AUDAC KYRA12/O Series Guía

KYRA12/O

User & Installation

Manual

www.audac.eu

Introduction

Design column speakers

The KYRA column speakers range is the elegant result of research in the field of phased

array acoustics. The selection of the highest quality materials including aluminum cone

2” drivers guarantee an extraordinary detail and clarity for music and speech, which is

uncommon for any kind of column speaker available from the market. It makes them

perfectly lend themselves to a wide variety of applications in acoustic difficult environ-

ments such as churches, auditoriums, presentation and meeting rooms where audibility

and intelligibility of music and speech have the highest importance.

They are housed in slim and elegant constructed enclosures made out of aluminum

materials and finished with finely perforated grilles. An included mounting bracket with

minimum distance to the wall allows swivelling and down-tilting for perfect directional

placement.

The outdoor version of the KYRA12 series loudspeakers (KYRA12/Ox) feature a special

designed waterproof AWX5™ connector, allowing selection for various power tappings.

A water repellent and UV resistant cloth in front of each driver keeps the elements of

nature at a safe distance. Further added reliability is achieved by using an aluminium

front grill and an electroplated stainless steel mounting bracket. They offer solutions for

uniform acoustic performance in any outdoor system while reducing echo and microphone

feedback to optimize the intelligibility of music & speech.

A multi-tapping line transformer allows them to be connected to 70V/100V public address

systems with various power tapping settings, while connections in low impedance (12Ω)

systems are also possible.

Precautions

READ FOLLOWING INSTRUCTIONS FOR YOUR OWN SAFETY

• ALWAYS KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. NEVER

THROW THEM AWAY

• ALWAYS HANDLE THIS UNIT WITH CARE

• CLEAN ONLY WITH DRY CLOTH

• HEED ALL WARNINGS AND FOLLOW ALL INSTRUCTIONS

• NEVER EXPOSE THIS EQUIPMENT TO RAIN, MOISTURE, ANY DRIPPING OR

SPLASHING LIQUID. AND NEVER PLACE AN OBJECT FILLED WITH LIQUID ON

TOP OF THIS DEVICE

• DO NOT INSTALL THIS UNIT NEAR ANY HEAT SOURCES SUCH AS RADIATORS

OR OTHER APPARATUS THAT PRODUCE HEAT

• DO NOT PLACE THIS UNIT IN ENVIRONMENTS WITH A HIGH LEVEL OF DUST,

HEAT, MOISTURE OR VIBRATION

• THIS UNIT IS DEVELOPED FOR INDOOR USE ONLY. DO NOT USE IT OUTDOORS

• ONLY USE ATTACHMENTS & ACCESSORIES SPECIFIED BY THE

MANUFACTURER.

• ONLY INSTALL THE SPEAKER IN LOCATIONS THAT CAN STRUCTURALLY

SUPPORT THE WEIGHT OF THE SPEAKER. IGNORING THIS CAN BRING THE

SPEAKER DOWN.

• DO NOT USE ANY OTHER METHOD THAN SPECIFIED TO MOUNT THE

SPEAKER. IF EXTREME FORCE IS APPLIED TO THE SPEAKER, IT COULD FALL

DOWN

• ATTACH A SAFETY WIRE TO THE SPEAKER WHEN IT IS MOUNTED HIGH UP.

ONLY USE INDUSTRY-ACCEPTED RIGGING TOOLS AND METHODS

• CAREFULLY CHECK THE UNIT’S CONDITION AFTER UNPACKING.

IF THERE IS ANY DAMAGE TO THE CARTON BOX OR THE UNIT ITSELF,

INFORM YOUR VENDOR IMMEDIATELY.

CAUTION

• USE CABLES OF THE RIGHT GAUGE TO CONNECT THE LOUDSPEAKER

• USE CABLES WITH CLEAR COLOR CODING INDICATING THE POLARITY AND

MAINTAIN THE SAME POLARITY THROUGHOUT THE WHOLE SYSTEM.

• ONLY USE THE CORRECT AMPLIFIER OUTPUT VOLTAGE AND IMPEDANCE.

EXCEEDING THESE LIMITS COULD CAUSE FIRE OR OTHER FAILURES.

AVOID EXPLOSIONS: DO NOT USE THE SPEAKER AROUND GASOLINE,

THINNER OR OTHER COMBUSTIBLES

• AVOID ELECTRIC SHOCKS: SWITCH OFF THE AMPLIFIER WHEN CONNECTING

THE LOUDSPEAKER

• DO NOT USE THE LOUDSPEAKER FOR AN EXTENDED PERIOD OF TIME AT

DISTORTED SOUND. THIS COULD CAUSE PERMANENT DAMAGE.

CAUTION - SERVICING

This product contains no user serviceable parts. Refer all servicing

to qualified service personnel. Do not perform any servicing

(unless you are qualified to do so.)

EC DECLARATION OF CONFORMITY

This product conforms to all the essential requirements and further

relevant specifications described in following directives: 2014/30/

EU (EMC) and 2014/35/EU (LVD)

WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE)

The WEEE marking indicates that this product should not be

disposed with regular houshold waste at the end of its product

life. This regulation is created to protect both the environment

and human health.

This product is developed and manufactured with high quality

materials and components which can be recycled and/or reused.

Please dispose this product to your local collection point or

recycling centre for electrical and electronic waste. This will

make to sure that it will be recycled on an environmentally friendly

manner, and will help to protect the environment in which we all

live.

Installing the KYRA

Mounting the speaker

Every KYRA speaker comes delivered with a two-way revolving bracket, making it

possible to install the speaker at each position and focusing it into the desired direction.

The metal constructed bracket ensures a solid and secure mounting of the loudspeaker

to any possible location.

It consists of two different parts, whereof the first part should be installed to the rear side

of the loudspeaker. It can be assembled on different heights on the rear of the speaker,

depending on the mounting possibilities and required installation height. It is fixated to

the loudspeaker cabinet by inserting the 2 supplied mounting screws into the pre-drilled

and threaded holes at the back of the speaker cabinet.

The second part is a wall plate which has to be fixed to the wall by at least four screws

(preferably six). The type of used fasteners shall be chosen according to the most

suitable type for the mounting surface (brick, concrete, wood, ...). The mounting holes

are provided according to the positions indicated in the following drawing.

87,5

Once both speaker part and wall part are safely attached to their positions, the protective

finishing cover can be assembled over the wall plate by clicking it. Afterwards the speaker

can be assembled to the wall bracket by bringing both parts together and tightening them

through the button head bolt and nuts together through an hex drive key. The upper one

can be used for adjusting the tilt-angle of the speaker.

13°

42°

Once installed, the speaker can be can be panned and tilted, focussing the loudspeaker

into the desired listening direction. This is useful when the installation height on the wall

is limited or the speaker is mounted from the side. The maximum downward tilt is 13°

and the maximum pan in both directions is 42°.

Connecting the speaker

The KYRA12/Ox speakers are designed for use in 70V and 100V public address systems.

Before connecting the loudspeakers to the system, make sure the amplifier is switched

off.

The power tap selection of the KYRA12/O outdoor series speakers is made through the

orientation of the waterproof AWX5™ connector on the rear side of the loudspeaker. This

allows connection to the amplifier output using the included connection cable (AWC07)

with a length of 0.7 meter. The blue conductor shall always be connected to the COM

terminal of the amplifier output and red conductor shall always be connected to the

positive terminal of the amplifier output. Mind the polarity markings when wiring the

loudspeaker cables.

The power tap selection is made by adjusting the rotation angle of the waterproof con-

nector. A dot on the connector indicates the direction of the connector and the various

power tappings are indicated on a label attached to the speaker and in the image below

12 Ω

KYRA12/O

Tapping 100V 70V Imp

Do not use

40 W 125 Ω

B40 W 20 W 250 Ω

D20 W 10 W 500 Ω

After the connector is correctly plugged into the socket, make sure the screw nut is well

tightened to guarantee the IP55 waterproof performance of the loudspeaker.

Additional Information

Technical specifications

KYRA12/O

Max Power 240 Watt

RMS Power 120 Watt

Nominal impedance 12 Ohm

Line transformer taps 125 Ω– 70V/40W

250 Ω– 100V/40W - 70V/20W

500 Ω– 100V/20W - 70V/10W

Drivers 12 x 2” Alu cone full range

Cross-over network Passive built-in (low-cut filter)

Connectors AWX5™

Mounting bracket 2-Way revolving metal bracket (stainless)

Construction Alu extrusion + plastic caps

Front finish Fine perforated aluminum grill

Ingress protection IP55

Operation temperature range -20°C to +50°C

Incline angle Horizontal 0 ~ 42° left & right

Vertical 0° ~ 13° down tilt

Colour White KYRA12/OW (RAL9003)

Black KYRA12/OB (RAL9005)

Dimensions (W x H x D) 70 x 1006 x 101 mm (excl bracket)

Weight 4.30 Kg

Packaging Carton box

Shipping weight & Volume 5.8 Kg - 0.032 Cbm

Accessories included AWC07 connection cable (0.7 meter)

2-Way revolving metal bracket

Cable guiding accessories

Optional accessories AWCxx cables (various lengths)

Notes
