AU Tool DOT3 Manual de usuario

Foreword

This manual provides the usage of this brake fluid tester and the basic profes-

sional knowledge required, including the safety instructions and effective test

instructions for the device, so that the technician can use the device to

perform brake fluid testing. Please read this manual carefully before using the

product for the first time and refer to the following documents to assist in

diagnosis.

● Vehicle Original Service Manual

● Related technical bulletins

● The Material Safety Data Sheet (MSDS) provided by brake fluid

manufacturer. Please put the relevant documents in the portable box of this

device for easy checking at any time.

Safety instructions

General safety guidelines

● Please read this manual before the first use

● Please wear goggles when working and be careful not to splash brake

fluid into your eyes

● Do not perform the test without sufficient liquid in the beaker (the test

stick can be damaged by empty boiling)

● Do not touch to avoid burns after the test, as the test stick and liquid

are at high temperature.

● Do not pour the brake fluid back into the reservoir as the structure of

the fluid has been damaged and the boiling point has been lowered,

otherwise, it will affect driving safety.

● After the test, please empty the brake fluid and fill another 50ml of

water to test the boiling point in order to clean the residual brake fluid of the

test stick.

● If the same brake fluid sample is tested continuously and the data

varies, this is normal because the test sample has been boiled and the

structure has changed.

Statement

● This equipment is designed for brake fluid detection and is not responsi-

ble for any product damage or property damage caused by its use for other

purposes.

● This equipment requires a professional technician or trained service

personnel. Please do not touch or use this equipment with non-automotive

technicians or by children.

Product Description

Structure diagram

Product parameters

● Applicable brake fluid types:

DOT 3, DOT 4, DOT4+, DOT4ESP, DOT 5, DOT 5.1, DOT5.1ESP, ENV4,

ENV6.

● Wet boiling point range: 140 °C ~ 205°C (284°F ~ 401°F) ±5%

● Dry boiling point range: 160 °C ~ 320 °C (320 °F ~ 608 °F)

● Working Voltage: 12 V, minimum 10 V

● Detection time: 16 seconds

● Working temperature range: 0 °C ~ 50 °C

Features

● Battery polarity reverse protection

● The screen will prompt the operation, which is clear and easy.

● Suitable for detecting different types of brake fluid. The minimum

boiling point of brake fluid can be obtained quickly and accurately, and the

official dry and wet boiling point values are also available as a reference.

● No need to use consumable test sticks to save costs.

OLED display

START key

Protective liners

Airhole

TAB key

Test stick

Instructions

Sampling operation

（1）The unit needs to use a 12 V battery as a working power supply.

● Clamp the power clip of the main unit to the 12V battery, and be careful

not to connect the positive and negative reversely or short-circuit with the

vehicle.

（2）Use the injection sampler to suck the brake fluid, take out 50 ml of

fluid, and then fill it into the beaker to be tested.

● Caution! The brake fluid to be tested should be filled into the beaker

over the 40 ml scale and not more than 50 ml.

（3）Put the test stick into the beaker and make sure the sampling hole of

the test stick is immersed in the brake fluid and the air bubbles are bled

from the cavity inside the test head to avoid affecting the test results.

● Do not shake, knock or drop the test head (heater bar) to avoid injury to

the sensor and other parts.

Detection Operation

● The red power clamp is connected to the positive of the battery, and the

black power clamp is connected to the negative, and then the tester is

automatically powered on.

● Select measurement mode: normal mode or brand mode.

● Select the brand and brake fluid type (DOT3\DOT4, etc.).

● After entering the ready interface, press and hold the S button for about

16s, and wait for the progress bar to run full to complete the test. During the

test, the live fluid temperature and battery voltage will be displayed.

● When the test is complete, remove the unit vertically to avoid brake

fluid from being spilled.

Maintenance and Calibration

Maintenance

● When it is not in use for a long time, please detect it with water, so that

the corrosive brake fluid can be removed vertically from the test stick and

dilute the corrosiveness, and then leave the heating stick to dry in the air at

room temperature.

Calibration

● Fill the beaker with water and test if the boiling point is at 100 °C (212 °F)

± 3 %, and make a quick initial diagnosis of whether the tool is working

properly. If more rigorous standards are required, it must be returned to the

factory for re-testing and calibration.

Brake fluid boiling point reference value

Remarks:

DOT 4 + (or Super DOT 4) does not have a standard specification. There are

currently three statements:

● The boiling point specification is in accordance with DOT 4, but the wet

absorption performance is lower.

● The boiling point specification is based on DOT 5.1, but the low tempera-

ture fluidity is based on DOT 4.

● The boiling point specification is 300 °C/ 195 °C, and other properties are

in accordance with DOT 4.

Supporting Brand List

This product covers 14 popular brands in the market:

ATE、TRW、BOSCH、MOBIL、TOTAL、FUCHS、MOTUL、DELPHI、

KUNLUN FERODO、BREMBO、TEXTAR、MONARCH、CHANGCHENG

Brake fluid related knowledge

Brake fluid specifications and components

Types Dry Boiling Point

（Brand new brake fluid）

Wet Boiling Point

（Brake fluid in use）

DOT3 205°C/401°F140°C/284°F

DOT4 230°C/446°F155°C/311°F

DOT4+ 230°C/446°F155°C/311°F

DOT5 260°C/500°F180°C/356°F

DOT5.1 270°C/518°F190°C/374°F

Why do we need to detect the boiling point of brake fluid

● Brake fluid is essentially a corrosive, water-soluble fluid for low-tempera-

ture hydraulics and is not an actual oil. Brake fluid tends to absorb wetness

in the air causing the boiling point to decrease and the brake fluid disc to boil

due to prolonged friction. Brake fluids with lowered boiling points are more

likely to boil and generate vapor due to heat absorption. Since the brake fluid

circuit is a sealed fluid system and no air is allowed to exist, the boiling steam

will affect the transmission of the fluid pressure channel and finally cause

brake failure.

● Generally, the brake fluid should be changed every 20,000 kilometers or

within two years. Detecting the boiling point of brake fluid is to determine

whether the brake fluid is good or bad, which is closely related to driving

safety.

● In addition to the above-mentioned reasons that will cause the air lock

phenomenon to cause the brake to fail, it will also greatly consume the

additives in the oil, causing the brake fluid lose its protective ability and acidify

the brake fluid. And it will produce copper ions, which will cause metal corro-

sion and produce sludge, and finally, jam the master cylinder and sub-cylin-

der of the brake system, and damage the ABS.

Why the actual boiling point is lower than the detected boiling point

● The typical working temperature of brake calipers is about 150°C~200°C.

If the boiling point of the brake fluid is detected to be 180°C when the brake

fluid is taken out from the mouth of the reservoir, the brake fluid caliper point

Base oil

(Compatible

ingredients)

Silicon oilPolyalkylene Glycolether,PAG

Additives Diethylene

Glycol-Ester

BorateEsters

DOT3 DOT4 DOT4+

Dry boiling point

（Boiling point of

new fluid）

205°C

401°F

230°C

446°F

230°C

446°F

270°C

518°F

260°C

500°F

Wet boiling point

（Use boiling point

with caution)

140°C

284°F

155°C

311°F

155°C

311°F

190°C

374°F

180°C

356°F

DOT5.1 DOT5

is actually only about 155°C, because the rubber tubing easily absorbs water,

resulting in a large difference.

How to prevent/remove vapor

● In fact, it is impossible to completely prevent vapor from entering, so

vapor will enter the brake fluid from the brake fluid reservoir cover, rubber

hose, and connector gap.For the majority of cars, vapor increases by about

2% over a year, and this alone can significantly affect brake fluid quality, so it

should be taken seriously.

● The only way to remove water vapor is to use twice the amount of brake

fluid. One bottle is used for rinsing to remove residual vapor in the pipeline,

and the other bottle is used for adding and refilling the pipeline.

Packing list

This unit and related accessories have been carefully inspected before

shipment. After you receive the goods, please check the parts on the follow-

ing list to make sure that they are intact.

● Main unit

● 50 ml Brake fluid sampler

● Sampler matching hose

● 50ml Breaker

● Manual

● Product certification

Specifications

● Product model：AS506

● Gross weight：0.6KG

Interface Display and Description

● Home Interface:

After the power clip is properly connected, the home interface will appear on

the screen. Press the "T" key to switch modes or press the "S" key to select

and enter this mode.

As shown in the figure below:

NORMAL Mode：

● After entering the "NORMAL" mode, you can use the "T" key to switch

the brake fluid types (DOT3, DOT4, DOT5); then press the "S" key to select

the required fluid type.

As shown in the figure below:

● In the NORMAL mode, after selecting a fluid type, it will enter the ready

interface, which displays the reference dry and wet boiling points and battery

voltage of the oil product;

the page is as shown in the figure below:

● In the NORMAL mode, when the ready page is displayed, press and hold

the "S" key, the progress bar starts to read, and the TMP displays the live

temperature value at the same time; after the progress bar is full (about 16s),

the screen will display the final test result. It can be used to judge whether the

brake fluid needs to be changed.

Press the "T" key again to return to the startup homepage.

BRAND Mode：

● Press the "T" key to select "BRAND" on the home interface, and then

press the "S" key to enter the brand selection page; This unit provides 14

kinds of popular brands of brake fluid for users to select. Press the "T" key to

switch brands, and press the "S" key to confirm the brand.

As shown in the figure below:

● After selecting the brand, enter the fluid type selection interface of this

brand; press the "T" key to switch the fluid type, press the "S" key to select.

As shown in the figure below:

● After the fluid type is confirmed, press the "S" key to enter the ready page

under the brand mode. This page will display the dry and wet boiling points,

battery voltage and live temperature.

As shown in the figure below:

● When the ready page is displayed, press and hold the "S" key, the

progress bar starts to read, and the live temperature starts to go up; after the

progress bar is full, the screen will display the final test result for the user's

reference.

As shown in the figure below:

Press the "T" key again to return to the startup homepage after the

detection is completed.

Press the "T" key again to return to the startup homepage.

BRAND Mode：

● Press the "T" key to select "BRAND" on the home interface, and then

press the "S" key to enter the brand selection page; This unit provides 14

kinds of popular brands of brake fluid for users to select. Press the "T" key to

switch brands, and press the "S" key to confirm the brand.

As shown in the figure below:

● After selecting the brand, enter the fluid type selection interface of this

brand; press the "T" key to switch the fluid type, press the "S" key to select.

As shown in the figure below:

● After the fluid type is confirmed, press the "S" key to enter the ready page

under the brand mode. This page will display the dry and wet boiling points,

battery voltage and live temperature.

As shown in the figure below:

may be reproduced, stored in a retrieval system, or transmitted in any form or

by any means, electronic, mechanical, photocopying, recording or otherwise,

without the prior written permission of AUTOOL. The information contained

herein is designed only for the use of this unit. AUTOOL is not responsible for

any use of this information as applied to other units.

Neither AUTOOL nor its affiliates shall be liable to the purchaser of this unit

or third parties for damages, losses, costs, or expenses incurred by purchas-

er or third parties as a result of: accident, misuse, or abuse of this unit, or

unauthorized modifications, repairs, or alterations to this unit, or failure to

strictly comply with AUTOOL operating and maintenance instructions.

AUTOOL shall not be liable for any damages or problems arising from the

use of anyoptions or any consumable products other than those designated

as OriginalAUTOOL Products or AUTOOL Approved Products by AUTOOL.

Other product names used herein are for identification purposes only and

may betrademarks of their respective owners. AUTOOL disclaims any and all

rights in those marks.

Manual are either trademarks, registered trademarks, service marks, domain

names, logos, company names of or are otherwise the property of AUTOOL

or its affiliates. Incountries where any of the AUTOOL trademarks, service

marks, domain names, logos and company names are not registered,

AUTOOL claims other rights associated with unregistered trademarks,

service marks, domain names, logos, and company names. Other products

or company names referred to in this manual maybe trademarks of their

respective owners. You may not use any trademark, service mark, domain

name, logo, or company name of AUTOOL or any third party without permis-

sion from the owner of the applicable trademark, service mark, domain name,

logo, or company name. You may contact AUTOOL by visiting AUTOOL at

https://www.autooltech.com, or writing to [email protected], to

requestwritten permission to use Materials on this manual for purposes or for

all other questions relating to this manual.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Equipo de diagnóstico de AU Tool

AU Tool

AU Tool CT-200 Manual de usuario

AU Tool

AU Tool CS520 Manual de usuario

AU Tool

AU Tool LM 706 Manual de usuario

Manuales populares de Equipo de diagnóstico de otras marcas

Mindray

Mindray M7Vet Guía de inicio rápido

Autel

Autel MaxiProgrammer 201 Manual de usuario

TEXA

TEXA TMD2 Manual de usuario

Autel

Autel MaxiIM IM608 Manual de usuario

Sealey

Sealey BT2012 Manual de usuario

Diagnoptics

Diagnoptics Age Reader Manual de usuario

LAUNCH TECH

LAUNCH TECH X-431 PRO5 Manual de usuario

Hella Gutmann

Hella Gutmann Mega macs X Manual de usuario

Foxwell

Foxwell I80TS Manual de usuario

KaVo

KaVo 3D eXam Manual de usuario

ATEQ

ATEQ VT46 Manual de usuario

Hella Gutmann

Hella Gutmann mega macs X Manual de usuario

Autel

Autel MaxiFlash VCMI Manual de usuario

Qiagen

Qiagen QIAcube Connect MDx Manual de usuario

Alber

Alber BDSU Manual de usuario

St. Jude Medical

St. Jude Medical QUANTIEN Manual de usuario

Bosch

Bosch DCU 100 Manual de usuario

Launch

Launch CNC-602A Manual de usuario
