

OPERATING YOUR VIDEO CASSETTE PLAYER

If you have any questions, please contact Audio International, Inc. See the last

page of this booklet for the nearest AI representative.

AUDIO INTERNATIONAL, INC. ______ 12/97

Document #560017, Rev. IR, Model No.: DVD-010 (-011, -012, -013)

(This page intentionally left blank)

AUDIO INTERNATIONAL, INC. ______ 12/97

Document #560017, Rev. IR, Model No.: DVD-010 (-011, -012, -013)

TABLE OF CONTENTS

Page

Product Features…………………………………………………………………………………. 6

Warnings………………………………………………………………………………………… 7

Cautions………………………………………………………………………………………….. 8

General Care……………………………………………………………………………………... 9

Introduction……………………………………………………………………………………… 10

Illustration of Front Panel……………………………………………………………………….. 11

Infrared Remote Unit……………………………………………………………………………. 13

Set-Up Main Menu………………………………………………………………………………. 14

Preferred Language Set-Up……………………………………………………………… 14

TV Shape Menu…………………………………………………………………………. 15

Angle Icon Menu………………………………………………………………………… 17

Audio Menu……………………………………………………………………………… 19

Subtitle Menu……………………………………………………………………………. 21

Disc Menu……………………………………………………………………………….. 24

Parental Lock Function………………………………………………………………….. 25

Operating Instructions…………………………………………………………………………… 27

Standard Playback……………………………………………………………………….. 27

Title, Chapter, or Track Selection……………………………………………………….. 29

AUDIO INTERNATIONAL, INC. ______ 12/97

Document #560017, Rev. IR, Model No.: DVD-010 (-011, -012, -013)

TABLE OF CONTENTS-CON’T

Page

Favorite Order Playback…………………………………………………………………. 30

Random Order Playback………………………………………………………………… 32

Viewing Disc Information and Operating Status………………………………………... 33

Troubleshooting Guide…………………………………………………………………………... 36

Appendix………………………………………………………………………………………… 37

Authorized Representative………………………………………………………………………. 39

AUDIO INTERNATIONAL, INC. ______ 12/97

Document #560017, Rev. IR, Model No.: DVD-010 (-011, -012, -013)

PRODUCT FEATURES

•Custom Design for Aircraft: Operates directly from 28 VDC

Compact, lightweight package

•Multiple Control Options: Optional infrared remote controllable

RS-485 digital data bus compatible

•High Quality Output: Audio: Hi-fidelity, Digital Stereo

Video: 720 Pixels/Horizontal Line

•Playback Options: Accepts DVD & Audio CD’s

8 Language & 32 Subtitle Options

Frame-by-frame Disc Advance

Choice of Camera Viewing Angles

Favorite Segment Programming

•Product Compatibility: NTSC Color System

Video Disc Sizes 8 cm or 12 cm (single or double sided)

Audio CD Disc Sizes 8 cm or 12 cm

AUDIO INTERNATIONAL, INC. ______ 12/97

Document #560017, Rev. IR, Model No.: DVD-010 (-011, -012, -013)

WARNINGS

•DO NOT look directly into the laser beam through the disc tray, etc.

Eyesight may be damaged.

•DO NOT place fingers in disc tray when the tray is moving. Tray

may close on fingers causing injury.

•DO NOT attempt to open the cabinet. Refer servicing to qualified

personnel.

•DO NOT place foreign objects into openings. Contact with foreign

objects may result in dangerous voltage or electric shock.

•DO NOT place unit near strong magnetic fields.

•DO NOT place unit near radiators and other heat sources.

STOP

AUDIO INTERNATIONAL, INC. ______ 12/97

Document #560017, Rev. IR, Model No.: DVD-010 (-011, -012, -013)

CAUTIONS

•DO NOT drop the unit, subject it to heavy impact, or place heavy objects

on the unit.

•DO NOT use this unit other than for its intended purpose. Doing so might

lead to electric shock or injury.

•DO NOT use near water, moisture, or volatile sprays. Do not use any

type of solvent when cleaning (surface damage may occur).

•DO NOT move the unit during playback. Damage to the disc may result.

•DO NOT use in cold, unheated cabin area. Moisture condensation may

damage the internal parts. Wait for the cabin to warm.

•DO NOT expose to sunlight or bright light. Damage to the sensor will

result.

CAUTION

AUDIO INTERNATIONAL, INC. ______ 12/97

Document #560017, Rev. IR, Model No.: DVD-010 (-011, -012, -013)

GENERAL CARE

•When playing a disc for the first time, check that there are no burrs stuck in the center

hole of the disc.

•Do not touch the playback side of the disc. Do not apply tape to either side of the disc.

•Do not store discs in hot locations or in areas exposed to direct sunlight. Do not store in

damp moist areas.

•Remove discs from the player and return to their cases after each use. Do not stack loose

discs or prop them against anything.

•To clean dirty discs, wipe gently with a soft cloth. Start from the center of the disc and

move outward in a circular motion. Do not clean with solvents or other chemicals.

•Dust or fingerprints on the disc may cause sound or picture difficulties.

•When cleaning heavy dirt from the unit, soak a soft cloth in a weak detergent solution.

Wring out excess liquid and gently wipe the unit. Dry the unit thoroughly with a soft

cloth. Do not use liquid or aerosol cleaners.

AUDIO INTERNATIONAL, INC. ______ 12/97

Document #560017, Rev. IR, Model No.: DVD-010 (-011, -012, -013)

INTRODUCTION

•Before setup or playing a disc, ensure that aircraft power is applied to the player. There

are no on/off controls on the unit. Power controls are located in the cockpit or cabin.

•Activate the monitor and speakers from the appropriate control panel. Audio will be

supplied through headphones or speakers.

•The names and functions of the DVD front panel are as follows:

1. Open/Close Button - To eject or load a disc from the DVD slot.

2. Play Button - To start playback of a disc or CD.

3. Skip (Forward) Button - To fast-forward the tape or to start a forward visual

4. Skip (Backward) Button –To reverse the tape or to start a backward visual

search.

5. Pause Button - To temporarily stop the tape during playback or a recording.

6. Stop Button - To stop the disc or CD tape.
