Atmor INLINE 900 Manual de usuario

Hot Water on Demand

Step 4

Connect the Cold water hose to

the inlet on the left side of the unit.

(Don't forget to insert rubbers).

Be sure to use reinforced hose.

Be sure to close it properly.

Step 1

Find the optimal place.

Drill 4 holes and insert Plugs.

Step 2

Open the entrance cable in the

back of the unit.

Be sure to open the side of the

cable

Step 3

Hang the unit on the wall by 4

screws.

Don't forget to inset the electric

cable before.

Step 5

Connect the Hot water hose to the

outlet (Don’t forget the rubbers).

Be sure to use reinforced hose.

Be sure to close it well.

Open the water supply and check for

leakage around the hoses.

If there is no leakage - Go to step 6

leakage

Check again.

Don’t continue unless you sure

there is no leakage.

Step 6

Connect the electric cable to the

Terminal block.

Step 7

Close the cover by 4 short

screws

After closing the screws

Insert the Gray Bottom cover

OUTLET

INLET

Atmor Super 900 - Assembly Steps

FREEPHONE 0800 101 201 / sales@atmor.co.nz / www.atmor.co.nz

External PRD installed

at water inlet

Hot Water on Demand

Step 1

Fit isolating tap on

cold water supply

Step 2

Having already entered the

power cable, connect to the

terminal block.

Step 7

Blue Wave 402 - Assembly Steps

FREEPHONE 0800 101 201 / sales@atmor.co.nz / www.atmor.co.nz

Position heater at

eye level or higher.

Fix to the wall 2 top

and 1 bottom screw

Step 6

Step 4

Assemble and fit the sliding

shower bar to the wall including

the shower hose and rose

Step 3

Turn on the water to fill

the heating chamber and

check for leaks

Connect cold water supply

inlet hose

Step 5

Attach the front cover, round

the knobs to match the correct

pivot and secure by screw

top and bottom.

For further information on installation and operation

please refer to leaflet enclosed with the heater.
