Audi Q7
Quick reference guide
Fuel and tyre
pressures
(see sticker)
Fuel tank flap
To open:
Press the switch on the
driver’s door.
To close:
Press the tank flap until you hear
it click into place.
Engine oil
The correct oil specifi-
cations and engine oil
capacity are listed in
the Performance,
weights and dimen-
sions section of the
Owner’s Manual.
Warning triangle
The compartment for the
warning triangle is located
behind the cover in the tailgate.
Welcome
Dear Audi Driver,
This quick reference guide gives you
an overview of the main features and
controls of your vehicle. However, it
cannot replace the detailed Owner’s
Manual which contains important
information and safety warnings.
Please refer to your Owner's Manual for
detailed information on your vehicle.
You will find everything you need to
know about the radio, CD, navigation,
TV and telephone functions in the
Infotainment/MMI Operating Manual.
We wish you safe and enjoyable
motoring with your new Audi.
AUDI AG
AUDI Q7
Controls
and displays
Unlock switches for:
Tailgate
Tank flap
Bonnet lock release
Parking brake
To apply: Press pedal firmly
with your foot.
To release: Pull lever .
Parking brake release lever
Adjuster for exterior
mirrors
Turn the adjuster for:
Left exterior mirror
Exterior mirror heating
Right exterior mirror
Exterior mirror
retraction
5
4
4
3
2
1
Press the adjuster to move
the mirror glass in the
desired direction.
Electric windows
To set the desired position:
Press/pull to the first stop
and hold.
”One-touch” function:
Press/pull briefly to the
second stop.
Buttons for seat memory
Light switch
Button for side assist
Door handle and central
locking switch
Lock
Unlock
10
9
8
7
6
7
10 9
8
11
12 13
14 14
15
16
17
18
3
2
4
5
6
1
Overview
Switches and warning
lamps for:
Electronic stabilisation
program
Hazard warning lights
Passenger airbag off
CD player or CD changer
Air conditioner
Selector lever
(for automatic gearbox)
or gear lever
MMI control console
Buttons for:
Starting engine
Switching off engine
27
26
25
24
23
ESP
OFF
22
side assist warning lamp
Headlight range control
Cruise control system or
adaptive cruise control
Controls on multi-function
steering wheel
Turn signal and main beam
lever with button for lane
assist
Instruments and warning/
indicator lamps
Windscreen wipers/washer
and buttons for on-board
computer
Steering wheel position
adjuster
18
17
16
15
14
13
12
11
Buttons for:
Activating/deactivating
parking system plus/
advanced
Resetting trip recorder
Check function
Instrument lighting
MMI display
Buttons for:
Switching MMI display
on/off
Opening glove box
CHECK
P
19
21
20
19
20
21
22
23
24
25
26
27
advanced key
1
Switching on the ignition/starting the
engine
On vehicles without the advanced key, start
the engine in the normal way using the car
key. On vehicles with the advanced key, you
can start the engine without inserting the
key in the ignition lock.
To switch on the ignition: Press the START
button down to the first stop. The glow
plugs on diesel engines start preheating in
this position.
To start the engine: Press the brake pedal
(on an automatic vehicle move the selector
lever to Por N) and press the START button
down to the second stop.
To switch off the engine: Stop the vehicle
(on an automatic vehicle move the selector
lever to position Por N) and press the
STOP button.
If you press the STOP button again for at
least one second,
this will lock
the steering.
Locking and unlocking the vehicle
The advanced key allows you to lock and
unlock the vehicle without handling the
key itself. You only need to have the
remote control key on your person.
To unlock the vehicle:
Take hold of one of the door handles
or press the release catch on the tailgate.
To lock the vehicle:
Move the selector lever (on an automatic
vehicle) to position P.
Press the exterior locking switch eon one
of the door handles.
To open the tailgate:
The tailgate will spring open slightly when
you unlock it.
To unlock:
Press the button on the remote
control key, or
Press the button on the driver’s door
or the release catch on the tailgate.
To close the power-operated tailgate:
Press the button inside the open tailgate.
7
6
5
4
123
3
Manual seat adjustment
To adjust lumbar support:
Press the appropriate part of
the switch.
To move seat backwards or
forwards:
Lift the lever and move the
seat. Then release the lever
and move the seat further
until the catch engages.
To adjust seat height:
Pull up or press down the
lever.
To adjust backrest:
Take your weight off the
backrest and turn the knob.
3
6
5
4
Adjusting head restraint
To lower, press button pon the
side of the head restraint. The
top of the head restraint should
be at eye level or higher.
Seat adjustment
Electric seat adjustment
To adjust seat height and move seat
backwards or forwards:
Front of seat cushion up/down
Rear of seat cushion up/down
Seat up/down
Seat forwards/backwards
To adjust backrest:
Backrest further upright/
further reclined
To adjust lumbar support:
Press the appropriate
part of the switch.
2
3
1
Sitting position
Sit in a normal upright position and
do not sit too close to the steering
wheel. If necessary, also adjust the
position of the steering wheel.
min.
25 cm
First steps
Panorama roof
The two roof segments are opened/closed
separately when the ignition is on.
To open/close the front segment:
Comfort position: Turn control to
position e.
To open: Turn control towards runtil the
roof reaches the desired position.
To close: Turn control to position .
To tilt open/close the front segment:
Briefly press/pull control in position .
Press/pull the control and hold it to tilt the
roof to any desired position.
To tilt open/close the rear segment:
Briefly press the appropriate symbol on
the rocker switch or on the switch in the
rear headliner. Press and hold the rocker
switch to tilt the roof to any desired
position.
Switches for deluxe automatic
air conditioner
Left switches – left side of vehicle
Right switches – right side of vehicle
Temperature selection
Blower speed
Automatic mode
Set the desired temperature and
press the button.
SETUP
For calling up additional settings on
the MMI display
Air recirculation
Circulates and filters the air in the
interior of the vehicle
ECON mode
Activates/deactivates air cooling
ECON
SETUP
AUTO
Air conditioner
1
2
0
A
B
Speed and distance control
The adaptive cruise control is a cruise
control with integrated distance control.
To switch on/off: Pull/press lever u.
To set speed: Press button t.
To adjust stored speed: Press lever uup
(faster) or down (slower).
The adaptive cruise control will automati-
cally apply the brakes as you approach
a vehicle in front.
To increase/reduce the distance: Press
switch rto the right/left.
Technology
lane assist
Audi lane assist
The lane assist detects lane markings (e.g. on
a motorway). If the vehicle approaches one of
the lane markings, the steering wheel vibrates to
warn you. The warning does not occur if you
operate the turn signals before changing lane.
To activate/deactivate the system, press
button eon the turn signal lever.
1
3
4
2
adaptive cruise control
1
2
2
Multi Media Interface
MMI controls and displays
Driver information system
Multi-function steering wheel
Scroll the left thumbwheel to select a menu item in the
driver information system. Press the thumbwheel to
confirm the selection.
Press the MODE button to switch between the active audio
source and the navigation and telephone functions.
Briefly press the button (talk button) to switch on the
speech dialogue system.
Speak after the <beep>, e.g. say <Help Radio> to call up the
possible commands for operating the radio.
Press and hold the talk button to switch off the speech
dialogue system.
Scroll the right thumbwheel to adjust the volume. If you
press the right thumbwheel, the last navigation cue will be
repeated.
2
1
